Icom IC-F620 Programming Software Manual page 43

Group Field
C. Tone RX, TX
Text
RF Pwr
TOT
Lockout
CS-F620TR Programming Software Manual
Description
Can be set to "DTCS" (Digital Tone Coded
Squelch), "OFF" or any number of CTCSS
selections from 67.0 to 254.1. If you select
"DTCS," you must manually enter the Digital
Code you wish to use. Also, when entering
DTCS, enter "N" after the three digit number
for normal polarity and "I" after the three digit
number for inverse polarity (as in screen shot
that follows). Note the "023N". See page 42 for
recommended DTCS Tones.
This can be used to force the radio to un-mute
only for radio traffic broadcasting the same
codes squelch signal. Also needed sometimes
to operate with Conventional repeaters.
Double click here to enter a text description for
this system (as described on page 13). You can
enter up to 10 characters for this field.
Select "High" or "Low". Specify if you wish to
transmit using high or low power by default on
this system. Can be toggled with the TX Power
key.
Set to "OFF" (manually type the word in) or
enter from 0 to 255 seconds. Setting this
prevents the radio from transmitting for a
period longer than this timer.
Select "Busy Lockout" or "Off". When set to
"Busy Lockout" the radio cannot transmit
while there is activity on the receive frequency
for this system.
Default
Off (Blank)
High
(Blank)
OFF
OFF
(Blank)
Conv. Programming Screen
(rev 1.0) -
Suggested
Settings
Set as
needed.
When
working with
Conventional
Repeaters,
consult the
system
operator.
Mandatory
field - set as
needed. You
cannot enter
any other
information
on this row
until this field
has been
filled in.
Set as
needed.
Set as
needed.
Set as
needed.
40
