DTMF ENCODE PROGRAMMING SCREEN

DTMF E P
NCODE
This programming screen allows the programmer to create, read, edit and delete all
global DTMF encode entries. If a Send DTMF key has been pressed, the entries from
this list appear for the operator to choose from to send the selected pre-programmed
DTMF sequence for whatever interconnect or system needs. Also these entries can be
used as auto-responses in the "Response" fields of the DTMF Decode programming
screen.
Note that to delete a row, you can right click on almost any field in the programming
screen and select "Delete" from the menu that appears.
DTMF E
NCODE
Group Field
No.
Atr
Text
Timer PTT Delay
CS-F620TR Programming Software Manual
S
ROGRAMMING CREEN
P
ROGRAMMING
Description
The line number of the DTMF Encode entry.
You can have up to 10 entries here before
getting an overflow error.
Select "Emergency" or "Emergency OFF" (or
"Return" to exit without selecting a new
setting). Selecting "Emergency" sets this
system as the one to be used if the Emergency
key has been pressed. Note: changing this field
to Emergency will deselect any other DTMF
Encode row from being the Emergency entry.
Select "Emergency OFF" to clear this setting.
Double click here to enter a text description for
this entry (as described on page 13). You can
enter up to 10 characters for this field.
Enter from 0 to 32.767 (in seconds). Sets the
period of time between when the radio initiates
transmission of RF carrier and the sending the
DTMF sequence. Used to ensure the radio and
the receiving system are up and stable before
sending out the DTMF sequence.
I : Located in DTMF Autodial folder.
CON
S F D
CREEN IELD ESCRIPTION
DTMF Encode Programming Screen
(rev 1.0) -
T
ABLE
Default Suggested
Settings
No user No user
entry. entry.
Emergency Set as
Off (Blank) needed.
Blank Set as
needed.
.1 Set as
needed.
47
