12mm/16mm Expansion Bolts.
Recomended for suitable
Concrete Surfaces
M10 x 20 Cap Screw
316 Stainless Steel
Included with Umbrella
Nut and Washer to suit
Galvanized/316 SS
To Suit Expansion Bolts
Not Included
NB: It is the responsibility of the installer to ensure that any fixings used in the installation of the umbrella surface plate are suitable for the application
Mounting Option - Surface Plate - Concrete Install
Shadowspec Unity
UM-110312
Unity Rotation plate
UM - 110068
Unity Spigot
UM - 110114
UM - 110312
Surface plate - 316 Stainless Steel
12mm/16mm Expansion bolts
Galvanized/ 316 Stainless Steel
Minimum length 100mm
Not Included
