- Page 1 SHADOWSPEC SERENITY & UNITY™ HARDWIRE KIT INSTALLATION GUIDE P01/22 220v AC For Australia and New Zealand www.shadowspec.com...
- Page 2 The Hard Wire Base Kit comes with the above components. Please check your kit to ensure that it is complete. If you have a Shadowspec Serenity™ Umbrella, you will need one Base Kit per umbrella. If you have purchased a Shadowspec Unity™...
- Page 3 Additional Kits - Shadowspec Unity™ Additional Canopy Kit Kit Code Part Code Image Part Name Notes Suitable for one LED light. Shad- 12v DC to 9v UM - 510020 owspec LED lights are strictly 9V Converter UM - 510025 Crimp...
- Page 4 We do not recommend using the Hard Wire Kit where a portable base for the umbrella mount is used. • The Installation method is similar for both Shadowspec Unity™ and Shadowspec Serenity™ umbrellas. Tip: Always Label cables where possible. This makes it much easier to do installs and finding faults later.
- Page 5 Connection Point Information Wiring Diagram (1-4 Lights) Connection Point 2 / 3 Connection Point 4 12v AC/DC Adatptor Low Voltage Feed Cable Connection Point 1 Components for each Connection Point Connection Point 1 Connection Point 2 Connection Point 3 Note: 12v DC to 9v Converter is shared between Connection Point 1 &...
- Page 6 Umbrella from the Spigot. Feed the Feed Cable through the Wire Feed Hole on Run the Feed Cable through the Spigot and into and the Surface Plate and Spigot through the Mast. Tip: Shadowspec Serenity and Unity Spigots have the same wire path...
- Page 7 In-Ground Anchor Wire Installation If you are retrofitting the Hardwire Kit - Remove your Remove the Spirit Bubble from the top of your Spigot Umbrella from the Spigot. Spigot In-Ground Anchor Conduit with Feed Cable Feed the Feed Cable through the Wire Feed Hole on Install a conduate when you set the In-Ground Anchor the Surface Plate and Spigot to make feeding the cable easier.
- Page 8 Connection Point 1: 12v AC/DC Adapter • The 220V AC/DC Adaptor Input Plug should only be used with a fixed wall socket that was installed by a certified electrician. • Please use a wall socket that is mounted in a dry and protected area or a socket that has a rain proof lid. •...
- Page 9 Connection Point 1: 12v AC/DC Adapter 1. Strip the Feed Cable back about 15mm to expose 2. Twist tightly together with the 12v DC output the bare wires. wires from the included adaptor - please ensure to get the polarity correct. 3.
- Page 10 Connection Point 2: 12V DC Feed cable to 9V DC Converter...
- Page 11 Connection Point 2: 12V DC Feed cable to 9V DC Converter 1. Remove the Top Cap from the Mast. Remove Mast 2. Feed the 12v Feed Cable from the Spigot (See Fig 1.) through End Cap to the top of the Mast. 3.
- Page 12 Connection Point 3: 9v DC Output to Main Spar LED Wire 1. Locate the Main Spar LED Cable at the back of the Main Spar. 2. With care, pull the loose end out of the transport hole. 3. Connect the Red Wire from the 9v DC Output to the Red Wire of the LED Cable with Crimp Connector. 4.
- Page 13 Red wires must only be connected to red wire Important: Connecting any third-party power source to the LED light will void the warranty. Cable feed for Serenity example 6. Return the Connection Point 3 system to the inside of the top of the Mast.
- Page 14 • If you need to enquire about a warranty claim, please either contact Shadowspec direct or the sales agent you purchased your product from.
- Page 15 Contact our in-house shade and outdoor specialists for more information and advice. AUSTRALIA NEW ZEALAND UNITED STATES Australian Nest Heron Base North American Nest Atlanta, Georgia Laverton North, Victoria Whangarei, Northland 844 888 5577 1800 144 155 0800 144 155 www.shadowspec.com www.shadowspec.com.au www.shadowspec.co.nz...
