M10/M12 Countersunk Bolts
with Nyloc Nuts.
Recommended for Wooden Deck
installations
4x M10 x 20 Cap Screw
316 Stainless Steel
Included with Umbrella
4x M10 - M12 CSK Socket Screw
Length to match application
150mm - 200mm | 6'' - 8''
316 Stainless Steel
Not included
NB: It is the responsibility of the installer to ensure that any fixings used in the installation of the umbrella surface plate are suitable for the application
Mounting Option - Surface Plate - Wooden Deck Install
Shadowspec Unity
Unity Rotation plate
UM - 110068
Unity Spigot
UM - 110114
UM - 110312
Surface plate - 316 Stainless Steel
Nyloc Nut and Washer to suit
316 SS - Not Included
www.shadowspec.com
™
UM-110312
