Summary of Contents for Shadowspec SU7
- Page 1 ROTATING CANTILEVER UMBRELLA OWNERS MANUAL Installation, Operation, Care and Warranty www.shadowspec.com...
-
Page 2: Table Of Contents
Stage 3C - Fixing the Fabric Canopy to Umbrella Frame Stage 3D - Connecting the LED Lights (optional accessory) Stage 3E - Fitting the LED Light System (optional accessory) Stage 4 - Operating the Umbrella SECTION 2 - Umbrella Care & Maintenance SECTION 3 - Warranty www.shadowspec.com... -
Page 3: Section 1 - Assembly, Installation & Operation
Ensure that the location you have chosen has the umbrella in a position where it provides the best possible coverage over the area that you want shaded. Remember the SU7 has the ability to rotate 360° so if you wish to utilise this function ensure that you allow the necessary space around the umbrella for this. - Page 4 Distance from ground to central frame hub (cm) +/- 78 +/- 42 +/- 78 +/- 42 g: Overall height of umbrella to top of mast cap (cm) +/- 276 +/- 276 +/- 276 +/- 276 Refer plan diagrams in table. www.shadowspec.com...
-
Page 5: Stage 2 Installation Of The Umbrella Fixing
STAGE 2 Installation of the Umbrella Fixing IMPORTANT TIP! On the base plate of the mast support there is a small protruding nipple (see Figure 2) which acts as a stopper, preventing the umbrella mast from rotating past a 300° radius. Should your umbrella be fitted with the optional LED light, this nipple is a necessary feature to prevent the electrical cable housed inside the mast from becoming twisted. -
Page 6: Option 2 - In-Ground Anchor Fixing
• Hex Allen key set • The complete In-ground Anchor kit (see Figure 3). Figure 3 - In-Ground Anchor kit for SU7 Umbrella* Rotational Locking Pin (x1) Rotating Platform (x1) Rotating Stopper Nipple (x1) M8 20mm Screws (x4) Main mast support spigot (x1) Main mast support foot (x2) 4.2mm x 32mm Screws (x2) - Page 7 Before leaving the concrete to cure re-check the fi tting to ensure that it is level/perpendicular. Step 7 Once the concrete is fully cured, the umbrella mast can be placed onto the Main Support Spigot (E). Figure 4 - In-Ground Anchor installation & suggested specifi cations for SU7 Umbrella 220mm 220mm 500mm...
-
Page 8: Option 3 - Surface Plate Fixing
2x adjustable spanner/wrench • The complete Surface Plate Anchor kit (see Figure 5). Figure 5 - Surface Plate Anchor kit for SU7 Umbrella Spigot (x1) Rotating Platform (x1) Rotational Locking Pin (x1) Spigot Mounting Bolts (provided) Surcafe Plate Fixing (x1) NOTE: Bolts for fixing to surface not supplied... - Page 9 Figure 6 - Securing SU7 Surface Plate Fixing to wooden deck (suggestion only) Spigot 10mmØ bolts running right through and fastened with a Spigot bolts Surface Plate Fixing. washer and nut. (provided) (not supplied) NOTE: Washer between Timber decking. surface plate and decking.
-
Page 10: Option 4 - Wall Anchor Fixing
2x adjustable spanner/wrench • The two Wall Anchor Fixing brackets (see Figure 8). Figure 8 - Wall Fixing Anchor brackets for SU7 Umbrella Wall Anchor Fixing Bracket (x2) NOTE: Fasteners for fi xing bracket to wall not included Bottom Step1 Choose your site carefully –... - Page 11 The Umbrella mast should now be mounted to the wall held between the two Wall Anchor brackets. It cannot be removed without fi rst removing one of the brackets from the wall. Figure 9 - SU7 Wall Anchor Fixing Installation...
-
Page 12: Stage 3 - Assembling & Mounting The Umbrella
3B) MOUNTING THE UMBRELLA: (Note Steps 8 and 9 apply only to the In-ground Anchor or Surface Plate Fixings (not applicable to the Wall Anchor Fixing). At this point you will also need: • Another person (recommended) • A step ladder www.shadowspec.com... - Page 13 Step 10 Attach the gas strut ensuring that it is positioned the correct way up as shown. Step 11 Once the gas strut is secure the screw stopper can be inserted in place. Figure 10 - SU7 Parts kit - small parts identifi cation list Axle nut (x4) Main axle (x2)
- Page 14 Figure 11 - SU7 Assembly, step by step attaching umbrella to mast (NOTE: If your umbrella has a Surface Plate, In-ground Anchor or Portable base fi xing please skip Step No.2) NOTE: This step applies to a Note: Bolts should be only loosely tightened in this step Wall Mount fi...
- Page 15 10+11 Upper Frame Hub Fabric Canopy Cap Screw stopper (part N) inserts here. Hole is located approx 500mm below top of mast inside trolley track...
-
Page 16: Stage 3C - Fixing The Fabric Canopy To Umbrella Frame
(refer Fig 11, Step 5). Bolt the fabric canopy cap fi rmly in position over the top of the fabric, as shown below. www.shadowspec.com... -
Page 17: Stage 3D - Connecting The Led Lights (Optional Accessory)
3D) CONNECTING THE LED LIGHT (optional accessory): The LED Lights which are an optional accessory off ered for the SU7 Umbrella are fi tted to the centre lower hub of the umbrella at the time of manufacture (see Figure 12). -
Page 18: Stage 3E - Fitting The Led Light System (Optional Accessory)
3E) FITTING THE LED LIGHT SYSTEM (Optional Accessory) 2. MOUNTING LED KIT SU7 110V 2.1. Mounting the 110 V power cable STEP 1 The power cable can be put into the provided channel behind the pole or into the central part of the pole. - Page 19 40W Transformer included Power supply 100-277V~ Max power output Operating temperature range t.a. 50°C Protection: short circuit, overload and overheating The product is exclusively designed for LED loads...
-
Page 20: Stage 4 Operating The Umbrella
(clockwise) once again. For more information on how to operate your umbrella please visit our website and view the SU7 product demonstration video. You can view these videos at any time by visiting www.shadowspec.com/videos... -
Page 21: Section 2 - Umbrella Care & Maintenance
Sunbrella and Dickson-Constant acrylic fabrics, along with other proven high-performance, UV stable materials. SHADOWSPEC Umbrella canopies should be cleaned regularly before dirt is allowed to accumulate and become embedded in the fabric. The fabric canopy can be cleaned without being removed from the frame, however, the canopy can be completely removed from the frame if preferred. -
Page 22: Section 3 - Warranty
• Repair costs by a third party. To avoid possible wind damage, it is recommended that your SU7 umbrella be closed in wind gusts exceeding 40km/h. This is subject to the umbrella being sufficiently anchored. This warranty does protect against the umbrella canopy fabric becoming unserviceable due to strength loss from normal usage and exposure conditions. - Page 24 Contact our in-house shade and outdoor specialists for more information and advice. AUSTRALIA NEW ZEALAND UNITED STATES North American Nest Australian Nest Heron Base Atlanta, Georgia Laverton North, Victoria Whangarei, Northland 844 888 5577 1800 144 155 0800 144 155 www.shadowspec.com www.shadowspec.com.au www.shadowspec.co.nz...
