- Page 1 SHADOWSPEC UNITY ™ THE EVOLUTION OF SHADE BEST-IN-CLASS WARRANTY Trusted for Fabric Frame Hand built in Marine 10 YEAR 6 YEAR Warranty Warranty over 25 years New Zealand Grade *Conditions apply. 3 year warranty for commercial applications.
- Page 2 SHADOWSPEC UNITY™ THE EVOLUTION OF SHADE PATENT-PENDING TECHNOLOGY SHADOWGLIDE™ SHADOWLIFT™ Gas-assisted deployment for an easy lift. Engineered to open or close in 3 seconds. SHADOWHUB™ SHADOWLOCK™ LED light technology built-in and App controlled. Integrated security and wind-protection. Featuring Marine-Grade 316 Stainless Steel Spigot.
- Page 3 Canopy Features Stock Colours Trend Colours - Summer 20/21* (Non-stock) • 100% Sunbrella™ Marine solution-dyed fabric • All fabrics can be cleaned, washed and are replaceable • UV & fade resistant • 10 year Sunbrella™ warranty Oyster Cadet Grey Natural Charcoal Grey Rust Silver...
- Page 4 Umbrella Dimensions 2.5m | 8’2’’ 3.0m | 9’10’’ 3.5m | 11’6’’ 4.0m | 13’2’’ Diagram Legend 2.5m 8'2'' 3.0m 9'10'' 3.5m 11'6'' 4.0m 13'2'' Ground to central frame hub when closed* 872mm 2'10'' 632mm 2'1'' 1091mm 3'7'' 879mm 2'11'' Height of umbrella to top of mast cap* 2920mm 9'7'' 2920mm...
- Page 5 Resources for Architects, Designers & Specifiers These resources include 2D & 3D files, CAD Resources and Spec Sheets for all the product range. https://www.shadowspec.com/cad...
- Page 6 Shadowspec Unity ™ Mounting Option - Surface Plate - Chemical Anchor UM-110312 M10/M12 Countersunk Barrel Nut with Unity Rotation plate Threaded Rod. Recomended for Chemical UM - 110068 Anchor systems or where non standard thread length are required. Unity Spigot...
- Page 7 Shadowspec Unity ™ Mounting Option - Surface Plate - Concrete Install UM-110312 12mm/16mm Expansion Bolts. Recomended for suitable Concrete Surfaces Unity Rotation plate UM - 110068 Unity Spigot UM - 110114 M10 x 20 Cap Screw 316 Stainless Steel Included with Umbrella...
- Page 8 - 20kg | 44 lb 1.5 oz weight - Allows 360o umbrella rotation - Ships in one box - Suits Shadowspec Serenity™ & Unity™ models - Full instruction and install guide provided - Adjustable Feet to level the base up to 50mm | 2’’...
- Page 9 - 7kg | 15lb 7oz weight - Allows 360o umbrella rotation - Ships in one box - Suits Shadowspec Serenity™ & Unity™ models - Full instruction and install guide provided All sizings are +/- 2.5mm | 3/32’’ and subject to change without notice.
- Page 10 Shadowspec Unity ™ Umbrella Dimensions Codes: UM - 010031 | UM - 010033 | UM - 010035 | UM - 010037 2.5m | 8’2’’ 3.0m | 9’10’’ 3.5m | 11’6’’ 4.0m | 13’2’’ Diagram Legend 2.5m 8'2'' 3.0m 9'10'' 3.5m 11'6'' 4.0m...
- Page 11 - 6.9kg | 15lb 3oz weight - Allows 360o umbrella rotation - Ships in one box - Suits Shadowspec Serenity™ & Unity™ models - Full instruction and install guide provided All sizings are +/- 2.5mm | 3/32’’ and subject to change without notice.
- Page 12 Shadowspec Unity ™ Mounting Option - Surface Plate - Wooden Deck Install UM-110312 M10/M12 Countersunk Bolts Unity Rotation plate with Nyloc Nuts. UM - 110068 Recommended for Wooden Deck installations Unity Spigot UM - 110114 4x M10 x 20 Cap Screw...
- Page 13 SHADOWSPEC UNITY ™ MULTI CANOPY CANTILEVER UMBRELLA P02/20 OWNERS MANUAL Installation, Operation, Care and Warranty SHADOWLIFT™ SHADOWGLIDE™ SHADOWLOCK™ SHADOWHUB www.shadowspec.com...
- Page 14 Read your manual in full before assembling your umbrella. To extend the life of your umbrella investment please read and follow the care instructions on a regular basis. Thank you for your purchase, we appreciate it. Enjoy the shade, courtesy of Shadowspec.
-
Page 15: Table Of Contents
CONTENTS Page SECTION 1 - WARRANTY Product Registration and Warranty Validation SECTION 2 - UMBRELLA CARE AND MAINTENANCE SECTION 3 - ASSEMBLY, INSTALLATION AND OPERATION STAGE 1 Umbrella Location - Planning Your Umbrella Location STAGE 2 Naming and Checking Your Umbrella Parts STAGE 3 Installation of Your Umbrella Mount Option 1 - Freestanding Base Option 2 - In-Ground Anchor... -
Page 16: Section 1 - Warranty
Except as expressly provided herein, all other warranties, representations, conditions, undertakings, rights, duties or liabilities, whether arising by implication of law or otherwise, are hereby expressly excluded. If you need to enquire about a warranty claim, please either contact Shadowspec direct or the sales agent you purchased your Unity from. -
Page 17: Product Registration And Warranty Validation
Shadowspec Fabric Canopies are manufactured from the most durable marine fabrics, thread and designs available. Shadowspec Fabric Canopies should be cleaned on a regular basis so dirt isn’t allowed to build-up and become embedded in the fabric. You can clean your Fabric Canopy without removing it from the Frame if you prefer, or it’s as easy to remove as it was to put on. -
Page 18: Section 3 - Assembly, Installation And Operation
*Freestanding Base installations will add 165mm to these measurements. Adding Freestanding Base wheels also will add a further 45-80mm/2-3’’. All sizings are +/- 2.5mm / 3/32’’ and subject to change without notice. NOTE: For the Unity Duo, Trio and Quattro the gap between adjoining umbrellas is 150mm / 6” www.shadowspec.com... -
Page 19: Stage 2 Naming And Checking Your Umbrella Parts
When unpacking your Unity umbrella please check you have all the correct parts pictured below before beginning the assembly. If any parts are missing please contact support@shadowspec.com to create a ticket to resolve. You will need to refer back to this page so why not earmark it for quick reference whilst you’re assembling your umbrella. -
Page 20: Stage 3 Installation Of Your Umbrella Mount
Step 6 Place the Freestanding Base in the desired location. Step 7 Insert the 12 pavers for ballast then slide the base cover over top. Step 8 Slide your Rotation Plate over the Spigot and move on to Stage 4. www.shadowspec.com... -
Page 21: Option 2 - In-Ground Anchor
Figure 6 - Freestanding Base Parts Unity Spigot Unity Spigot Base Frame Rotation Plate Pavers NOTE: 12 Pavers stacked in 3 layers. Pavers are not supplied. Threaded Feet Base Cover Unity Screws* Serenity Screws* Nuts Optional Wheels / Castors *Both Serenity and Unity Screws are included in box. Only use the set required for your Unity (Serenity Screws will be surplus). OPTION 2 - IN-GROUND ANCHOR For installation you will require:... -
Page 22: Option 3 - Surface Plate
Concrete Slab: Recommended minimum depth of 100mm / 4” (reinforced) - See Figure 11. It’s also recommended to use washers to space the plate on the decking to allow water to escape to minimise water damage to the deck. Figure 9 - Surface Plate Unity Spigot Surface Plate Rotation Plate Surface Plate Bolts www.shadowspec.com... - Page 23 Step 6 Drill pilot holes on the marks and check that the pilots are in the right place by laying the Surface Plate over the top of them, and then if correct, drill the proper holes. Step 7 Use your bolts to secure the Surface Plate and Spigot to the chosen spot. Step 8 Slide your Rotation Plate over the Spigot and move on to Stage 4.
-
Page 24: Option 4 - Wall Base Bracket
Drill holes ensuring that they are parallel to each other and secure the Wall Mount bracket to the wall. Step 7 Slide your Rotation Plate over the Spigot and move on to Stage 4. Figure 12 - Wall Base Bracket Unity Spigot Wall Mount Rotation Plate Figure 8 NOTE: Refer to Spigot orientation diagram - www.shadowspec.com... -
Page 25: Stage 4 Assembling And Mounting Your Umbrella(S)
4A) ASSEMBLING YOUR UMBRELLA: Shadowspec Unity comes partially assembled which is great! If you have a Duo, Trio or Quattro you’ll need to attach a few things to the Mast to add your additional Frames. Remove the pre-assembled Unity umbrella from your box packaging and make sure you place it somewhere where the surface of your umbrella parts won’t get scuffed or... -
Page 26: Stage 4B - Mounting Your Umbrella(S)
Step 14 Together now, lift the Unity Umbrella up and manoeuvre it over the Spigot so the base of the Mast is positioned over the top of the Spigot. Note: Remember to lightly grease the spigot with the supplied grease. www.shadowspec.com... - Page 27 Step 15 With care, lower the Mast down onto the Spigot and push it into the correct grooves of the Rotation Plate. Step 16 Lift the Rotation Lock Lever and tighten the security screw all the way. You now should not be able to lift the Umbrella off the Spigot.
-
Page 28: Stage 4C - Fabric Canopy Installation
Lift the Shadowglide Carriage to the top, slowly, to test the tension of the Fabric Canopy. See Figure 18 tension adjustability options for the Fabric Canopy. Step 7 Repeat for each Additional Frame (2-4). TIP: Reposition the bottom velcro strip if needed so it is perfectly symmetrical onto the Through-Spar. www.shadowspec.com... -
Page 29: Stage 5 Operating Your Umbrella
STAGE 5 OPERATING YOUR UMBRELLA Your Shadowspec Unity is engineered to be easy to use. Squeeze the Shadowglide Button to release the Carriage from its closed position and push it up the Mast until it locks in place. Step 1 To open your umbrella, push down onto the Shadowglide Button located in the Shadowglide Handle and assist the opening by pushing the Carriage with the with the palm of your hand upwards until it locks into place. -
Page 30: Section 4 - Accessories
The SS-1 Smart Battery allows the user to control the LED Light via any Android mobile device using the Shadowspec App or operate the LED Light using the manual on/off button located on the end of the SS-1 Smart Battery itself. - Page 31 RECHARGEABLE SMART BATTERY CARE AND RULES FOR USE • Only use the Shadowspec Charging Adapter to charge the Shadowspec SS-1 Bluetooth LED Smart Battery. • Please charge your SS-1 Smart Battery completely before the very first time it is used.
- Page 32 Contact our in-house shade and outdoor specialists for more information and advice. AUSTRALIA NEW ZEALAND UNITED STATES Australian Nest Heron Base North American Nest Atlanta, Georgia Laverton North, Victoria Whangarei, Northland 844 888 5577 1800 144 155 0800 144 155 www.shadowspec.com www.shadowspec.com.au www.shadowspec.co.nz...
