- Page 1 Shadowspec ™ RETREAT The Wall Mounted Umbrella INSTALLATION GUIDE Operation, Care and Warranty www.shadowspec.com P01/22...
- Page 2 Shadowspec Retreat™ Dimensions 2700mm / 8’10’’ 2340mm / 7’8’’ Recommended Installation Height 310mm/1’ 440mm/1’5’’ 1210mm/4’ Shadowspec Retreat™...
- Page 3 This document contains all the information you need to install your Shadowspec Retreat™ Thank you for your purchase, we appreciate it. Enjoy the shade, courtesy of Shadowspec. What’s in the Box? Retreat Arm Assembly C-Clip Spring Cup...
-
Page 4: Wall Mount Bracket Installation
Wall Mount Bracket Installation 1. Install the Top Wall Bracket Choose a wall, pillar or post that is strong enough to mount the Retreat Choose a 316 Stainless Steel Fastener that matches your structure. Fig. A. iii: Using the Top Wall Bracket as a guide, mark holes on your wall at the desired height. - Page 5 Fig. H Fig. I Fig. J vii. Lower Retreat Arm and push the Spring Cup Up to align with the marks on the Wall Mount. Fig. K. viii: Fully tighten the Spring Cup Bolt with supplied Hex Wrench. Fig. L.
- Page 6 Shadowspec Retreat™ Installation 5. Fit the Canopy Frame Pull the Claw Latch Lever to open it. Fig. N / Fig. O. The Grab Latch will detach from the Bracket Fig. P / Fig. Q. iii. Insert the Canopy Frame into the Claw Bracket Fig.
- Page 7 Fig. R Fig. S Fig. Q Fig. P (Reversed) (Reversed) Fig. O Fig. N (Reversed) (Reversed) www.shadowspec.com...
- Page 8 Shadowspec Retreat™ Canopy Fitting 6. Fit Fabric Canopy 1: Pull the Shoulder Locking Pin. Fig. T: 2. Push downward the until it locks in the angled position. Fig. U. Tip: Take care as the Gas Spring will require some force to compress and the arm may swing up before it locks into place.
