Shadowspec UNITY Square Uno Manual page 4

Umbrella Dimensions
B
A
F
G
2.5m | 8'2''
Diagram Legend
A
Ground to central frame hub when closed*
B
Height of umbrella to top of mast cap*
C
Total height to top of canopy*
D
Ground to central frame hub when open*
E
Ground to lower outer edge of canopy*
F
Centre of mast to outside edge of canopy
G
Diagonal from centre of mast to corner
*Free-Standing Base installations will add 165mm | 6'' to the height and surface plates will add 12mm | 1/2'' to the height. Adding Free-Standing base wheels also
will add a further 45-80mm | 2-3''. All sizings are +/- 2.5mm | 3/32'' and subject to change without notice.
C
F
G
3.0m | 9'10''
2.5m
872mm
2920mm
2913mm
2143mm
2235mm
2640mm
3734mm
D
F
3.5m | 11'6''
8'2'' 3.0m 9'10''
2'10'' 632mm 2'1''
9'7'' 2920mm 9'7''
9'7'' 2837mm 9'4''
7'0'' 2066mm 6'9''
7'4'' 2233mm 7'4''
8'8'' 2967mm 9'9''
12'3'' 4197mm 13'9''
F
4.0m | 13'2''
3.5m 11'6'' 4.0m
1091mm 3'7'' 879mm
2920mm 9'7'' 2920mm
2988mm 9'10'' 2912mm
2218mm 7'3'' 2141mm
2245mm 7'4'' 2185mm
3438mm 11'3'' 3910mm
N/A N/A N/A
E
13'2''
2'11''
9'7''
9'7''
7'1''
7'2''
12'10''
N/A
