Shadowspec UNITY Square Uno Manual page 10

C
B
A
F
G
2.5m | 8'2''
Diagram Legend
A
Ground to central frame hub when closed*
B
Total height to top of canopy*
C
Height of umbrella to top of mast cap*
D
Ground to central frame hub when open*
E
Ground to lower outer edge of canopy*
F
Centre of mast to outside edge of canopy
G
Diagonal from centre of mast to corner
*Portable Base installations will add 165mm | 6'' to the height & surface plates will add 12mm | 1/2'' to the height
Adding portable base wheels also will add a further 45-80mm | 2-3''. All sizings are +/- 2.5mm | 3/32'' and subject to change without notice.
Codes: UM - 010031 | UM - 010033 | UM - 010035 | UM - 010037
D
F
G
3.0m | 9'10''
2.5m 8'2''
872mm 2'10''
2913mm 9'7''
2920mm 9'7''
2143mm 7'0''
2235mm 7'4''
2640mm 8'8''
3734mm 12'3''
Umbrella Dimensions
F
3.5m | 11'6''
3.0m 9'10'' 3.5m
632mm 2'1'' 1091mm
2837mm 9'4'' 2988mm
2920mm 9'7'' 2920mm
2066mm 6'9'' 2218mm
2233mm 7'4'' 2245mm
2967mm 9'9'' 3438mm
4197mm 13'9'' N/A
Shadowspec Unity
E
F
4.0m | 13'2''
11'6'' 4.0m 13'2''
3'7'' 879mm 2'11''
9'10'' 2912mm 9'7''
9'7'' 2920mm 9'7''
7'3'' 2141mm 7'1''
7'4'' 2185mm 7'2''
11'3'' 3910mm 12'10''
N/A N/A N/A
™
