Product Image - Ruijie RG-AP820-L(V2) Series Hardware Installation And Reference Manual

Dimensions
(W x D x H)
Weight
Service Ports
Management Ports
Button
Anti-Theft Lock
LED
Power Supply
Power Consumption
Bluetooth
Temperature
Humidity
Installation
IP Rating
Safety Standards
EMC Standards
Vibration Standards
Radio
MTBF
The weight refers to the weight of host and bracket.

1.2 Product Image

The AP provides one Ethernet ports (PoE-capable), one Console port, and one power port for external power supply.
Figure 1-1 Appearance of RG-AP820-L(V2)
193 mm x153 mm x 26 mm
(7.60 in x 6.02 in x 1.02 in)
≤ 1 kg (2.20 lbs)
One 10/100/1000BASE-T Ethernet port (802.3af PoE-capable)
One RJ45 Console port supports 9600bps, 57600bps and 115200bps.
One Reset button
Support
1 LED (red, green, blue, orange, and flashing modes, flashing mode for smart device access,
and the indicator can be switched off to silent mode)
Adapter: DC 48V/0.3A (optional)
PoE: IEEE 802.3af
Maximum: 12.95W
Bluetooth 5.0 (BLE)
Operating: -10° C to 50° C (14° F to 122° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Operating: 5% to 95% RH (non-condensing)
Storage: 5% to 95% RH (non-condensing)
Ceiling/wall mount
IP41
GB4943-2011
IEC60950-1
IEC60825-1
EN300386
GB19286-2003
GB17618-1998
NEBS GR-63-CORE_Issue3_2006
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
> 200,000H
·
