3. Click to highlight the partition
The Add or Modify Hard Partition screen displays (Figure 4–16).
4. Do one of the following:
•
Select a QBB in the block labeled Available system resources to add it to
the partition specified in the title bar; click Add, or
•
Select a QBB in the block labeled Resources assigned to this partition to
remove it from the partition; click Remove. The partition information
for the QBB changes to Unassigned.
5. Specify the operating system for the partition in the OS type dropdown list,
and, optionally, supply a name for the partition in the name block. You
must enter the name in capital letters, and it cannot match a console name,
group name, or alias in ConsoleWorks (it must be unique). Click OK. The
Create or Modify a Partition Map screen returns.
6. Repeat steps 3 through 5 to modify other partitions.
NOTE: A QBB can be assigned to only one partition at a time.
Figure 4–16 Add or Modify Hard Partition Screen
2
Any hard partition that is running an operating system is grayed out. The QBBs in
this partition are also grayed out and cannot be assigned.
2
to be modified, and click the Modify button.
Compaq AlphaServer Partition Manager 4-23
