Figure 4–5 shows the Current Partition Map screen with the Partition Map
option button selected. This selection provides partition information about the
GS80/160/320 system in the form of a table. (See page 4-10 for the screen with
the System Information button selected.)
The parts of the display are described here.
Partition – A number from 1 to the number of quad building blocks (QBB) in
the system (maximum 8). If the system has already been partitioned, with
either CAPM or console commands, and this partitioning is still in effect, that
partitioning information is displayed here.
NOTE: Partition numbering in CAPM differs from partition numbering
shown in the output of console commands.
Name – The name of the hard partition's console in ConsoleWorks.
OS Status – Running if an operating system is running in this partition; Not
Running if the SRM firmware is running; Powered Off if the partition is
powered off; Faulted if there is a fault.
OS Type – The operating system for this partition. This is set in the Add or
Modify Hard Partition screen and can be Tru64 UNIX, OpenVMS, OpenVMS
Galaxy, or Unknown.
QBBs – The hard QBB number of each QBB in this partition.
CPUs – The number of CPUs found by CAPM in the partition during the
discovery process. This may include faulted CPUs.
Memory – The amount of memory (in megabytes) found by CAPM in the
partition during the discovery process. If an operating system is running, this
might display as Unknown or show the memory discovered the last time CAPM
was run.
Soft Partitions – The number of soft partitions in this hard partition.
Details – Click this button for additional information about the system, as
shown in Figure 4–7.
You can resize the columns in the display by clicking on a divider between
columns and dragging. Roll the mouse over a button at the bottom of the screen
to see a description of it in the block above the buttons.
Continued on page 4-10
