Front Panel Description; Figure 3-1: Front Panel; Table 3-2: Front Panel Description - AudioCodes i Series Hardware Installation Manual

3.2

Front Panel Description

The front panel provides LEDs for indicating the status of various functionalities. The LEDs
are shown in the figure below and described in the subsequent table.
Note:
The figure above is used only as an example. Available LEDs depend on the
ordered hardware configuration.
Item # LED Label
Power
1
2 Status
Hardware Installation Manual

Figure 3-1: Front Panel

Table 3-2: Front Panel Description

Indicates the status of the power supply to the device. For more
information, see Section
Indicates the operating status of the device. For more information,
see Section 3.2.1.2 on page 13.
12
Description
3.2.1.1 on page 13.
Document #: LTRT-10605
Mediant 500Li
