3.2.1.3

Wi-Fi LED

The Wi-Fi LED indicates the Wi-Fi link status, as described in the table below.
LED Color
Green
-
3.2.1.4

WAN LEDs

This section describes the WAN LEDs.
3.2.1.4.1 WAN 4G LED
The WAN 4G LED indicates the status of the cellular WAN link (4G LTE or 3G), as described
in the table below.
LED
Color
Green
Red
-
3.2.1.4.2 WAN GE LED
The WAN GE LED indicates the status of the Gigabit Ethernet over Copper WAN link, as
described in the table below.
LED Color LED State
Green On
Flashing
- Off
Hardware Installation Manual

Table 3-5: Wi-Fi LED Description

LED State
On Wi-Fi is activated.
Flashing Traffic on the wireless LAN.
Off Wi-Fi is not configured.

Table 3-6: WAN 4G LED Description

LED
State
On Connected to the cellular network.
Flashing In the process of connecting to the cellular network.
On No SIM card in the SIM slot, or if there is a SIM card, the device
cannot connect to the cellular network.
Off Cellular WAN interface has not been configured (or the
functionality is not included in the device's installed License Key).

Table 3-7: WAN GE LED Description

WAN GE link established.
Data is being received or transmitted.
No WAN GE link or power not received by the device.
Description
Description
Description
