24.3

Laser unit sideways (Art. No. SA-SM-LASER-SIDE)

Figure 114: Laser unit sideways
Figure 115: Laser unit sideways: used for setup
Expert tip:
The laser can be precisely aligned if, for example, a mark has previously been milled into the work-
piece with a V-groove cutter.
The laser unit sideways is intended to assist
you in aligning the milling tool position in the
longitudinal direction (Y-axis).
The laser unit sideways is batterie-operated.
It can be switched on and off.
Routing and drilling device
81
