24.1 SlabMatrix Pro 1.0: Longitudinal rails for extending the Y-axis
(Art. No. SA-SM-EXT-KIT)
Figure 108: Set of longitudinal rails for extending the
Y-axis
Figure 109: Routing and milling device with extended
Y-axis
Routing and drilling device
The extension set longitudinal rails ex-
tends the machining length of the Y-
axis to 230 cm.
It is available for mounting on the
worktable and (in the version shown)
on the hole matrix board.
The extended Y-axis enables the ma-
chining of workpieces up to a length of
230 cm.
79
