- Page 1 Sauter GmbH Ziegelei 1 Tel.: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.sauter.eu Data sheet / User manual SAUTER CJ X467 / CJ X468 V. 1.0 11/2020 CJ X467-CJ X468-BA-e-2010.docx...
- Page 2 SAUTER CJ X467 / CJ X468 V. 1.0 11/2020 Data sheet / User manual Summarize: Introduction ....................3 Warnings ......................3 Brief description .................... 3 Available models.................... 3 Dimensions ....................4 CJ X467 ............................4 CJ X468 ............................4 Electrical connection ..................5 Cable diameter ..........................
- Page 3 After receipt of the measuring cell, it should be checked in advance to ensure that no transport damage has occurred, that the repackaging or other parts or even the article itself have not been damaged. If any damage is evident, please notify SAUTER GmbH immediately.
- Page 4 5 Dimensions 5.1 CJ X467 (1) Cable gland load cell (2) Mounting bracket (3) Screw (4) Seal Screw (5) Cable bushing Evaluation unit (6) Pressure relief valve 5.2 CJ X468 CJ X467-CJ X468-BA-e-2010.docx...
- Page 5 Supply - + SIG Signal + - SIG Signal - + SEN * Probe + - SEN * probe - SHIE Screen Table 1: Connection of load cells and evaluation units (* only for connection to evaluation unit) CJ X467-CJ X468-BA-e-2010.docx...
- Page 6 If a 6-wire measuring cell is to be connected to a 4-wire connection block, the sensor wires and the supply line must be connected together as shown in the following figure (EXC+ and SEN+ as well as EXC- and SEN-). 6.4 Grounding 7 Adjusting the balance Potis for corner adjustment CJ X467-CJ X468-BA-e-2010.docx...
- Page 7 Use a load cell simulator to check if the evaluation unit works without errors and displays stable values. 9 Declaration of conformity To view the CE declaration, please click on the following link: https://www.kern-sohn.com/shop/de/DOWNLOADS/ CJ X467-CJ X468-BA-e-2010.docx...
