Technical specifications 1.1 Appearance The ISCOM6860 is an xPON integrated Optical Line Terminal (OLT) device. It provides data, voice, and video service access of large capacity, high speed, and high bandwidth, which fully meets carriers' requirements on establishing xPON networks with large capacity and few offices.
1 Product overview 1.2 Structure The ISCOM6860 adopts a chassis+card modular design, which helps users select the number and type of uplink/downlink cards freely according to the network scale. In addition, the ISCOM6860 supports network expansion based on redundant slots and service expansion based on new service cards.
ISCOM6860 (A) Hardware Description 1 Product overview Figure 1-3 Slot distribution of ISCOM6860 1.4 Capacity distribution Figure 1-4 shows capacity distribution of the ISCOM6860. Figure 1-4 Capacity distribution of ISCOM6860 1.5 Technical specifications Table 1-1 lists technical specifications of the ISCOM6860.
Raisecom ISCOM6860 (A) Hardware Description 1 Product overview Table 1-1 Technical specifications Hardware feature Description Dimensions 443 mm (Width) × 237 mm (Depth) × 266 mm (Height) (6U) Components such as panel, screws, and brackets are not counted in the dimensions.
LEDs Technical specifications 2.1 Features The FANS381 is a fan module of the ISCOM6860 and its main features are as below: Provide 6 embedded fans, offering better heat dissipation for cards in the chassis. Provide an alarm LED and an operating status LED on the front panel. These two LEDs monitor fan status in real time.
Raisecom ISCOM6860 (A) Hardware Description 2 Fan 2.3 LEDs There are 2 LEDs on the front panel of the FANS381. Table 2-1 lists descriptions of the 2 LEDs. Table 2-1 FANS381 LED Status Description Green Power supply LED Green: the power supply is working properly.
XP4L card RPD2151 card 3.1 Overview 3.1.1 Appearance and dimensions The types, appearance, and dimensions of the ISCOM6860 cards are different, as shown in Table 3-1. Table 3-1 Types, appearance, and dimensions of ISCOM6860 cards Dimension (Width × Type Appearance Depth ×...
Definitions of width, depth, and height are shown in the right figure. Height and width define the dimensions of a card while depth defines the depth of the PCB. 3.1.2 Card types Table 3-2 describes types of cards supported by the ISCOM6860. Table 3-2 ISCOM6860 card types Type Name...
The hardware information label of a card should be pasted in a visible place, facilitating users viewing it. Figure 3-1 shows the hardware information label of card supported by the ISCOM6860. Figure 3-1 Hardware information label of card supported by ISCOM6860 Raisecom Technology Co., Ltd.
Support 1 + 1 redundancy backup. Card protection Support hot swapping. 3.2.2 Panel and slots The SMCA card can be inserted into the following slots of the ISCOM6860 chassis. Slot 1 Slot 2 Figure 3-2 shows appearance of the SMCA card.
Raisecom ISCOM6860 (A) Hardware Description 3 Cards 3.2.4 LEDs There are 5 LEDs on the SMCA card. Table 3-8 lists descriptions of these LEDs. Table 3-8 LEDs on SMCA card Number Status Description SYS/ALM Green System working status LED ...
72 W 3.3 EP16 card 3.3.1 Features The EP16 card is an EPON service card inserted in the ISCOM6860 chassis. Each card provides 16 SFP PON interfaces which are placed at a 30-degree angle. Table 3-10 lists features of EP16 card.
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Figure 3-3 Appearance of EP16 card 3.3.3 Interfaces There are 16 interfaces on the EP16 card. Table 3-11 describes these interfaces. Table 3-11 Interface of EP16 card Name Type Purpose Description Service downlink 1–16...
3.4 GP8A card 3.4.1 Features The GP8A card is a GPON service card inserted in the ISCOM6860 chassis. Each card provides 8 SFP GPON interfaces with SFP placed at a 30-degree angle. Table 3-14 lists features of the GP8A card.
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Figure 3-4 Appearance of GP8A card 3.4.3 Interfaces There are 8 interfaces on the GP8A card. Table 3-15 describes the interface type and usage. Table 3-15 Interface of GP8A card Name Type Usage Description 1–8...
3.5 GP16 card 3.5.1 Features The GP16 card is a GPON service card inserted in the ISCOM6860 chassis. Each card provides 16 SFP GPON interfaces with SFP placed at a 30-degree angle. Table 3-18 lists features of the GP16 card.
Raisecom ISCOM6860 (A) Hardware Description 3 Cards 3.5.3 Interfaces There are 16 interfaces on the GP16 card. Table 3-19 describes the interface type and usage. Table 3-19 Interface of GP16 card Name Type Usage Description 1–16 SFP GPON Service interface...
70 W consumption 3.6 XEP8 card 3.6.1 Features The XEP8 card is a 10GEPON card inserted in the ISCOM6860 chassis. Each card provides 8 XFP PON interfaces. Table 3-22 lists features of the XEP8 card. Table 3-22 Features of XEP8 card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Table 3-23 Interface of XEP8 card Name Type Usage Description 1–8 XFP PON Service interface Available optical modules: 10G/1GBASE-PRX30 3.6.4 LEDs There are 9 LEDs on the XEP8 card. Table 3-24 lists descriptions of these LEDs.
88.5 W consumption 3.7 GE16 card 3.7.1 Features The GE16 card is a GE Ethernet card inserted in the ISCOM6860 chassis, which provides 16 GE optical interfaces. Table 3-26 lists features of the GE16 card. Table 3-26 Features of GE16 card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards 3.7.2 Panel and slots The GE16 card can be inserted into slots 3–9 of the ISCOM6860 chassis. Figure 3-7 shows appearance of the GE16 card. Figure 3-7 Appearance of GE16 card 3.7.3 Interfaces There are 16 interfaces on the GE16 card.
32 W consumption 3.8 XP2A card 3.8.1 Features The XP2A card is a 10GE Ethernet card inserted in the ISCOM6860 chassis. It provides 2 SFP+ optical interfaces. Table 3-30 lists features of the XP2A card. Table 3-30 Features of XP2A card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards 3.8.2 Panel and slots The XP2A card can be inserted into slots 10 of the ISCOM6860 chassis. Figure 3-8 shows appearance of the XP2A card. Figure 3-8 Appearance of XP2A card 3.8.3 Interfaces There are 2 interfaces on the XP2A card.
13 W consumption 3.9 XP4A card 3.9.1 Features The XP4A card is a 10GE Ethernet card inserted in the ISCOM6860 chassis, which provides 4 SFP+ optical interfaces. Table 3-34 lists features of the XP4A card. Table 3-34 Features of XP4A card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Figure 3-9 Appearance of XP4A card 3.9.3 Interfaces There are 4 interfaces on the XP4A card. Table 3-25 describes the interface type and usage. Table 3-35 Interface descriptions of XP4A card Name Type...
35 W 3.10 XP4L card 3.10.1 Features The XP4L card is a 10GE Ethernet card inserted in the ISCOM6860 chassis, which provides 4 SFP+ optical interfaces. Table 3-38 lists features of the XP4L card. Table 3-38 Features of XP4L card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Figure 3-10 Appearance of XP4L card 3.10.3 Interfaces There are 4 interfaces on the XP4L card. Table 3-39 describes the interface type and usage. Table 3-39 Interface descriptions of XP4L card Name Type...
3.11 RPD2151 card 3.11.1 Features The RPD2151 card is an intelligent -48 VDC power supply card inserted in the ISCOM6860 chassis. It supplies power for other cards in the chassis. Table 3-42 lists features of the RPD2151 card. Table 3-42 Features of RPD2151 card...
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Figure 3-11 Appearance of RPD2151 card 3.11.3 Interfaces There is only one DC power supply interface on the RPD2151 card. Table 3-43 describes the interface. Table 3-43 Interface descriptions of RPD2151 card Identifier purpose –...
Page 46
Raisecom ISCOM6860 (A) Hardware Description 3 Cards Parameter Description Maximum power < 5 W (no load) or 1500 W (output power) consumption Raisecom Technology Co., Ltd.
Ground cable 4.1 Fiber 4.1.1 Introduction The ISCOM6860 can use the Single-mode Fiber (SMF) and Multi-mode Fiber (MMF). The two kind of fibers are the same in appearance but different in color. The SMF is yellow while the MMF is orange.
The appearance of various types of fiber connector and the methods of inserting and plugging the fiber connector are as below: LC/PC fiber connector Figure 4-1 shows the LC/PC fiber connector used by the ISCOM6860. Figure 4-1 LC/PC fiber connector Raisecom Technology Co., Ltd.
To remove the fiber, press the latch on the connector, pull the fiber connector inward slightly, and pull the fiber out. SC/PC fiber connector Figure 4-2 shows the SC/PC fiber connector used by the ISCOM6860. Figure 4-2 SC/PC fiber connector When connecting or removing the SC/PC fiber connector, align the connector with the optical interface, and do not rotate the fiber.
Connect the uplink electrical interface of the ISCOM6860 or other devices. Connect the SNMP interface of the ISCOM6860 and the NMS network. Ethernet service interfaces of the ISCOM6860 are adaptive to both straight-through cable mode and crossover cable mode. Make Ethernet cables as required on site.
2-m cable, the cable name will be configured to CBL-ETH-RJ45/RJ45-2m/RoHS. 4.3 Configuration cable 4.3.1 Introduction The configuration cable is used to connect the Console interface of the ISCOM6860 to a PC. Therefore, you can manage the ISCOM6860 through the PC. Raisecom Technology Co., Ltd.
Raisecom ISCOM6860 (A) Hardware Description 4 Cables 4.3.2 Appearance The configuration cable connector used by the ISCOM6860 is a DB9 connector and a RJ45 connector, as shown in Figure 4-6. Figure 4-6 Configuration cable 4.3.3 Wiring Figure 4-7 lists PINs and wiring of the RS-232 Console interface and RJ45 Ethernet interface.
4.4.1 Introduction The DC power cable transmits -48 VDC power to the -48 VDC power supply interface of the ISCOM6860, and supplies power for other cards in the chassis. 4.4.2 Appearance A DC power cable is composed of a DC connector and a coaxial cable, as shown in Figure 4-8.
4.5 Ground cable Connecting the ground cable properly is an important guarantee for lightning protection, anti-electric shock, and anti-interference. The ISCOM6860 must be grounded with the ground cable correctly during installation, which helps to avoid personal injury and equipment damage.
Outer diameter: ≤ 6.1 mm Cross-section area of the 5–4AWG (16–25 mm conductive wire The ISCOM6860 is delivered without the ground cable. You need to prepare one or make the ground cable on site if needed. Raisecom Technology Co., Ltd.
Page 57
Raisecom ISCOM6860 (A) Hardware Description 4 Cables The length of the ground cable cannot be greater than 30 m and should be as short as possible. If the length exceeds 30 m, use a ground bar instead. Raisecom Technology Co., Ltd.
PON SFP module We recommend using Raisecom optical modules. Raisecom optical modules have been tested during R&D period very suitable for the ISCOM6860. Therefore, using Raisecom optical modules are the best choice for better performance index and lower fault occurrence rate.
Figure 5-3 shows the appearance of the 10GE SFP+ module. Figure 5-3 Appearance of 10GE SFP+ module Available SFP+ modules for the 10GE service interfaces of the ISCOM6860 are shown as follows: ...
Passive Optical Network (PON) system. Figure 5-4 shows the appearance of the PON SFP module. Figure 5-4 Appearance of PON SFP module 5.3.2 Label Available modules for the PON interfaces of the ISCOM6860 are shown as below: 1000BASE-PX20-D (EPON) ...
Ensure the proper ventilation of the cooling air within the chassis. 6.1.2 Appearance According to different slots, the ISCOM6860 supports 5 types of blank panels. There is no LED, interface, and print on the blank panel. Figure 6-1 shows the appearance.
Raisecom ISCOM6860 (A) Hardware Description 7 Lookup table for LEDs Lookup table for LEDs Table 7-1 lists LEDs on the ISCOM6860 chassis and cards in the chassis. Table 7-1 Lookup table for LEDs on the ISCOM6860 Status Description Green Power LED ...
Page 67
Raisecom ISCOM6860 (A) Hardware Description 7 Lookup table for LEDs Status Description Green PON interface working LED Green: the interface is properly connected and a regularly- registered ONU is working on the interface. Off: the interface is not connected or there is no regularly-registered ONU working on the interface.
8 Lookup table for weight and power consumption Lookup table for weight and power consumption Table 8-1 lists weight and power consumption values of the ISCOM6860. Table 8-1 Lookup table for weight and power consumption of the ISCOM6860 Component Parameter Overall maximum power...
Page 69
Raisecom ISCOM6860 (A) Hardware Description 8 Lookup table for weight and power consumption Component Parameter XP4L Weight 0.82 kg Maximum power consumption 35 W RPD2151 Weight 0.24 Kg Output power consumption: Maximum power consumption 1500 W Non-load power consumption: <5 W...
Raisecom ISCOM6860 (A) Hardware Description 9 Appendix Appendix This chapter introduces abbreviations and terms involved in this guide. Terms Acronyms and abbreviations 9.1 Terms AES (Advanced A specification for the encryption of electronic data established by Encryption the U.S. National Institute of Standards and Technology (NIST). At Standard) present, it is one of most popular algorithm for key encryption.
