  • Page 1 ISCOM6820 (A) Hardware Description (Rel_03)
  • Page 2 Raisecom Technology Co., Ltd. provides customers with comprehensive technical support and services. For any assistance, please contact our local office or company headquarters. Website: http://www.raisecom.com Tel: 8610-58963399 Fax: 8610-58963399-8886 Email: export@raisecom.com Address: No. 11, East Area, No. 10 Block, East Xibeiwang Rd, Haidian District, Beijing, P.R.China...
  • Page 3 ISCOM6820 (A) Hardware Description Preface Preface Objectives This document describes the chassis, hardware components, and cables of the ISCOM6820, including hardware features, components, supported functions of each component, and appearance and technical specifications of cables. Versions The following table lists the product versions related to this document.
  • Page 4 Paragraphs in Warning, Caution, Notes, and Tip are in Arial. Buttons and navigation path are in Boldface. Boldface Italic Book titles are in italics. Lucida Console Terminal display is in Lucida Console. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 5 Upgraded the software version to V3.23. Issue 02 (2023-08-03) Second commercial release  Added descriptions of the ISCOM6800-GPHA and ISCOM6800-XCHA.  Upgraded the software version to V3.21. Issue 01 (2023-03-31) Initial commercial release Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 6: Table Of Contents

    2.1 Overview ................................4 2.1.1 Classification............................4 2.1.2 Appearances ............................5 2.1.3 Hardware information label ........................7 2.2 Main control uplink card ISCOM6820-SMUA ....................9 2.2.1 Introduction ............................. 9 2.2.2 Panel and slots............................9 2.2.3 Interfaces ..............................9 2.2.4 LEDs ..............................10 2.2.5 Technical specifications ........................
  • Page 7 3.4.2 POL-DC(2C)-DSUB/U-6.0mm2-6m/RoHS ..................29 3.4.3 POL-DC(2C)-DSUB/U-6.0mm2-A-15m/RoHS ................... 30 3.5 Ground cable ..............................31 3.5.1 Introduction ............................31 3.5.2 Appearance ............................31 3.5.3 Technical specifications ........................32 4 Pluggable optical modules ......................33 Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 8 5 Lookup table of LEDs......................... 37 6 Lookup table of weight and power consumption ..............39 7 Appendix ............................40 7.1 Terms ................................40 7.2 Acronyms and abbreviations .......................... 41 Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 9: Overview

    Physical parameters 1.1 Introduction The ISCOM6820, developed by Raisecom, is a next-generation, compact, 2U, and plug-in Optical Line Terminal (OLT) which supports Gigabit Passive Optical Network (GPON) cards and XG(S)-PON cards. It is oriented to industrial customers, providing rich features and flexible networking schemes to meet low-density and long-distance requirements for optical fiber access.

  • Page 10: Appearance And Slots

    1.2 Appearance and slots 1.2.1 Appearance of chassis The ISCOM6820 is a cartridge device, which is flexible to deploy. Dimensions of the chassis are: 442 mm (Width) × 250 mm (Depth) × 88 mm (Height) (without brackets). Figure 1-1 shows the appearance of the ISCOM6820 chassis.

  • Page 11: Physical Parameters

    Raisecom ISCOM6820 (A) Hardware Description 1 Overview 1.3 Physical parameters Table 1-2 lists physical parameters of the ISCOM6820. Table 1-2 Physical parameters of the ISCOM6820 Parameter Description 442 mm (Width) × 250 mm (Depth) × 88 mm Dimensions (Height) (excluding brackets)

  • Page 12: Cards And Components

    Service card ISCOM6800-XGHA  DC power module (RPD1601)  Fan module FANS385 2.1 Overview 2.1.1 Classification The ISCOM6820 is composed of the following 6 types of components:  Main control uplink card  Service card  Power supply card ...

  • Page 13: Appearances

    Figure 2-1 shows the appearance of the main control uplink card. Figure 2-1 Appearance of the main control uplink card Appearance of service cards  ISCOM6800-XCOA Figure 2-2 shows the appearance of the ISCOM6800-XCOA. Figure 2-2 Appearance of the ISCOM6800-XCOA Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 14 Figure 2-4 shows the appearance of the ISCOM6800-XCHA. Figure 2-4 Appearance of the ISCOM6800-XCHA Appearance of the power module Figure 2-5 shows the appearance of the power module. Figure 2-5 Appearance of the power module Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 15: Hardware Information Label

    Figure 2-6 shows the appearance of the fan module. Figure 2-6 Appearance of the fan module 2.1.3 Hardware information label Hardware information about ISCOM6820 components is pasted on the eye-catching position of the Printed Circuit Board (PCB), as shown in Figure 2-7. Raisecom Proprietary and Confidential...
  • Page 16 Raisecom ISCOM6820 (A) Hardware Description 2 Cards and components Figure 2-7 Hardware information label on the ISCOM6820 The position of hardware information labels may be different because the layouts of elements are different, so search for it carefully. Table 2-2 lists items on the hardware information label.

  • Page 17: Main Control Uplink Card Iscom6820-Smua

    The MCUA card can be inserted into slot 1 and slot 2 only. Figure 2-8 shows the panel of the main control uplink card. Figure 2-8 Panel of the main control uplink card When the ISCOM6820-SMUA is inserted into slot 1 or 2, it supports the 1000 Mbit/s optical module (1000base-X) and 10 Gbit/s optical module (10Gbase-X). 2.2.3 Interfaces There are 10 interfaces on the ISCOM6820-SMUA.

  • Page 18: Leds

    Electrical features RS-232 Baud rate 115200 Cable specifications 4-core shielded cable 2.2.4 LEDs There are 4 LEDs on the ISCOM6820-SMUA. Table 2-5 lists LEDs on the ISCOM6820- SMUA. Table 2-5 LEDs on the ISCOM6820-SMUA Status Description Green Active/Backup LED ...

  • Page 19: Technical Specifications

    The ISCOM6800-XCOA is a XG(S)-PON Combo interface card of the ISCOM6820, providing 8 XG(S)-PON Combo interfaces. 2.3.2 Panel and slots The ISCOM6800-XCOA can be only inserted into slots 3 are 4 of the ISCOM6820. Figure 2-9 shows the panel of the ISCOM6800-XCOA. Figure 2-9 Panel of the ISCOM6800-XCOA 2.3.3 Interfaces...

  • Page 20: Leds

    Table 2-9 lists technical specifications of the ISCOM6800-XCOA. Table 2-9 Technical specifications of the ISCOM6800-XCOA Parameter Description Dimensions 391.50 mm (Width) × 222 mm (Depth) × 22.56 mm (Height) Weight 1.3 kg Power consumption < 85 W Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 21: Service Card Iscom6800-Gpha

    The ISCOM6800-GPHA is a GPON interface card of the ISCOM6820, providing 16 GPON interfaces. 2.4.2 Panel and slots The ISCOM6800-GPHA can be only inserted into slots 3 are 4 of the ISCOM6820. Figure 2-10 shows the panel of the ISCOM6800-GPHA. Figure 2-10 Panel of the ISCOM6800-GPHA 2.4.3 Interfaces...

  • Page 22: Technical Specifications

    The ISCOM6800-XCHA is a XG(S)-PON Combo interface card of the ISCOM6820, providing 16 XG(S)-PON Combo interfaces. 2.5.2 Panel and slots The ISCOM6800-XCHA can be only inserted into slots 3 are 4 of the ISCOM6820. Figure 2-11 shows the panel of the ISCOM6800-XCHA. Figure 2-11 Panel of the ISCOM6800-XCHA 2.5.3 Interfaces...

  • Page 23: Leds

    < 125 W 2.6 Service card ISCOM6800-XGHA 2.6.1 Introduction The ISCOM6800-XGHA is a XGS-PON service card of the ISCOM6820, providing 16 SFP+ XGS-PON interfaces. The SFP module is inserted with a degree of 30º C. Table 2-16 lists features of the ISCOM6800-XGHA.

  • Page 24: Panel And Slots

    Security Support PON interface Layer 2 isolation. 2.6.2 Panel and slots The ISCOM6800-XGHA can be only inserted into slots 3 are 4 of the ISCOM6820. Figure 2-12 shows the panel of the ISCOM6800-XGHA. Figure 2-12 Panel of the ISCOM6800-XGHA 2.6.3 Interfaces There are 16 interfaces on the ISCOM6800-XGHA.

  • Page 25: Technical Specifications

    Table 2-19 lists technical specifications of the ISCOM6800-XGHA. Table 2-19 Technical specifications of the ISCOM6800-XGHA Parameter Description Dimensions 392 mm (Width) × 222 mm (Depth) × 22.5 mm (Height) Weight 1.35 kg Power consumption < 82 W Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 26: Dc Power Module (Rpd1601)

    2 Cards and components 2.7 DC power module (RPD1601) 2.7.1 Introduction The RPD1601-48S48 (hereinafter referred to as the RPD1601) module is the DC power module of the ISCOM6820. It has the following features:  Wide voltage input: -38.4 to -57.6 VDC ...

  • Page 27: Leds

    Common mode: 1 kV 2.8 Fan module FANS385 2.8.1 Introduction The FANS385 is the fan module of the ISCOM6820. It supports the following features:  Support fan monitoring. The system monitors the working status of the fan and an alarm is generated when the fan fails.

  • Page 28: Panel And Slots

    ISCOM6820 (A) Hardware Description 2 Cards and components 2.8.2 Panel and slots The FANS385 module can be inserted into slot 5 of the ISCOM6820. Figure 2-14 shows the panel of the FANS385 module. Figure 2-14 Panel of the FANS385 module 2.8.3 LEDs...
  • Page 29 2 Cards and components Table 2-24 Technical specifications of the FANS385 module Parameter Description Dimensions 37.0 mm (Width) × 221.5 mm (Depth) × 85.5 mm (Height) Weight 0.7 kg Power consumption 30 W Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 30: Fiber And Cables

    Raisecom ISCOM6820 (A) Hardware Description 3 Fiber and cables Fiber and cables This chapter describes fiber and cables of the ISCOM6820, including the following sections:  Fiber  Ethernet cable  Configuration cable  DC power cable  Ground cable 3.1 Fiber...

  • Page 31: Connector

    Figure 3-1 shows the appearance of the LC/PC fiber connector. Figure 3-1 LC/PC fiber connector When connecting or removing the LC/PC fiber connector, align the connector with the optical interface, and do not rotate the fiber. Do as below: Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 32: Wiring

    Optical interface Tx 3.2 Ethernet cable 3.2.1 Introduction The Ethernet cable of the ISCOM6820 can be used to:  Connect the Ethernet electrical interface of the ISCOM6820 to other devices. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 33: Appearance

     Connect the SNMP of the ISCOM6820 to the NView NMS system. The Ethernet interface on the ISCOM6820 is adaptive to straight-through cable mode and crossover cable mode. So both kinds of Ethernet cables can be used. The Ethernet cable needs to be made on site.
  • Page 34 White/Blue PIN 5 White/Blue PIN 6 Orange PIN 6 Green PIN 7 White/Brown PIN 7 White/Brown PIN 8 Brown PIN 8 Brown Figure 3-5 shows wiring of the crossover cable. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 35: Configuration Cable

    CBL-ETH-RJ45/RJ45-2m/RoHS. 3.3 Configuration cable The configuration cable is used to connect the Console interface of the ISCOM6820 and the RS-232 serial interface of the maintenance console, and transmit configuration data signals. The maintenance console troubleshoots and maintains the ISCOM6820 through the Console interface.

  • Page 36: Appearance

    Function PIN 1 PIN 6 PIN 2 PIN 7 PIN 3 PIN 8 PIN 4 PIN 9 – – PIN 5 Table 3-8 lists PINs of the RJ45 Ethernet interface. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 37: Dc Power Cable

    3.4 DC power cable 3.4.1 Introduction The DC power cable supplies -48 VDC power from the power souring equipment to the power interface on the RPD1601 module of the ISCOM6820, and then transmits power to the entire device. 3.4.2 POL-DC(2C)-DSUB/U-6.0mm2-6m/RoHS Appearance Figure 3-8 shows the DC power cable with one DSUB.

  • Page 38: Pol-Dc(2C)-Dsub/U-6.0Mm2-A-15M/Rohs

    60228 IEC 02 (RV) black (6mm ) with flame retardant tube Rated voltage (V) 450/750 Insulation and voltage 2500 VAC, 5min resistance (cable) Certification RoHS Compliant Customized length The cable length is 15 m. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 39: Ground Cable

    3 Fiber and cables 3.5 Ground cable Connecting the ground cable properly is an important guarantee for lightning protection, anti-electric shock, and anti-interference. The ISCOM6820 must be connected to the ground cable correctly during installation, which helps avoid personal injury and equipment damage.

  • Page 40: Technical Specifications

    5–4 AWG (16–25 mm conducting wire  The ISCOM6820 is delivered without the ground cable. If required, prepare or make the ground cable on site.  The ground cable cannot be longer than 30 m and should be as short as possible;...

  • Page 41: Pluggable Optical Modules

    ISCOM6820 (A) Hardware Description 4 Pluggable optical modules Pluggable optical modules This chapter describes pluggable optical modules (Raisecom SFP modules are recommended) that could be used by the ISCOM6820, including the following sections:  1000 Mbit/s SFP optical module ...

  • Page 42: Gbit/S Sfp+ Optical Module

    The SFP+ optical module can be applied to 10Gbit/s telecommunication or data communication networks. It is integrated with sending and receiving features. Figure 4-2 shows the appearance of the SFP+ optical module. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 43: Technical Specifications

    Raisecom ISCOM6820 (A) Hardware Description 4 Pluggable optical modules Figure 4-2 SFP+ optical module The 10GE service interface on the ISCOM6820 supports the optical module of the following types:  10GBASE-SX  10GBASE-LR 4.2.2 Technical specifications Table 4-3 lists technical specifications of the SFP+ optical interface.

  • Page 44: Pon Sfp Optical Module

    Figure 4-3 shows the appearance of the PON SFP optical module. Figure 4-3 PON SFP optical module 4.3.2 Standard The GPON interface on the ISCOM6820 supports the optical module compliant with the Class B+, Class C+, Class C++, GSFP+-XSCN2DM-R (XGS Combo PON), and GSFP+- XCN2DM-R (XG Combo PON) standards.

  • Page 45: Lookup Table Of Leds

    Raisecom ISCOM6820 (A) Hardware Description 5 Lookup table of LEDs Lookup table of LEDs Table 5-1 lists LEDs of the ISCOM6820. Table 5-1 LEDs of the ISCOM6820 Status Description Green Power LED  Green: the power supply is working properly.
  • Page 46 Red: the power is working improperly and an alarm is generated.  Off: the power is working properly. STATUS Green Fan status LED  Green: the fan is working properly.  Off: the fan is working improperly. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 47: Lookup Table Of Weight And Power Consumption

    ISCOM6820 (A) Hardware Description 6 Lookup table of weight and power consumption Lookup table of weight and power consumption Table 6-1 lists weight and power consumption of the ISCOM6820. Table 6-1 Weight and power consumption of the ISCOM6820 Component Parameter...

  • Page 48: Appendix

    The cable to connect the device to ground, usually a yellow/green coaxial cable. Connecting the ground cable properly is an important Ground cable guarantee to lightning protection, anti-electric shock, and anti- interference. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 49: Acronyms And Abbreviations

    The Ethernet interface chooses the rate and duplex mode according to Self-adaption the result of auto-negotiation. Single-mode In this fiber, single-mode optical signals are transmitted. fiber 7.2 Acronyms and abbreviations American Wire Gauge Access Control List Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 50 Link Layer Discovery Protocol MPLS Multi-protocol label switching Optical Distribution Frame Operation Administration and Maintenance Packet Transport Network Precision Time Protocol Quality of Service Relative Humidity Service-Level Agreement Uninterruptible Power Supply Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 51 Address No. 11, East Area, No. 10 Block, East Xibeiwang Rd, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-58963399 Fax: 8610-58963399-8886 http://www.raisecom.com Email: export@raisecom.com...
