  • Page 1 ISCOM5508 (B) Hardware Description (Rel_01)
  • Page 2 Website: http://www.raisecom.com Tel: 8610-82883305 Fax: 8610-82883056 Email: export@raisecom.com Address: Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 ----------------------------------------------------------------------------------------------------------------------------------------- Notice Copyright © 2014 Raisecom All rights reserved.
  • Page 3 ISCOM5508 (B) Hardware Description Preface Preface Objectives This document describes the chassis, hardware components, and cables of the ISCOM5508, including hardware features, components, supported functions and technical specifications of each component, and appearance and technical specifications of cables. Versions The following table lists the product versions related to this document.
  • Page 4 Raisecom ISCOM5508 (B) Hardware Description Preface Conventions Symbol conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicate a hazard with a medium or low level of risk which, if not avoided, could result in minor or moderate injury.

  • Page 5: Table Of Contents

    Raisecom ISCOM5508 (B) Hardware Description Contents Contents 1 Product overview........................... 1 1.1 Overview ................................1 1.2 Appearance and slots ............................2 1.2.1 Appearance of chassis ..........................2 1.2.2 Distribution of slots ..........................2 1.3 Physical parameters ............................2 2 Components ........................... 4 2.1 Overview of components ..........................
  • Page 6 Raisecom ISCOM5508 (B) Hardware Description Contents 2.5.3 Interfaces ............................... 15 2.5.4 LEDs ..............................15 2.5.5 Technical specifications ........................16 2.6 DC power module (RPD1101-48S12) ......................16 2.6.1 Introduction ............................16 2.6.2 Panel and slots............................17 2.6.3 Interfaces ............................... 17 2.6.4 LEDs ..............................17 2.6.5 Technical specifications ........................
  • Page 7 Raisecom ISCOM5508 (B) Hardware Description Contents 4.1.1 Functions and appearance ........................34 4.1.2 Label ..............................34 4.1.3 Technical specifications ........................35 4.2 1000 Mbit/s SFP electrical module ........................ 36 4.2.1 Functions and appearance ........................36 4.2.2 Techinical specifications ........................36 4.3 PON SFP optical module ..........................
  • Page 8 Figures Figures Figure 1-1 Appearance of the ISCOM5508 chassis ....................2 Figure 1-2 Distribution of slots on the ISCOM5508 ....................2 Figure 2-1 Appearance of the MCC (EPSC) ......................5 Figure 2-2 Appearance of the EP4B sub-card ......................5 Figure 2-3 Appearance of the GE4B sub-card ....................... 6 Figure 2-4 Appearance of the power module ......................
  • Page 9 Raisecom ISCOM5508 (B) Hardware Description Figures Figure 3-13 OT terminal ............................32 Figure 4-1 1000 Mbit/s SFP optical module ......................34 Figure 4-2 Label of the 1000 Mbit/s SFP optical module ..................35 Figure 4-3 1000 Mbit/s SFP electrical module ..................... 36 Figure 4-4 PON SFP optical module ........................
  • Page 10 ISCOM5508 (B) Hardware Description Tables Tables Table 1-1 Physical parameters of the ISCOM5508 ....................3 Table 2-1 Components of the ISCOM5508 ......................4 Table 2-2 Items on the hardware information label ....................7 Table 2-3 Interfaces on the EPSC card ........................8 Table 2-4 Parameters of the Console interface .......................
  • Page 11 Table 4-4 Model of the PON SFP optical module ....................37 Table 4-5 Technical specifications of the CLASS B+ optical module ..............38 Table 5-1 LEDs of the ISCOM5508 ........................39 Table 6-1 Weight and power consumption of the ISCOM5508 ................41 Raisecom Technology Co., Ltd.

  • Page 12: Product Overview

    Physical parameters 1.1 Overview The ISCOM5508 is a next-generation, small-capacity, 1 U, and plug-in Ethernet Passive Optical Network (EPON) Optical Line Terminal (OLT). It is oriented to industrial customers, providing rich features and flexible networking schemes to meet low-density and long- distance requirements for optical fiber access.

  • Page 13: Appearance And Slots

    1.2 Appearance and slots 1.2.1 Appearance of chassis The ISCOM5508 is a cartridge device, which is flexible to be deployed. Dimensions of the chassis are: 440 mm (Width) × 266 mm (Depth) × 44 mm (Height) (without brackets). Figure 1-1 shows the appearance of the ISCOM5508 chassis.

  • Page 14: Table 1-1 Physical Parameters Of The Iscom5508

    Raisecom ISCOM5508 (B) Hardware Description 1 Product overview Table 1-1 Physical parameters of the ISCOM5508 Technical specification Description 440 mm (Width) × 266 mm (Depth) × 44 mm Dimensions (Height) (without brackets) Standard Weight 5.51 kg configuration Power consumption 40 W...

  • Page 15: Components

    AC power module (RPA1101-SI-220S12)  DC power module (RPD1101-48S12)  Fan module (FANS306) 2.1 Overview of components 2.1.1 Classification of components The ISCOM5508 is composed of the following four types of components:   Extended sub-card  Power module ...

  • Page 16: Appearances Of Components

    Raisecom ISCOM5508 (B) Hardware Description 2 Components Component Name Description RPD1101-48S12 -48 VDC power module Fan module FANS306 Fan module 2.1.2 Appearances of components Appearance of MCC Figure 2-1 shows the appearance of the MCC (EPSC). Figure 2-1 Appearance of the MCC (EPSC) Appearance of sub-card Figure 2-2 shows the appearance of the EP4B sub-card.

  • Page 17: Figure 2-3 Appearance Of The Ge4B Sub-Card

    Raisecom ISCOM5508 (B) Hardware Description 2 Components Figure 2-3 Appearance of the GE4B sub-card Appearance of power module Figure 2-4 shows the appearance of the power module. Figure 2-4 Appearance of the power module Appearance of fan module Figure 2-5 shows the appearance of the fan module.

  • Page 18: Hardware Information Label

    2 Components 2.1.3 Hardware information label Hardware information of ISCOM5508 components will be described by a label pasted on the Printed Circuit Board (PCB) to facilitate you to view it, as shown in Figure 2-6. Figure 2-6 Hardware information label on the ISCOM5508 The position of hardware information labels may be different because the layouts of elements are different, so search for it carefully.

  • Page 19: Mcc (Epsc)

    The EPSC card is the main unit for accessing, processing, and switching services. It provides 4 EPON optical interfaces, 2 GE electrical interfaces (RJ45), and 4 GE optical interfaces (SFP). Moreover, it supports managing and maintaining the ISCOM5508 through the SNMP interface and Console interface.

  • Page 20: Table 2-4 Parameters Of The Console Interface

    Raisecom ISCOM5508 (B) Hardware Description 2 Components Table 2-4 Parameters of the Console interface Parameter Description Connector RJ45 Working mode Duplex UART Electrical features RS-232 Baud rate 9600 Baud Data bit Parity check None Stop bit Flow control None Cable specifications 8-core shielded cable Table 2-5 lists parameters of the SNMP interface.

  • Page 21: Leds

    Raisecom ISCOM5508 (B) Hardware Description 2 Components 2.2.4 LEDs There are 16 LEDs on the EPSC card, where 6 LEDs are integrated with the RJ45 interface. Table 2-7 lists LEDs on the EPSC card. Table 2-7 LEDs on the EPSC card...

  • Page 22: 4-Epon Interface Sub-Card (Ep4B)

    The EP4B sub-card is the EPON interface sub-card of the ISCOM5508, providing 4 EPON SFP interfaces. 2.3.2 Panel and slots The EP4B sub-card can be inserted into slot 2 or slot 3 of the ISCOM5508. Figure 2-8 shows the panel of the EP4B sub-card. Figure 2-8 Panel of the EP4B sub-card 2.3.3 Interfaces...

  • Page 23: Leds

    Power consumption 2.4 4-GE interface sub-card (GE4B) 2.4.1 Introduction The GE4B sub-card is the GE interface sub-card of the ISCOM5508, providing 4 SFP-type GE interfaces and being compatible with 1000 Mbit/s Ethernet optical and electrical modules. 2.4.2 Panel and slots The GE4B sub-card can be inserted into slot 2 or slot 3.

  • Page 24: Interfaces

    For details of the optical module, see chapter 4 Pluggable modules.  When the GE4B card uses the 1000BASE-T electrical module, the interface rate should be configured to "forced 1000M" mode. For details, see ISCOM5508 (B) Configuration Guide. 2.4.4 LEDs There are 6 LEDs on the GE4B sub-card.

  • Page 25: Technical Specifications

    Power consumption 2.5 AC power module (RPA1101-SI-220S12) 2.5.1 Introduction The RPA1101-SI-220S12 (hereinafter referred to as RPA1101) module is the AC power module of the ISCOM5508. It supports the following features:  Wide voltage input: 100–240 VAC  Rated output voltage: 12 V; rated output current: 8.3 A ...

  • Page 26: Panel And Slots

    Raisecom ISCOM5508 (B) Hardware Description 2 Components  Turn off the power switch or disconnect the power connection before installing or removing the power cable.  Ensure that the label on the power cable is correct before connecting the power cable.

  • Page 27: Technical Specifications

    (AC power) 2.6 DC power module (RPD1101-48S12) 2.6.1 Introduction The RPD1101-48S12 (hereinafter referred to as RPD1101) module is the DC power module of the ISCOM5508. It supports the following features:  Wide voltage input: -38 to -72 VDC  Rated output voltage: 12 V; rated output current: 8.3 A ...

  • Page 28: Panel And Slots

    Raisecom ISCOM5508 (B) Hardware Description 2 Components 2.6.2 Panel and slots The RPD1101 power module can be inserted into slot 4 or slot 5. Figure 2-11 shows the panel of the RPD1101 power module. Figure 2-11 Panel of the RPD1101 power module 2.6.3 Interfaces...

  • Page 29: Technical Specifications

    Output power 100 W 2.7 Fan module (FANS306) 2.7.1 Introduction The FANS306 module is the fan module of the ISCOM5508. It supports the following features:  Support fan monitoring. The system monitors the working status of the fan and an alarm is generated when the fan fails.

  • Page 30: Leds

    Raisecom ISCOM5508 (B) Hardware Description 2 Components Figure 2-12 Panel of the FANS306 module 2.7.3 LEDs There are 2 LEDs on the FANS306 module. Table 2-22 lists LEDs on the FANS306 module. Table 2-22 LEDs on the FANS306 module Status...

  • Page 31: Fiber And Cables

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables Fiber and cables This chapter describes fiber and cables of the ISCOM5508, including the following sections:  Fiber  Ethernet cable  Configuration cable  DC power cable  AC power cable ...

  • Page 32: Connector

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables Usage Local Remote Type Standard connector connector Connect the ISCOM5508 to SC/PC LC/PC 2 mm single-mode fiber the ODF through the PON SC/PC FC/PC 2 mm single-mode fiber interface. SC/PC SC/PC 2 mm single-mode fiber ...

  • Page 33: Wiring Scheme

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables When connecting or removing the LC/PC fiber connector, align the connector with the optical interface, and do not rotate the fiber. Operate as below:  To connect the fiber, align the head of the fiber with the optical interface and insert the fiber into the interface gently.

  • Page 34: Ethernet Cable

     Connect the SNMP interface of the ISCOM5508 to the NView NMS system. The Ethernet interface on the ISCOM5508 is self-adaptive to straight-through cable mode and crossover cable mode. So both kinds of Ethernet cables can be used. The Ethernet cable needs to be made on site.

  • Page 35: Figure 3-4 Wiring Of The Straight-Through Cable Wiring

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables Connector 1 (RJ45) EIA/TIA568B Connector 2 (RJ45) EIA/TIA568B PIN 7 White/Brown PIN 7 White/Brown PIN 8 Brown PIN 8 Brown Figure 3-4 shows wiring of the straight-through cable. Figure 3-4 Wiring of the straight-through cable wiring...

  • Page 36: Figure 3-5 Wiring Of The 100 Mbit/S Crossover Cable

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables Figure 3-5 Wiring of the 100 Mbit/s crossover cable The 1000 Mbit/s crossover cable uses all 8 wires of the twisted-pair cable. The crossover is PIN 1 to PIN 3, PIN 2 to PIN 6, PIN 4 to PIN 7, and PIN 5 to PIN 8.

  • Page 37: Configuration Cable

    3.3 Configuration cable 3.3.1 Introduction The configuration cable is used to connect the Console interface of the ISCOM5508 and the RS-232 serial interface of the maintenance console, and transmit configuration data signals. The maintenance console troubleshoots and maintains the ISCOM5508 through the Console interface.

  • Page 38: Technical Specifications

    3 Fiber and cables 3.3.3 Technical specifications PIN definitions The configuration cable is used to connect the Console interface of the ISCOM5508 and the RS-232 serial interface of the maintenance console. 0 shows PINs on both connectors of the ISCOM5508.

  • Page 39: Dc Power Cable

    3.4 DC power cable 3.4.1 Introduction The DC power cable supplies -48 VDC power from the power souring equipment to the power interface on the RPD1101 module of the ISCOM5508, and then transmits power to the entire device. 3.4.2 Appearance The DC power cable is composed of the DC power connector and coaxial cable, as shown in Figure 3-9.

  • Page 40: Technical Specifications

    3.5.1 Introduction The AC power cable supplies 110/220 VAC power from the power souring equipment to the power interface on the RPA1101 module of the ISCOM5508, and then transmits power to the entire device. Types of the AC power cable of the ISCOM5508 depend on different regional standards, as shown in Table 3-9.

  • Page 41: Appearance

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables 3.5.2 Appearance The AC power cable which meets European standard is composed of a European standard French mode 3-pin plug and a receptacle, as shown in Figure 3-10. Figure 3-10 European standard AC power cable The AC power cable which meets American standard is composed of an American standard 3- pin plug and a receptacle, as shown in Figure 3-11.

  • Page 42: Grounding Cable

    3.6 Grounding cable Connecting the grounding cable properly is an important guarantee to lightning protection, anti-electric shock, and anti-interference. The ISCOM5508 must be connected to the grounding cable correctly during installation, which helps avoid personal injury and equipment damage.

  • Page 43: Technical Specifications

    Raisecom ISCOM5508 (B) Hardware Description 3 Fiber and cables Figure 3-13 OT terminal Inner radius of Inner radius of sheath Thickness of soldering lug soldering lug 3.6.3 Technical specifications Table 3-12 lists technical specifications of the grounding cable. Table 3-12 Technical specifications of the grounding cable...

  • Page 44: Table 3-13 Technical Specifications Of The Ot Terminal

    16–15 AWG (1.2–1.5 mm of conducting wire  The ISCOM5508 is delivered without the grounding cable. If required, prepare or make grounding cables on site.  The grounding cable cannot be longer than 30 m and should be as short as possible;...

  • Page 45: Pluggable Modules

    Raisecom ISCOM5508 (B) Hardware Description 4 Pluggable modules Pluggable modules This chapter describes pluggable modules of the ISCOM5508, including the following sections:  1000 Mbit/s SFP optical module  1000 Mbit/s SFP electrical module  PON SFP optical module 4.1 1000 Mbit/s SFP optical module 4.1.1 Functions and appearance...

  • Page 46: Technical Specifications

    Raisecom ISCOM5508 (B) Hardware Description 4 Pluggable modules Figure 4-2 Label of the 1000 Mbit/s SFP optical module Table 4-1 describes the model of the 1000 Mbit/s SFP optical module. Table 4-1 Model of the 1000 Mbit/s SFP optical module...

  • Page 47: 1000 Mbit/S Sfp Electrical Module

    Raisecom ISCOM5508 (B) Hardware Description 4 Pluggable modules Model Mode Min. Extinction Transmi wavelength optical overload ratio (dB) sensitivity ssion (nm) power point (dBm) distance (dBm) (dBm) (km) Interface type USFP- 1550 Dual fiber -3 to 2 Gb/S2-D-R (LC/PC) single-mode...

  • Page 48: Pon Sfp Optical Module

    Figure 4-4 PON SFP optical module 4.3.2 Label The EPON interface on the ISCOM5508 supports the optical module compliant with the 1000BASE-PX20-D standard. There is a label on the bottom of the SFP optical module, which describes the model of the SFP optical module, as shown in Figure 4-5.

  • Page 49: Technical Specifications

    Raisecom ISCOM5508 (B) Hardware Description 4 Pluggable modules Field Description EPON-OLT-PX20+ Comply with PX20+ specification and be applied to OLT optical module 21CFR (J) Comply with U.S. DHHS 21CFR (J). Class1 Comply with class 1 laser safety. 4.3.3 Technical specifications Table 4-5 lists technical specifications of the CLASS B+ optical module.

  • Page 50: Lookup Table Of Leds

    Raisecom ISCOM5508 (B) Hardware Description 5 Lookup table of LEDs Lookup table of LEDs Table 5-1 lists LEDs of the ISCOM5508. Table 5-1 LEDs of the ISCOM5508 Status Description Green Power LED  Green: the power supply is working properly.
  • Page 51 Raisecom ISCOM5508 (B) Hardware Description 5 Lookup table of LEDs Status Description Alarm LED  Red: the device is working improperly and an alarm is generated.  Off: the device is working properly. Green AC power working LED  Green: the power module is working properly.

  • Page 52: Lookup Table Of Weight And Power Consumption

    ISCOM5508 (B) Hardware Description 6 Lookup table of weight and power consumption Lookup table of weight and power consumption Table 6-1 lists weight and power consumption of the ISCOM5508. Table 6-1 Weight and power consumption of the ISCOM5508 Component Parameter...
  • Page 53 Raisecom ISCOM5508 (B) Hardware Description 6 Lookup table of weight and power consumption  Standard configuration: chassis, MCC (EPSC), 2 power modules, and 1 fan module.  Full configuration: chassis, MCC (EPSC), 2 extended sub-cards, 2 power modules, and 1 fan module.

  • Page 54: Appendix

    Raisecom ISCOM5508 (B) Hardware Description 7 Appendix Appendix This chapter lists terms, acronyms, and abbreviations involved in this document.  Terms  Acronyms and abbreviations 7.1 Terms Unit of dimension, short for unit. It takes 44.45 mm as basic unit, namely, 1 U = 44.45 mm...

  • Page 55: Acronyms And Abbreviations

    Raisecom ISCOM5508 (B) Hardware Description 7 Appendix Cable to connect device to ground, usually a yellow/green coaxial Grounding cable cable IEEE American Institution of Electrical and Electronic Engineers International Telecommunication Union Telecommunication ITU-T Standardization Sector Label Signs for cable, chassis, and warnings 4 security levels for laser products in usual.
  • Page 56 Raisecom ISCOM5508 (B) Hardware Description 7 Appendix BPDU Bridge Protocol Data Unit Connectivity Fault Management Electro Static Discharge ETSI European Telecommunications Standards Institute LLDP Link Layer Discovery Protocol MPLS Multi-protocol label switching Optical Distribution Frame Operation Administration and Maintenance Packet Transport Network...
  • Page 57 Raisecom ISCOM5508 (B) Hardware Description 7 Appendix Uninterruptible Power Supply Raisecom Technology Co., Ltd.
  • Page 58 Address Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-82883305 Fax: 8610-82883056 http://www.raisecom.com Email: export@raisecom.com...
