11.2.1

"F-RUN" LED

The following table shows the states of the "F-RUN" LED.
LED status
Flashing se-
quence
Red, slowly
flashing
Red, rapidly
flashing
Green, rapidly
flashing
Red
Green, rapidly
flashing
Green, slowly
flashing
Off
11.2.2

"F-ERR" LED

The following table shows the states of the "F-ERR" LED.
LED status
Flashing se-
quence
Red
Yellow, rapidly
flashing
Red, slowly
flashing
Yellow
Green, slowly
flashing
Green
Meaning
Device identification for memory module ID query.
Device identification for parameterization.
Firmware update, do not switch the device off.
• Device booting up/initializing
• Device in parameterization state
• STO drive safety function is active
• Critical fault (cannot be acknowledged)
• Device in the operating state with one or more of the following
constraints:
– The safety card controls inverters
– Test mode
Acceptance of the assembly has not yet taken place.
Device off.
Priority Meaning
- Device identification for memory module ID query.
1 Critical fault, cannot be acknowledged.
2 Encoder fault muting.
3 • Fault can be acknowledged
• Fault outside of the device, cabling system fault
• Reaction to limit value overshoot active
4 Warning:
• Error connection basic device
• Firmware update, do not switch the device off.
5 Error in the operating state "Parameterization":
• Error in parameterization
• No parameterization exists
• Current parameter set not consistent with the
memory module
• Inconsistent parameterization
6 Fault-free operation.
®
