Data exchange with higher-level controller
9

F-process input data

9.4 F-process input data
34
Manual – MOVISAFE
Byte Bit Name
0 0 STO1
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Warning
7 Fault
status
1 0 Reserve
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Reserve
7 Reserve
2 0 Reserve
1 Reserve
2 SSx1
3 SSx2
4 Reserve
5 Reserve
6 Reserve
7 Reserve
®
CSB51A Safety Option
Value Description
0 STO is not active. Safe disconnection of the drive is
not active.
1 STO signals the status "STO active". Status internal
output F-DO_STO is disabled.
0 CSB51A does not signal warning
1 CSB51A signals warning
0 CSB51A is in fault-free operation.
1 At least one fault at the CSB51A.
0 SSx1 is not active.
1 SSx1 is active.
0 SSx2 is not active.
1 SSx2 is active.
