9.3

F-process output data

Byte Bit Name
0
1
2
9.3.1

Substitute values

In the F-controller, all bits described as "Reserve" must be set to "0".
Data exchange with higher-level controller
Value Description
0 STO1 0
1
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Reserve
7 Fault ac- 0
knowledg-
1
ment
0 Reserve
1 Reserve
2 Reserve
3 Reserve
4 Reserve
5 Reserve
6 Reserve
7 Reserve
0 Reserve
1 Reserve
2 SSX1 0
1
3 SSX2 0
1
4 Reserve
5 Reserve
6 Reserve
7 Reserve
Activate STO.
Deactivate STO.
No acknowledgment.
Fault acknowledgment (0 → 1 edge).
Activate SSx1.
Deactivate SSx1.
Activate SSx2.
Deactivate SSx2.
