Data exchange with higher-level controller
9
F-periphery access of the safety option in the TIA Portal
PASS_ON
ACK_NEC
ACK_REI
ACK_REQ
PASS_OUT
QBAD
DIAG
32
Manual – MOVISAFE
Address Symbolic
Variables that DBX2.0
can be read
in by the user.
DBX2.1
DBX2.2
DBX2.3
DBB3
With the PASS_ON variable, you can activate a passivation of the safety option. Pas-
sivation of the F-periphery takes place, provided that PASS_ON = "1".
After resolving an error, the safety option is reintegrated depending on the setting of
the variable ACK_NEC.
• ACK_NEC = 0: Automatic reintegration occurs.
• ACK_NEC = 1: Automatic reintegration occurs following acknowledgment by the
user.
WARNING
Disallowed parameterization of the variable ACK_NEC = 0.
Severe or fatal injuries
• The parameterization of the variable ACK_NEC = 0 is permitted only if automatic
reintegration is safe for the process in question.
• Check if automatic reintegration is permitted for the process in question.
In order to reintegrate the safety option after the fault has been corrected, user ac-
knowledgment with positive edge at the variable ACK_REI is required. Acknowledg-
ment is only possible if variable ACK_REQ = 1.
The F control system sets ACK_REQ = 1 after all faults in the data exchange with the
safety option have been corrected. After successful acknowledgment, the F control
system sets ACK_REQ to "0".
The variable PASS_OUT indicates whether there is a passivation of the safety option.
Substitute values are output.
Fault in the data exchange with the safety option. Indicates passivation. Substitute val-
ues are output.
For service information purposes, the variable DIAG supplies non-failsafe information
about faults that have occurred in the F control system. For further information, refer to
the relevant F control system manual.
®
CSB51A Safety Option
Data
name type
(Variable)
"F00008_198" BOOL
(PASS-OUT)
"F00008_198" BOOL
(QBAD)
"F00008_198" BOOL
(ACK_REQ)
"F00008_198" BOOL
(IPAR_OK)
"F00008_198" BYTE
(DIAG)
Function Preset-
ting
Run passivation. 1
1: Substitute values 1
are output.
1: Acknowledgment 0
required for reintegra-
tion
Variable for repara- 0
meterization (not sup-
ported by the safety
option).
Service information -
