UG-500

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
2 C1, C2
1 C3
3 C4, C5
1 C6
1 C12
4 C7, C8, C9, C10, C11
1 D1
1 JP1
2 JP2, JP3
2 J1, J2
2 J3, J11
6 J5, J6, J7, J8 ,J9, J10
1 R1
1 R2
1 R3
3 R5, R6, R7
4 R8, R13, R14, R15
3 R10, R11, R16
1 R17
1 R18
20 TP1 to TP20
1 U1
1 U2
1 U3A
Description
Capacitors, MLCC, 1 μF, 10 V, 0805, X7R
Capacitor, MLCC, 10 μF, 25 V, 0805, X5R
Capacitors, MLCC, 22 μF, 6.3 V, 1206, X5R
Capacitor, MLCC, 100 nF, 16 V, 0402, X7R
Capacitor, MLCC, 10 nF, 16 V, 0402, X7R
Capacitors, size 1206
Red LED 2.2 mm × 1.4 mm
Connector header, 3 pins × 1 pin
Connector headers, 10 pins × 2 pins
Terminal block PCB connector, 4 position
Connector headers, 3 pins × 1 pin
Connector headers, 2 pins × 1 pin
Resistor, 56 kΩ, 1%, 0805, SMD
Resistor, 100 kΩ, 1%, 0805, SMD
Resistor, 3296 - 3/8 " Square Trimpot Trimming Potr 50k
Resistors, 0805, SMD, no assembly
Resistors, 1.5 kΩ, 1%, 0805, SMD
Resistors, 0 Ω, 1%, 0805, SMD
Resistor, 470 Ω, 1%, 0805, SMD
Resistor, 0.150 Ω, 1%, 0805, SMD
Test point, test header, 1.0 mm hole
ADP1720 50 mA high voltage, micropower
linear regulator, 8-lead MSOP
ADP5062 Linear Li-Ion Battery Charger with Power
Path and USB Compatibility in LFCSP
2
8-bit I C-bus I/O port with reset
Rev. 0 | Page 12 of 15
Evaluation Board User Guide
Manufacturer/Vendor
Murata
Murata
Murata
Murata
Murata
Not assembled
Toshiba or equivalent
Sullins Electronics
Not assembled
Tyco Electronics
Sullins Electronics
Sullins Electronics
Vishay or equivalent
Panasonic
Burns or equivalent
Not applicable
Vishay or equivalent
Vishay or equivalent
Vishay or equivalent
Rohm
Vero Technologies
Analog Devices, Inc.
Analog Devices, Inc.
NXP
Vendor P/N
GRM21BR71A105KA01
GRM21BR61E106MA73
GRM31CR60J226ME19
GRM155R71C104KA88
GRM15XR71C103KA86
Not assembled
TLRF1060(T18)
PEC36SAAN
Not assembled
282836-4
PEC36SAAN
PEC36SAAN
CRCW080556K0FKEA
ERJ-6ENF1003V
3296 W - 1 - 503 LF
Not applicable
CRCW08051K50FKEA
CRCW08050000Z0EA
CRCW0805470RFKEA
MCR10EZHFLR150
20-2137
ADP1720ARMZ-R7
ADP5062
PCA9557PW,112
