Keypad connector (KEYPAD1)

USB Connector

C-16
Pin Signal
1 GND
2 KSO(9)
3 KSO(10)
4 KSI(0)
5 KSI(1)
6 KSI(2)
7 KSI(3)
8 KSI(4)
9 KSI(5)
10 KSI(6)
Pin Description Pin
1A GND 1B
2A USBP0+ 2B
3A USBP0- 3B
4A GND 4B
Pin Signal
11 KSI(7)
12 KSO(0)
13 KSO(1)
14 KSO(2)
15 KSO(3)
16 KSO(4)
17 KSO(5)
18 KSO(6)
19 KSO(7)
20 KSO(8)
Description
5V Fuse
USBP1+
USBP1-
GND
