AHIP6+ Manual

Flat Panel Connector (FPNL1 and FPNL2)

Backlight Inverter Connector (DCINV1)

C-8
Pin Signal Pin
1 GND 31
2 SHFCLK 32
3 GND 33
4 LP 34
5 FLM 35
6 GND 36
7 P(16) 37
8 P(17) 38
9 P(18) 39
10 P(19) 40
11 GND 41
12 P(20) 42
13 P(21) 43
14 P(22) 44
15 P(23) 45
16 GND 46
17 P(8) 47
18 P(9) 48
19 P(10) 49
20 P(11) 50
21 GND 51
22 P(12) 52
23 P(13) 53
24 P(14) 54
25 P(15) 55
26 GND 56
27 P(0) 57
28 P(1) 58
29 P(2) 59
30 P(3) 60
Pin Signal
1 +12V (switched)
2 +12V (switched)
3 Undefined Voltage
4
ENABKL (thru 10K
5 Undefined Voltage
6 Undefined Voltage
7 GND
8 GND
Signal
GND
P(4)
P(5)
P(6)
P(7)
GND
M
VCCSW
VCCSW
+5V
+5V
PANEL_LOGIC
PANEL_LOGIC
+3.3V_CPU
+3.3V_CPU
GND
FPSEL(0)
FPSEL(1)
FPSEL(2)
FPSEL(3)
+12V
NC(Note 1)
ENAVEE
POT_DQ
POT_CLK
POT_RST*
TEMP_RST*
ENAVDD
ENABCK
RESET*
9
res
