Xycom AHIP6+ Manual page 53

Appendix C – Pinouts
'A' denotes the lower connector (LPT1) and 'B' denotes the upper con-
nector (COM2, RS-232). This connector also contains the remote system
reset option The reset jumper (J1) must be in position B for this option to
work. The PB_RESET* pin must be switched to GND to reset the entire
board.
C-3
Pin Signal
16A INIT
17A SELIN
18A GND
19A GND
20A GND
21A GND
22A GND
23A GND
24A GND
25A GND
Note
Pin Signal
16B NC
17B NC
18B NC
19B NC
20B DTR2
21B NC
22B RI2
23B NC
24B NC
25B NC
