Appendix B– Video Modes

Introduction

Appendix B defines the video modes and the panels the AHIP6+ supports.

Video Modes

The Chips & Technologies 69000 VGA controller supports many standard, VESA,
and extended modes. The following tables list the standard and extended video
modes and whether they passed, failed or are not supported with the CRT, TFT active
color, or STN passive color displays.

Standard Modes

Mode VESA
IBM mode
00
01
02
03
04
05
06
07
0D
0E
0F
10
11,20
12
13
- = Not supported by BIOS
1
= Execute the VESA.EXE device driver to initiate VESA modes.
B-1
Number Pixels
1
of colors
- 16/256 320x200
- 16/256 320x350
- 16/256 640x200
- 16/256 640x200
- 4/256 320x200
- 4/256 320x200
- 2/256 640x200
- mono 720x350
- 16/256 320x200
- 16/256 640x200
- mono 640x350
- 16/256 640x350
- 2/256 640x480
- 16/256 640x480
- 256/256 320x200
Display CRT TFT
mode
text OK OK
text OK OK
text OK OK
text OK OK
graphics OK OK
graphics OK OK
graphics OK OK
text OK OK
graphics OK OK
graphics OK OK
graphics OK OK
graphics OK OK
graphics OK OK
graphics OK OK
graphics OK OK
STN
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
