Appendix C – Pinouts

Internal Keyboard Connector (KYBD1)

PS/2 Keyboard/Mouse Connector (KBMS1)

If the touchscreen controller is using the mouse port, this interface will
not be available.

Internal Floppy Connector (FDD1)

C-9
Pin Signal
1 KB_CLK
2 GND
3 KB_DATA
4 5VFUSE
5 SPEAKER
Note
Pin Signal Pin
1A KB_DATA 1B
2A NC 2B
3A GND 3B
4A 5VFUSE 4B
5A KB_CLK 5B
6A NC 6B
Pin Signal
1 +5V
2 IDX*
3 +5V
4 FDS1*
5 +5V
6 DCHG*
7 NC
8 NC
9 NC
10 MO1*
11 NC
12 FDIRC*
13 NC
Signal
AUX_DATA
NC
GND
5VFUSE
AUX_CLK
NC
Pin Signal
14 FSTEP*
15 GND
16 FWD*
17 GND
18 FWE*
19 GND
20 FTK0*
21 GND
22 FWP*
23 GND
24 FRDD*
25 GND
26 FHS*
