AHIP6+ Manual

FPGA Program Connector (J15)

DCIN1 Power Connector (PWR1)

-5V is not provided by the power supplies and will have to be created on
the backplane board.
C-4
Pin Signal
1 +5V
2 SDO*
3 SDI*
4 ISPEN*
5 NC
6 MODE*
7 GND
8 SCLK*
Pin Signal
1 GND
2 GND
3 NC
4 +5V
5 +5V
6 +5V
Note
