Chapter 1 Introduction

Product Overview

The Xycom Advanced High-Integration Platform (AHIP6+) board is designed ex-
pressly for use in Xycom's line of flat panel industrial personal computers. The
AHIP6+ is optimized in design, layout, and features for use with flat panel computer
systems. This integrated design approach allows Xycom industrial PC/ATs to incor-
porate "Big PC" features in an extremely compact package. These "Big PC" features
include "industry first" PCI/ISA expansion, Pentium CPU, full-size hard disk, status
LEDs, infrared port, and integrated touchscreen.

Module Features

·
Supports
·
32 MB - 256 MB DRAM DIMMs
·
PCI local bus XGA graphics with 2 MB integrated SDRAM
·
PCI fast IDE controller
·
Two 16550-compatible serial ports
·
Centronics-compatible parallel port
·
PCI and PC/AT™ expansion
·
Floppy Controller (only one floppy supported)
·
Touchscreen interface (COM 2 or PS/2 mouse port)
·
PS/2 keyboard port
·
Real time clock and battery
·
Disk on a chip supported (DOC 2000)
100 MHz front side bus (350 MHz and above)
·
· Intel Celeron® processor
® II
· Pentium or Pentium
· Up to 1024x768\256 colors non-interlaced
· 640x480x256K, 800x600x64K, 1024x768x256 color TFT panels
· COM 1 is RS-232, or RS-485
· COM 2 is RS-232 port, or Infrared (IR or IrDA), or Touchscreen
· internal FFC connector
· external connector
III®
processors
