Incompatible
or irregular
application,
which may
increase risk
of roll-out.
NO.
Two or more
snap hooks or
carabiners
connected to
each other.
NO.
Correct Anchorage Positioning:
This chart details allowable working zones required
to reduce risk of swing falls and improper side loading.
ALWAYS adhere to information specified by chart.
Anchor Distance
Working Distance
From
Along Roof Edge
Leading Edge (Y)
(Either Direction) (X)
6'
10'
9' - 9"
15'
11' - 7"
13' - 3"
20'
25'
14' - 6"
30'
16'
35'
17' - 2"
40'
18' - 3"
45'
19' - 4"
50'
19' - 10"
55'
21' - 4"
60'
22' - 3"
For example, if the anchorage connector is 6' from the leading
edge (Y), the working distance (X) is 8' in each direction from
the perpendicular, which translates to a 53° working angle.
Components and Specifications
Materials: galvanized steel.
3
Working Angle
From
Perpendicular (Ø)
8'
53°
45°
38°
33°
30°
28°
26°
24°
23°
21°
21°
21°
Connection
Point
Ø: Total Working Angle
X: Working Distance
Along Leading Edge
Y: Distance From
Leading Edge
Y
X
Leading Edge
Central
Frame
Member (6)
Connector
directly to
horizontal
lifeline.
NO.
ø
X
Frame
Weighted
Pad (12)
