Product Name: CB-18 Anchor
Part #: 00652; 00654; 00656; 00657; 00658; 00659; 10652; 10655; 10656; 10683
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
1
1
2
2
3 - 4
4
5 - 7
7
8
8
9
10
Advertisement
Table of Contents
Related Manuals for Guardian Fall Protection CB-18 Anchor
Summary of Contents for Guardian Fall Protection CB-18 Anchor
-
Page 1: Table Of Contents
Product Name: CB-18 Anchor Part #: 00652; 00654; 00656; 00657; 00658; 00659; 10652; 10655; 10656; 10683 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications... -
Page 3: Introduction
Distributed by: BEST MATERIALS ® Ph: 800-474-7570, 602-272-8128 www.BestMaterials.com Email: Sales@BestMaterials.com Introduction Thank you for purchasing a Guardian Fall User Information Protection CB-18. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA Date of First Use: or any applicable state agency. -
Page 4: Worker Classifications
Worker Classifications Understand the following definitions of those who CAUTION work near or who may be exposed to fall hazards. Qualified Person: A person with an accredited degree or certification, and with extensive experience or sufficient professional standing, who is considered proficient in planning and reviewing the conformity of fall protection and rescue systems. -
Page 5: Limitations
Limitations Fall clearance calculation shown based on standing worker falling directly in-line with anchor point. Fall Clearance: There must be sufficient Always consider potential swing fall and other clearance below the anchorage connector hazards when calculating fall clearance. to arrest a fall before the user strikes the ground or an obstruction. -
Page 6: Components And Specifications
CB-18 Backer Plate #00658 18” 12” x 12” CB-18 Anchor w/Pass-Through Top for Concrete Applications #00657 #00654 18” 16” x 16” CB-18 Anchor for Wood & Metal Applications #00659 18” 16” x 16” CB-18 Anchor w/Pass-Through Top for Wood & Metal Applications... -
Page 7: Installation And Use
Installation and Use All installation of CB-18 Anchors MUST be approved by a Competent or WARNING Qualified Person, or by a Guardian Fall Protection certified installer. MINIMUM substrate thickness requirements: Substrate fastener requirements: • Wood: 3/4” CDX. • Wood: #14 x 10, 2” wood deck screws. Qty. 60. - Page 8 Distributed by: BEST MATERIALS ® Ph: 800-474-7570, 602-272-8128 www.BestMaterials.com Email: Sales@BestMaterials.com Metal Install (part #s 00654, 00657, and 00659): MINIMUM substrate requirement: 18 gauge, or 20 gauge if reinforced with CB Spanner Plate (part # 00604, contact All fasteners penetrate Guardian for more information).
-
Page 9: Maintenance, Cleaning, And Storage
Installation, CB-18 Weld-On (part # 10652, 10655, and 10656) CB-18 Weld-On Post must be installed by an American Welding Society (AWS) certified welder in accordance with all applicable welding regulations. Post diameter: 2 7 / 8 ” Welding must Fillet weld: 5/16” be done by AWS certified welder Minimum beam flange width: 3½”... -
Page 10: Inspection
Inspection Prior to EACH use, inspect CB-18 for deficiencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating, alteration, and missing or illegible labels. IMMEDIATELY remove CB-18 from service if defects or damage are found, or if exposed to forces of fall arrest. -
Page 11: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 12: Labels
Labels CB-18 Anchor Prior to use, read and understand all manufacturer’s instructions provided with equipment at time of shipment. Part #: Materials: Galvanized steel Type A anchorage connector. 1-800-466-6385 5,000 lb. MBS (minimum breaking strength). www.guardianfall.com Date of Manufacture: Minimum service temperature: -30° F.
