Product Name: CB-1-W Anchor
Part #: 00610
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction
Applicable Safety Standards
Worker Classifications
Product Specific Applications
Limitations
Components and Specifications
Installation and Use
Maintenance, Cleaning, and Storage
Inspection
Inspection Log
Safety Information
Labels
1
1
1
2
3 - 4
4
4 - 5
5
5
6
6 - 7
7
Advertisement
Related Manuals for Guardian Fall Protection CB-1-W
Summary of Contents for Guardian Fall Protection CB-1-W
- Page 1 Product Name: CB-1-W Anchor Part #: 00610 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations 3 - 4 Components and Specifications Installation and Use...
- Page 2 CB-1-W Anchors do not comply with CalOSHA section 3291 (f) for roof tie-back/suspension anchorages, which are required on all buildings in California above 36’ (or three stories), with certain rare exceptions.
- Page 3 Maximum 1 attachment per connection point. Personal Fall Arrest: CB-1-W Anchors may be used to support a MAXIMUM 1 personal fall arrest system (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lb., or achieve a minimum 2:1 safety factor, as...
- Page 4 Swing falls significantly increase the likelihood of serious injury or death in the event of a fall. Compatibility: When making connections with CB-1-W, eliminate all possibility of roll-out. 5’ 2’ Roll-out occurs when interference between a...
- Page 5 2. Eliminate or minimize all risk of swing fall. 3. Ensure structure to which CB-1-W is to be installed, and on which work is to be performed, is free of all hazards, including, but not limited to, debris, rot, rust, sharp or abrasive edges and surfaces, and hazardous...
- Page 6 4. A Qualified Person must determine that structure to which CB-1-W is to be installed is rated to withstand minimum required loads. There are no minimum or maximum spacing requirements for CB-1-W Anchors, provided structure is of sufficient strength. 5. CB-1-W must be installed by an American Welding Society (AWS) certified welder in accordance with all applicable welding regulations.
- Page 7 12 months. Competent Person to inspect and initial. This inspection log must be specific to one CB-1-W. Separate inspection logs must be used for each CB-1-W. All inspection records must be made visible and available to all users at all times.
- Page 8 Physical harm may still occur even if fall safety equipment functions correctly. Sustained post-fall suspension may result in serious injury or death. Use trauma relief straps to reduce the effects of suspension trauma. Labels guardianfall.com CB-1-W Anchor • Part #: 00610 DOM: Serial #: Prior to use, read and understand all manufacturer’s instructions.
