Summary of Contents for Guardian Fall Protection Beamer 2000
-
Page 1: Table Of Contents
Product Name: Beamer 2000 Part #: 00101; 00103 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations Components and Specifications Installation and Use... -
Page 2: Introduction
Introduction Thank you for purchasing a Guardian Fall Protection Beamer 2000. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or any applicable state agency. This and any other included instructions must be made available to the user of the equipment. The user must understand how to safely and effectively use the Beamer 2000, and all fall safety equipment used in combination with the Beamer 2000. -
Page 3: Product Specific Applications
Maximum 1 attachment per connection point. Personal Fall Arrest: Beamer 2000 may be used to support a MAXIMUM 1 personal fall arrest system (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lbs. -
Page 4: Components And Specifications
All connections must be selected and deemed compatible with Beamer 2000 by a Competent Person. All connector gates must be self-closing and self-locking, and withstand minimum loads of 3,600 lbs. -
Page 5: Installation And Use
Prior to installation, plan your system: 1. Beamer 2000 is an adjustable anchorage connector, and is designed for use both overhead and at foot level. If used below the harness dorsal D-ring in Fall Arrest applications, ALWAYS account for increase in required fall clearance, and ALWAYS use PFAS equipment explicitly certified for extended free fall up to 12’. -
Page 6: Maintenance, Cleaning, And Storage
Cleaning after use is important for maintaining the safety and longevity of Beamer 2000. Remove all dirt, corrosives, and contaminants from Beamer 2000 before and after each use. If Beamer 2000 cannot be cleaned with plain water, use mild soap and water, then rinse and wipe dry. NEVER clean Beamer 2000 with corrosive substances. -
Page 7: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 8: Labels
Labels Beamer Anchor Part #: WARNING! READ CAREFULLY BEFORE USING MANUFACTURER’S INSTRUCTIONS INCLUDED AT TIME OF SHIPMENT MUST BE FOLLOWED AT ALL TIMES FOR PROPER USE, MAINTENANCE, AND INSPECTION. ALTERATION, ABUSE , OR MISUSE OF THIS PRODUCT MAY RESULT IN SERIOUS INJURY OR DEATH. - Page 9 Product Name: Beamer BBC Part #: 00125; 00127; 00130; 00135 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations Components and Specifications Installation and Use Maintenance, Cleaning, and Storage Inspection Inspection Log...
-
Page 10: Introduction
Introduction Thank you for purchasing a Guardian Fall Protection Beamer BBC. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or any applicable state agency. This and any other included instructions must be made available to the user of the equipment. The user must understand how to safely and effectively use the Beamer BBC, and all fall safety equipment used in combination with the Beamer BBC. -
Page 11: Product Specific Applications
Product Specific Applications Use of equipment in unintended applications may result in serious WARNING injury or death. Maximum 1 attachment per connection point. Personal Fall Arrest: Beamer BBC may be used to support a MAXIMUM 1 personal fall arrest system (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lbs. -
Page 12: Components And Specifications
Compatibility: When making connections with Beamer BBC, eliminate all possibility of roll-out. Roll-out occurs when interference between a hook and the attachment point causes the hook gate to unintentionally open and release. All connections must be selected and deemed compatible with Beamer BBC by a Competent Person. -
Page 13: Installation And Use
Installation and Use Part # 00125: Maximum flange width: 8” - 18“. Maximum flange thickness: 2.5”. Part # 00127: Maximum flange width: 8” - 18“. Maximum flange thickness: 2.5” - 4”. Part # 00130: Maximum flange width: 12” - 24“. Maximum flange thickness: 2.5”. Part # 00135: Maximum flange width: 12”... -
Page 14: Maintenance, Cleaning, And Storage
Maintenance, Cleaning, and Storage If Beamer BBC fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair. Field serviceability testing is not required, and should not be done by the end user. -
Page 15: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 16: Labels
Labels Beamer BBC Part #: WARNING! READ CAREFULLY BEFORE USING MANUFACTURER’S INSTRUCTIONS INCLUDED AT TIME OF SHIPMENT MUST BE FOLLOWED AT ALL TIMES FOR PROPER USE, MAINTENANCE, AND INSPECTION. ALTERATION, ABUSE , OR MISUSE OF THIS PRODUCT MAY RESULT IN SERIOUS INJURY OR DEATH. - Page 17 Product Name: Beamer Trolley Anchor Part #: 00215 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations Components and Specifications Installation and Use Maintenance, Cleaning, and Storage Inspection Inspection Log...
-
Page 18: Introduction
Introduction Thank you for purchasing a Guardian Fall User Information Protection Beamer Trolley Anchor. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or Date of First Use: any applicable state agency. -
Page 19: Limitations
Restraint: Beamer Trolley Anchor may be used in Restraint applications. Restraint systems prevent workers from reaching the leading edge of a fall hazard. Always account for fully deployed length of lanyard/SRL. Structure must withstand loads applied in the directions permitted by the system of at least 1,000 lbs. -
Page 20: Components And Specifications
Application Two connectors that places to same load on gate. D-ring. Incompatible or irregular Connector directly to application, horizontal which may increase risk lifeline. of roll-out. Correct Anchorage Positioning: This chart details allowable working zones required to reduce risk of swing falls and improper side loading. ALWAYS adhere to information specified by chart. -
Page 21: Installation And Use
Installation and Use Compatible beam flange width: 3” - 10”. Maximum beam flange thickness: 9/10”. Prior to installation: 1. Ensure all PFAS equipment is selected and deemed compatible with Beamer Trolley Anchor by a Competent Person. Make considerations for eliminating or minimizing swing fall hazards. 2. -
Page 22: Maintenance, Cleaning, And Storage
Maintenance, Cleaning, and Storage If Beamer Trolley Anchor fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair. Field serviceability testing is not required, and should not be done by the end user. Cleaning after use is important for maintaining the safety and longevity of Beamer Trolley Anchor. -
Page 23: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 24: Labels
Labels INSPECTION GRID User must inspect prior to EACH use. Beamer Trolley Anchor Competent Person must complete formal inspection every 6 months. Competent Part #: 00215 Person to inspect and initial. DOM: Serial #: Date of First Use: ________________ Product lifetime is indefinite as long Prior to use, read and understand as equipment passes pre-use and all manufacturer’s instructions provided...
