Connector
closed and
locked to
D-ring. OK.
Two or more
snap hooks or
carabiners
connected to
each other. NO.
Two connectors
to same
D-ring. NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out. NO.

Components and Specifications

Materials: steel, polyester or nylon, and steel polyolefin.
Lifeline diameter: 5/8".
Average arrest force: 900 lbs.
Maximum arrest force: 1,800 lbs.
Maximum deployment: 48".
Part # Length
01310 25'
01320 50'
01323 75'
01324 100'
01325 130'
01326 150'
01327 200'
11318 30'
11320 50'
11329 25'
11330 30'
11331 50'
11332 75'
11333 100'
11334 150'
3
Fall Arrester with
Extension Lanyard
Snap Hook
Description
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, & 18" Lanyard Extension
No Tangle VLA w/Swivel Snap Hook, Shock Absorber, Positioning Device, & 18" Lanyard Extension
No Tangle VLA w/Swivel Snap Hook, Shock Absorber, Positioning Device, & 18" Lanyard Extension
Polydac Rope w/Snap Hook End
Polydac Rope w/Snap Hook End
Polydac Rope w/Snap Hook End
Polydac Rope w/Snap Hook End
Polydac Rope w/Snap Hook End
Polydac Rope w/Snap Hook End
Connector
to integral
lanyard.
NO.
Connector
directly to
webbing.
NO.
Application
that places
load on gate.
NO.
Connector
directly to
horizontal
NO.
lifeline.
Rope Lifeline
Shock
Absorber
