Page 1: Table Of Contents
Product Name: G-Bolt Part #: 00235 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations 2 - 3 Components and Specifications Installation and Use Maintenance, Cleaning, and Storage Inspection Inspection Log... -
Page 2: Introduction
Introduction Thank you for purchasing a Guardian Fall Protection G-Bolt. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or any applicable state agency. This and any other included instructions must be made available to the user of the equipment. The user must understand how to safely and effectively use the G-Bolt, and all fall safety equipment used in combination with the G-Bolt. -
Page 3: Product Specific Applications
Product Specific Applications Use of equipment in unintended applications may result in serious WARNING injury or death. Maximum 1 attachment per connection point. Personal Fall Arrest: G-Bolt may be used to support a MAXIMUM 1 personal fall arrest system (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lbs. -
Page 4: Components And Specifications
Compatibility: When making connections with G-Bolt, eliminate all possibility of roll-out. Roll-out occurs when interference between a hook and the attachment point causes the hook gate to unintentionally open and release. All connections must be selected and deemed compatible with G-Bolt by a Competent Person. All connector gates must be self-closing and self-locking, and withstand minimum loads of 3,600 lbs. -
Page 5: Installation And Use
Installation and Use MINIMUM concrete thickness requirements: • If installation location is between 6”-12” from any edge/corner: 12” thick, 3,000 psi. • If installation location is greater than 12” from any edge/corner: 6” thick, 3,000 psi. • Do not install if installation location is less than 6” from any edge/corner. •... -
Page 6: Maintenance, Cleaning, And Storage
Maintenance, Cleaning, and Storage If G-Bolt fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair. Field serviceability testing is not required, and should not be done by the end user. Cleaning after use is important for maintaining the safety and longevity of G-Bolt. -
Page 7: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 8: Labels
Labels Compliant with ANSI Z359.18-17, ANSI A10.32-12, OSHA 1910, & OSHA 1926 Subpart M. Type A anchorage connector. www.guardianfall.com Capacity: 130-420 lbs. (including all equipment). G-Bolt Anchor 5,000 lb. MBS (min. breaking strength). Part #: 00235 Min. service temp.: -30º F. Maximum 1 connection.
