Page 1 SERVICE MANUAL A4 Full Color Laser Printer EPSON AcuLaser C2800/C2800D C3800/C3800D Confidential SEPG06001...
Page 2 Notice: The purpose of this manual is to provide the product knowledge and the technical information required for repair or maintenance of EPSON AcuLaser C2800/C2800D/C3800/ C3800D. All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means electronic, mechanical, photocopying, or otherwise, without the prior written permission of SEIKO EPSON CORPORATION.
Page 3 Indicates an operating or maintenance procedure, practice or Manual Configuration condition that, if not strictly observed, would result in injury or loss of life. This manual consists of the following seven chapters: Indicates an operating or maintenance procedure, practice or condition that, if not strictly observed, could result in injury or loss CHAPTER 1 PRODUCT DESCRIPTIONS of life.
Page 4 Location of Safety Equipment Safety Safety-related Symbols Indicates an operating or maintenance procedure, practice or condition that, if not strictly observed, would result in injury or loss of life. Indicates an operating or maintenance procedure, practice or condition that, if not strictly observed, could result in injury or loss of life.
Page 5 Safety System Wiring Schematic Confidential...
Page 6 Laser Specifications Maximum output power 5 mV Safety-related Label (Caution Label)/Laser Opening Location Wavelength (AcuLaser C2800/C2800D) 770 nm ~ 800 nm Wavelength (AcuLaser C3800/C3800D) 785 nm Handling Precautions Disassembling and adjustment procedures not specified herein may result in hazardous radiation exposure.
Page 7 Never modify the safety equipment or replace it with part not approved by EPSON. Doing so may cause the safety functions to stop working properly, and may result in fire or injury. Do not connect any other devices to the electrical outlet supplying Never modify the product.
Page 8 Do not use vacuum cleaner for home use to clean up spills of Before performing repair and maintenance work, read and powdered toners. The very fine particles can cause fire/explosion. understand the documents of the product (e.g. service manual). Sweep them thoroughly with a broom or wipe them with a cloth Be sure to follow the specified steps and use the prescribed tools moistened with neutral detergent.
Page 9 November 8, 2006 Revision up: Chapter 1 Over view(p14) / Printer Specifications(P15) / Dimensions and weight(P18) / Supported papers(P20) / External interfaces(P25) Some items were revised. October 16, 2007 Revision up: All Chapter Information on AcuLaser C2800/C2800D has been added. Confidential...
Page 10: Table Of Contents
Contents Chapter 1 PRODUCT DESCRIPTION 2.5.7 Drive ....................... 52 2.5.8 Electrical ....................53 1.1 Overview ......................14 2.5.9 Duplex..................... 55 1.2 Product Specifications ..................15 2.5.10 550 Paper Feeder .................. 56 1.2.1 Basic Specifications................. 15 2.6 Mode ........................59 1.2.2 Paper Specifications ................21 2.6.1 Operating Modes..................
Page 11 Chapter 3 TROUBLESHOOTING Chapter 4 DISASSEMBLY/REASSEMBLY 3.1 Procedure for Troubleshooting................77 4.1 Preliminary Check ................... 160 3.1.1 Procedure for Troubleshooting..............77 4.1.1 Required Tools..................160 3.1.2 Preliminary Check ................... 77 4.1.2 Prohibited Disassembly ................ 160 3.1.3 Precautions in Performing Troubleshooting Work........78 4.2 Major Reassembly Unit ...................
Page 12 Chapter 5 ADJUSTMENT 5.1 Adjustment Items....................382 5.2 Adjustment ....................... 383 5.2.1 Adjusting Color Registration Alignment (Auto) ........383 5.2.2 Adjusting Color Registration Alignment (Manual)....... 384 5.2.3 Writing USB ID..................385 5.2.4 MCU Maintenance Program..............387 Chapter 6 MAINTENANCE 6.1 Consumable Products/Products that Require Periodic Replacement ....390 6.2 Cleaning......................
Page 13 C H A P T E R PRODUCT DESCRIPTION Confidential...
Page 14: Overview
AcuLaser C2800D/C3800D has a duplex unit as part of its standard equipment, whereas the unit is available as an optional device for AcuLaser C2800/C3800. Listed below are the features of AcuLaser C2800/C2800D/C3800/C3800D: Prints on A4 paper (User defined paper size: 76.20 x 98.40 mm ~ 220 x 355.6 mm)
Page 15: Product Specifications
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 1.2 Product Specifications Life 300,000 pages or five years, whichever comes first MPBF 150,000 pages 1.2.1 Basic Specifications Durability Average: 2,000 pages / month Max.: 60,000 pages / month PRINTER SPECIFICATIONS Serviceability MTTR : Less than 30 minutes (average)
Page 16 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Safety and Safety standards <120 V> <120 V> regulations AcuLaser C2800/C2800D AcuLaser C2800/C2800D • 2006/95/EC EN60950-1 • EN55022, Class B • EN60825-1 • EN55024 (IEC61000-4-2/IEC61000-4- 3/IEC61000-4-4/IEC 61000-4-11) • CNS14336 • CNS13438 Class B AcuLaser C3800/C3800D AcuLaser C3800/C3800D •...
Page 17 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C *1 : Conditions: A4, plain paper, continuous printing The values vary depending on paper type and size. *2: Less than 30 seconds from sleep mode. *3: Paper feeder = MP tray, Paper size = A4 *4 : Main unit only.
Page 18 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C EXTERNAL VIEW AND PART NAMES Table 1-1. Part Names Name Name Name Control panel I/F cover Ethernet interface connector MP tray (Multi-Purpose tray) Power switch AC inlet Standard lower paper cassette Output tray extension Paper cassette cover (optional)
Page 19 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C DIMENSIONS AND WEIGHT The following figure shows the dimensions and weight of the printer. NOTE 1 : Manufacturing tolerance is ± 1% mm in dimensions and ± 1% kg in weight. 2 : Imaging cartridges are not included in the weight of the main unit.
Page 20 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C INSTALLATION SPACE REQUIREMENTS The following figure shows the dimensions of the space required around the printer. Be sure to provide the space for installation, operation, and maintenance. AcuLaser C2800/C2800D 826.5 mm AcuLaser C3800/C3800D 127.3 858 mm...
Page 21: Paper Specifications
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 1.2.2 Paper Specifications SUPPORTED PAPERS Table 1-2. Supported Papers Paper Type Feeding Assurance Capacity Paper Feeder Paper Size (Height) Type Weight Standard Paper Plain Paper Special Media Standard Standard lower Standard paper 60 ~ 105 g/m...
Page 22 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C UNSUITABLE PAPERS The following types of paper should not be used, otherwise decreased print quality, paper misfeeds, or damage to the printer may occur. Paper that has been treated, such as carbon-backed, non-carbon, heat-sensitive, pressure-sensitive, or acid paper...
Page 23 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C PRINTABLE AREA ENVELOPE ORIENTATION Maximum guaranteed print area (Printing and quality are guaranteed) ISO-B5, C5 Envelope Size Paper width: 212 mm x Length: 347.6 mm Feeding Maximum printable area (Printing is guaranteed) Direction ↑ Paper width: 215 mm x Length: 351.6 mm...
Page 24: Replacement Parts
Fuser unit: 120 V 100,000 pages 100,000 pages Fuser unit: 220 V 100,000 pages 100,000 pages The imaging cartridges of AcuLaser C2800/C2800D and AcuLaser C H E C K P O I N T C3800/C3800D are not exchangeable. PRODUCT DESCRIPTION Product Specifications...
Page 25: Controller Specifications
Included in the program Expansion Optional Flash DIMM (A slot) *1 : In AcuLaser C2800/C2800D's case, an add-on memory can be installed in the S1 slot only. Control panel 22 digits x 5 lines LCD, three LEDs, six buttons Printer setting...
Page 26 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C EXTERNAL INTERFACES Standard 1.1 (2.0FS) 1 ch 2.0 HS 1 ch Ethernet 100BaseTX/10BaseT 1 ch Option Type-B Level 3 compatible 1 slot * : AcuLaser C3800/C3800D only USB Host interface connector (1.1) (AcuLaser C3800/C3800D only) USB (2.0 HS)
Page 27: List Of Printer Messages
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 1.3 List of Printer Messages Table 1-4. List of Printer Messages Sort Display Error LED Status The following is a list of messages displayed on the printer’s control panel when Warming Up English is selected in the language option.
Page 28 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 1-4. List of Printer Messages Table 1-4. List of Printer Messages Sort Display Error LED Status Sort Display Error LED Status Service Req Cffff All flashing Duplex Mem Overflow Flashing 1 (synchronized with Invalid Data...
Page 29: Product Comparison
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 1.4 Product Comparison Table 1-5. Product Comparison Model name Table 1-5. Product Comparison AcuLaser AcuLaser C2800/C2800D C3800/C3800D Model name AC 120 V ± 10% / 50 or 60 Hz ± 3Hz Power supply AcuLaser AcuLaser AC 220 V ~ 240 V ±...
Page 30 C H A P T E R OPERATING PRINCIPLES Confidential...
Page 31: Print Process Overview
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.1 Print Process Overview This printer is a full-color laser printer that takes advantage of the principle of electrophotographic recording. This printer uses a tandem-type engine that equips exclusive drums and developer units for each yellow, magenta, cyan, and black (abbreviated to Y, M, C, and K), and prints images in full color by laying images of four colors on paper that is transferred on the transfer belt.
Page 32: Print Process Diagram
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.2 Print Process Diagram The diagram below illustrates the entire print process. Figure 2-2. Print Process Diagram OPERATING PRINCIPLES Print Process Diagram Confidential...
Page 33: Technical Explanation Of Print Process
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3 Technical Explanation of Print Process 2.3.1 Charging In charging process, BCR (Bias Charge Roll) applies a uniform negative potential to the drum which rotates at a fixed speed. This process is performed simultaneously for each of the yellow, magenta, cyan and black colors.
Page 34: Exposure
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.2 Exposure A laser beam is irradiated according to the print data (image data) sent from the printer controller. The laser beam is output only when a pixel data (minute dot In exposure process, a laser beam is applied to the negatively charged surface of the composing the print data) exists.
Page 35: Development
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.3 Development In development process, toner is electrically applied to the invisible electrostatic latent image on the drum to form a visible image on it. This process is performed simultaneously for each of the yellow, magenta, cyan and black colors.
Page 36: Transfer (Drum Æ Paper)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.4 Transfer (Drum → Paper) In transfer process, the toner images formed on the drums are transferred to a paper. Toner image is transferred in the order Y, M, C, and K. BTR (Bias Transfer Roll) is a conductive roll and is supplied high positive voltage from the HVPS.
Page 37: Cleaning (Toner Cartridge)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.5 Cleaning (Toner Cartridge) In cleaning (toner cartridge) process, remaining toner on the Drum and the BCR as well as electrical charge on the Drum are removed. Drum cleaning Cleaning blade contacts the Drum surface and scrape off remaining toner.
Page 38: Discharging
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.6 Discharging In discharging process, the charge on the paper is neutralized/removed by the Detack Saw. Detack Saw Detack Saw neutralizes/removes electrical charge of the paper so that toner transferred on the paper will not scatter over the surrounding metal parts.
Page 39: Fusing
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.3.7 Fusing 2.3.8 Cleaning (Transfer Belt) In fusing process, toner is fixed on paper by applying heat and pressure. In cleaning (transfer belt) process, remaining toner on the Transfer Belt is removed. As a complete toner image clings to a paper only by the electrostatic force, one light touch can remove the image easily.
Page 40: Paper Feed
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.4 Paper Feed 2.4.2 Paper Feed Path Layout 2.4.1 Paper Feed Path 550 Paper Feeder 550 Paper Feeder (Option) ROLL ASSY FEED ROLL ASSY FEED ROLL ASSY FEED MSI (Nuger Roll) (Nuger Roll) ROLL ASSY RETARD...
Page 41: Main Structures And Functions
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5 Main Structures and Functions 2.5.1 Paper Cassette 2.5.1.1 Part Names and Functions This section explains and illustrates the main functional components. GUIDE ASSY SIDE (R/L) The explanations are given for each of the components (section) listed below:...
Page 42 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.1.2 Multi-Feed Prevention 2.5.1.3 Bottom Plate Operation Some papers are stuck together in the paper cassette and these papers tend to cause The lock of GEAR BTM LOCK ONEWAY is released when a paper cassette is multi-feeding or paper jams.
Page 43: Paper Feeder
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.2 Paper Feeder 2.5.2.1 Part Names and Functions SWITCH ASSY SIZE Detects paper size and the presence of the paper tray. (Refer to “2.7.1 Paper Size Control (p60) ”.) SENSOR PHOTO (CST No Paper Sensor) Detects presence of papers in the paper tray according to the change in position of the Actuator No Paper.
Page 44: Msi & Regi Assy
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.3 MSI & Regi Assy 2.5.3.1 Part Names and Functions SOLENOID FEED MSI Controls the drive from DRIVE ASSY PH to ROLL ASSY FEED MSI. (Refer to “2.8.3 DRIVE ASSY PH (p70) ”.) CLUTCH ASSY PH TURN Transmits the drive from DRIVE ASSY PH to ROLL ASSY TURN.
Page 45 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.3.2 MSI Paper Detection 2.5.3.3 Multi-Feed Prevention When papers are loaded in MSI, ACTUATOR NO PAPER shields the light to MSI No Some papers are stick together in MSI and these papers tend to cause multi-feeding or Paper Sensor, and detects paper presence.
Page 46 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.3.4 Paper Edge Alignment 2.5.3.5 Regi Sensor Paper Detection If papers, which are transferred from MSI or paper tray to the toner transfer section, are As the paper path from MSI or Duplex to Regi Sensor and the one from paper tray to skewed, toner image on the drum cannot be transferred to the appropriate position on Regi Sensor are different, Regi Sensor has both Actuator A and Actuator B.
Page 47: Transfer Belt & Fuser
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.4 Transfer Belt & Fuser 2.5.4.1 Part Names and Functions FUSER UNIT The FUSER UNIT fixes the unsteady toner on paper by heat and pressure, and also transfers the paper before and after the fixing. The FUSER UNIT mainly consists of the components shown below:...
Page 48 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.4.2 TRANSFER UNIT Details The TRANSFER UNIT mainly consists of the components shown below: Transfer Belt Transfer Belt transfers paper towards FUSER UNIT. ADC Sensor ADC Sensor reads the toner patch on the Transfer Belt at the window position and converts the data to voltage value.
Page 49: Ros Assy
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.5 ROS ASSY SOS PWB SOS Sensor on SOS (Start of Scan) PWB converts input laser beam into electrical signal as a start of scanning. 2.5.5.1 Part Names and Functions This signal is used to match the start timing of a laser scanning with that of ROS ASSY image drawing.
Page 50: Xerographics
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.6 Xerographics 2.5.6.1 Part Names and Functions CONNECTOR CRUM* (CRUM Sensor) As IMAGING CARTRIDGE is attached to CRUM Sensor, the sensor contacts CRUM in IMAGING CARTRIDGE and read/write the data concerning CRUM. * : Customer Replaceable Unit Memory: stores information specific to the printer.
Page 51 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.6.2 IMAGING CARTRIDGE Detection Table 2-1. Toner Cartridge Sensor Conditions IMAGING CARTRIDGE IMAGING CARTRIDGE not inserted inserted Toner Cartridge Sensor Light blocked Light received Figure 2-28. IMAGING CARTRIDGE Detection OPERATING PRINCIPLES Main Structures and Functions Confidential...
Page 52: Chapter 1 Product Description
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.7 Drive 2.5.7.1 Part Names and Functions DRIVE ASSY MAIN Supplies the driving to the parts shown below and other parts. (Refer to “2.8.1 DRIVE ASSY MAIN (p66) ”.) Main Motor Drum (K) (included in IMAGING CARTRIDGE (K))
Page 53: Electrical
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.8 Electrical SENSOR HUM Detects temperature and humidity inside the printer and converts the values to voltage value. 2.5.8.1 Part Names and Functions CONTROL PANEL FAN MAIN Shows the printer conditions with LCD and LEDs, and operates the printer with Prevents overheating inside the printer by exhausting/inhaling the ambient air.
Page 54 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.8.2 Data Flow Reference: Forming two-dimensional print image A laser beam scans while turning on and off the beam in accordance with the electrical Print data (electric signals) from the Printer Controller follows the flow shown below signal (Video signal: Expresses image data by ups and downs of voltage) to form a line to form a print image.
Page 55: Duplex
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.9 Duplex 2.5.9.1 Part Names and Functions SENSOR PHOTO (DUP Jam Sensor) Detects that paper has been transferred to the duplex section. CLUTCH DUP Transmits drive force from MOTOR ASSY DUP to Exit Roll in FUSER UNIT.
Page 56: Paper Feeder
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.10 550 Paper Feeder 2.5.10.1 Part Names and Functions (Paper Cassette) GUIDE ASSY SIDE (R/L) The GUIDE ASSY SIDE (R/L) moves crossways of the paper feed direction, and trues up the left and right edges of sheets of paper.
Page 57 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.10.2 Multi-Feed Prevention 2.5.10.3 Bottom Plate Operation Some papers are stuck together in the paper cassette and these papers tend to cause The lock of GEAR BTM LOCK ONEWAY is released when a paper cassette is multi-feeding or paper jams.
Page 58 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.5.10.4 Part Names and Functions (Feeder) SWITCH ASSY SIZE Detects paper size and the presence of the paper tray. (Refer to “2.7.1 Paper Size Control (p60) ”.) SENSOR PHOTO (CST No Paper Sensor) Detects presence of papers in the paper cassette according to the change in position of the ACTUATOR NO PAPER.
Page 59: Mode
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.6 Mode Mode transition between each mode is shown below: 2.6.1 Operating Modes The printer has the following six operating modes: Wait Mode The printer is adjusting print image quality Ready Mode The printer is ready to print...
Page 60: Control
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.7 Control 2.7.1 Paper Size Control Paper size is defined by the position of GUIDE ASSY CST END. Status of Paper Size Switch of SWITCH ASSY SIZE varies depending on the position of GUIDE ASSY CST END, and paper size is determined by the combination of the Paper Size Switch.
Page 61: Ros Light Intensity Control
AcuLaser C2800/C2800D/C3800/C3800D Revision C The following table shows the on/off status of Paper Size Switch in the SWITCH 2.7.2 ROS Light Intensity Control ASSY SIZE according to the paper size. An image data converted to electric signals (expresses image data by ups and downs of voltage) is sent to the laser diode in the ROS ASSY, and the laser diode converts the Paper Size Switches are referred to as “SW2”, “SW1”, and “SW0”...
Page 62: Process Control
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.7.3 Process Control 2.7.3.1 Electric Potential Control To acquire stabilized print image density, drum charging voltage, developer DC In order to perform stabilized printing, it is necessary to adjust the parameters related to charging voltage, and ROS Light Intensity should be adjusted depending on the forming images on a timely basis.
Page 63 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.7.3.2 Toner Density Control 2.7.3.3 High Area Coverage Mode To acquire stabilized print images, toner density should be kept constant. The control The Toner Dispense control cannot keep up with heavy consumption of toner, such as to keep the toner density constant is called “toner density control”.
Page 64: Color Registration Control
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.7.4 Color Registration Control Overview of the control is described below. Measures the output value of the ADC Sensor when it is detecting non-toner area This printer uses a tandem-type engine that equips exclusive drums and developer units on the Transfer Belt, and determines the threshold value.
Page 65: Fuser Control
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.7.5 Fuser Control 2.7.5.1 Fuser Temperature Control The Fuser Temperature Control sets up the target temperature at all times, and turns on/ off the Heater Lamp so that the surface temperature of the Heat Roll becomes the target temperature.
Page 66: Drive Transmission Path
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.8 Drive Transmission Path 2.8.1 DRIVE ASSY MAIN DRIVE ASSY MAIN consists of Main Motor, Sub Motor, and Deve Motor. (Refer to “2.5.7 Drive (p52) ”.) The following section explains drive transmission from DRIVE ASSY MAIN to each unit by dividing the flow into two sections: development/transfer and fusing/ejection.
Page 67 AcuLaser C2800/C2800D/C3800/C3800D Revision C FULL COLOR MODE Figure 2-45. Drive Transmission Path (Development/Transfer) Figure 2-44. Drive Transmission Flow (Development/Transfer) OPERATING PRINCIPLES Drive Transmission Path Confidential...
Page 68 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSING/EJECTION FUSER ASSY The following section explains drive transmission of paper transfer to Heat Roll, and drive transmission during single-sided printing and duplex printing. DRIVE ASSY MAIN Kmy06055EA Figure 2-47. Drive Transmission Flow (Fusing/Ejection) Figure 2-46. Drive Transmission Flow (Fusing/Ejection)
Page 69: Toner Dispenser (Y, M, C, K)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.8.2 TONER DISPENSER (Y, M, C, K) TONER DISPENSER drive force drives Agitator and Auger inside IMAGING CARTRIDGE. There are four Dispenser Assys in total corresponding Y, M, C, and K, and they operate in the same way.
Page 70: Drive Assy Ph
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.8.3 DRIVE ASSY PH Drive force of DRIVE ASSY PH is transmitted as shown in the flowchart below: PAPER HANDLING CLUTCH ASSY PH TURN Figure 2-51. Drive Transmission Path (DRIVE ASSY PH) Figure 2-50. Drive Transmission Flow (DRIVE ASSY PH)
Page 71: Motor Assy Dup
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.8.4 MOTOR ASSY DUP The drive force of the MOTOR ASSY DUP is transmitted as shown in the flowchart below: DUPLEX PRINT MODE Figure 2-53. Drive Transmission Path (MOTOR ASSY DUP) Figure 2-52. Drive Transmission Flow (MOTOR ASSY DUP)
Page 72: Drive Assy Opt Fdr
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.8.5 DRIVE ASSY OPT FDR The drive force of DRIVE ASSY OPT FDR is transmitted as shown in the flowchart below: 550 PAPER FEEDER (OPTION) Figure 2-55. Drive Transmission Path (DRIVE ASSY OPT FDR) Figure 2-54. Drive Transmission Flow (DRIVE ASSY OPT FDR)
Page 73: Features Of The Controller
2 slot Program ROM DIMM: 16 MB (standard), Flash ROM DIMM: C533PROG (option) Max. SDRAM capacity AcuLaser C2800/C2800D : 640MB Processing language: ESC/PAGE-Color, PostScript3, PCL5c, PCL6c (standard) AcuLaser C3800/C3800D : 1GB Optional ROM DIMM that supports Chinese and Unicode fonts...
Page 74 AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 2-4. Main Elements Explanation DIAGRAM IC Name Reference Function/Specification Overview of connections of the clock and the data bus is shown below: IC101 Device: PowerPC 750FL-600 Clock speed: 600MHz IC102 ASIC for memory control and video control...
Page 75: Power Supply
AcuLaser C2800/C2800D/C3800/C3800D Revision C 2.9.1 Power Supply The power supply diagram is shown below: Figure 2-57. Power Supply Diagram OPERATING PRINCIPLES Features of the Controller Confidential...
Page 76: Chapter 3 Troubleshooting
C H A P T E R TROUBLESHOOTING Confidential...
Page 77: Procedure For Troubleshooting
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.1 Procedure for Troubleshooting 3.1.2 Preliminary Check Before starting troubleshooting, make sure that the following conditions are all met. For efficient troubleshooting, verify the condition of the trouble carefully using FIP (Fault Isolation Procedures) with reference to Chapter 2 “OPERATING...
Page 78: Precautions In Performing Troubleshooting Work
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.1.3 Precautions in Performing Troubleshooting Work Be sure to unplug the power cord before starting troubleshooting work unless instructed to plug it in. Never touch any live parts unnecessarily when the power is on. The power switch/inlet part is alive even when the power switch is turned OFF.
Page 79: Notes On Using Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.1.4 Notes on Using FIP When measuring the voltage, perform measurement with the TRANSFER UNIT and paper cassette loaded, FRONT COVER closed, and the power turned ON. The troubleshooting method described here assumes that there is no malfunction 10.
Page 80: Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.2 FIP 3.2.2 The flow of FIP Ask the operator about the conditions of the trouble. 3.2.1 FIP Was the operator operating the printer correctly? FIP is provided as the first step to identify the cause of the trouble. FIP is a guide for proceeding with troubleshooting while checking error codes and various other Instruct the operator how to operate the printer.
Page 81: List Of Warnings And Errors
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.2.3 List of Warnings and Errors PAPER JAM Table 3-1. List of Warnings and Errors (Paper Jam) Class LCD Message Description See FIP Paper Jam MP C1 A The REGI SENSOR could not detect paper within the specified time after feeding paper from the MSI.
Page 82 AcuLaser C2800/C2800D/C3800/C3800D Revision C Figure 3-3. Paper Feed Path Diagram TROUBLESHOOTING Confidential...
Page 83 AcuLaser C2800/C2800D/C3800/C3800D Revision C OTHER THAN PAPER JAM Table 3-2. List of Warnings and Errors (Other than paper jam) Class LCD Message Description See FIP Yellow(Y) Toner Low A remaining amount of yellow toner fell to below about 25%. Magenta(M) Toner Low A remaining amount of magenta toner fell to below about 25%.
Page 84 AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 3-2. List of Warnings and Errors (Other than paper jam) Class LCD Message Description See FIP Replace Toner Yellow(Y) IMAGING CARTRIDGE (Y) has reached near the end of its service life. (Warning) FIP 1-35 (p.111) IMAGING CARTRIDGE (Y) has reached near the end of its service life.
Page 85: List Of Service Request
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.2.4 List of Service Request Table 3-3. List of Service Request Class Code Description See FIP Laser power has weakened. FIP 1-24 (p.103) SOS signal cannot be detected. Abnormal high temperature was detected FIP 1-25 (p.104) The printer detected that the circuit for the Temp sensor is in failure.
Page 86 AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 3-3. List of Service Request Class Code Description See FIP 1110 ROM checksum error (bit 0 to 15) (font latter half) 1111 ROM checksum error (bit 16 to 31) (font latter half) 1120 ROM checksum error (bit 0 to 7) (program)
Page 87: Engine-Related Trouble Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.3 Engine-related Trouble FIP Step Check Check the operation of the CLUTCH ASSY End of procedure Go to Step [7]. PH TURN 3.3.1 Level 1 FIP Check the CLUTCH ASSY PH TURN with reference to FIP 2-3 (p.122).
Page 88 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-2 Paper Jam C1 A Possible parts that caused the error CLUTCH ASSY PH FEED ROLL ASSY FEED (Nudger Roll) DRIVE ASSY PH ROLL ASSY FEED (Retard Roll) REGI SENSOR PWBA MCU ROLL ASSY FEED (Feed Roll)
Page 89 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-3 Paper Jam C2 C1 A Step Check Check the operation of the CLUTCH ASSY End of procedure Go to Step [7]. Possible parts that caused the error TURN OPT (550 PAPER FEEDER) Check the CLUTCH ASSY TURN OPT with...
Page 90 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-4 Paper Jam C1 A Possible parts that caused the error REGI SENSOR PWBA MCU Troubleshooting Step Check Check the paper feed path Clean or replace Go to Step [2]. the part. Is there any foreign material, deformation, or...
Page 91 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-5 Paper Jam A B Step Check Check the operation of the Main Motor in End of procedure Go to Step [9]. Possible parts that caused the error the DRIVE ASSY MAIN Check the Main Motor in the DRIVE ASSY...
Page 92 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-6 Paper Jam C1 A Step Check Check the operation of the Main Motor in End of procedure Go to Step [9]. Possible parts that caused the error the DRIVE ASSY MAIN Check the Main Motor in the DRIVE ASSY...
Page 93 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-7 Paper Jam A B Possible parts that caused the error DRIVE ASSY MAIN PWBA MCU FUSER UNIT Troubleshooting Step Check Check the paper feed path Clean or replace Go to Step [2]. the part.
Page 94 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-8 Paper Jam A D Step Check Check the operation of the DRIVE ASSY PH End of procedure Go to Step [8]. Possible parts that caused the error Check the DRIVE ASSY PH with reference to FIP 2-6 (p.123).
Page 95 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-9 Paper Jam A D Possible parts that caused the error DUP JAM SENSOR ROLL ASSY DUP2 CLUTCH DUP PWBA DUP MOTOR ASSY DUP PWBA MCU ROLL ASSY DUP1 Troubleshooting Step Check Check the paper feed path Clean or replace Go to Step [2].
Page 96 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-10 Check Transparency Step Check Check the continuity of the HARNESS ASSY Replace the Replace the Possible parts that caused the error PWBA OHP HARNESS SENSOR. ASSY OHP. Is the continuity between P/J241 <=> P/J24...
Page 97 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-11 Paper Jam A D FIP 1-12 Paper Jam A B Possible parts that caused the error Possible parts that caused the error REGI SENSOR PWBA MCU FUSER UNIT PWBA MCU Troubleshooting Troubleshooting Step Check...
Page 98 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-13 Paper Jam C1 A FIP 1-14 Install Yellow(Y) TnrCart Possible parts that caused the error Possible parts that caused the error DUP JAM SENSOR PWBA MCU IMAGING CARTRIDGE (Y) HARNESS ASSY TNR SNR PWBA DUP...
Page 99 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-15 Install Magenta(M) TnrCart FIP 1-16 Install Cyan(C) TnrCart Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (M) HARNESS ASSY TNR SNR IMAGING CARTRIDGE (C) HARNESS ASSY TNR SNR...
Page 100 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-17 Install Black(K) TnrCart FIP 1-18 Install Transfer Unit Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (K) HARNESS ASSY TNR SNR TRANSFER UNIT HARNESS ASSY FRONT COVER SENSOR ASSY CRU (K)
Page 101 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-19 Install Fuser FIP 1-20 TonerCart Error Yellow(Y) Possible parts that caused the error Possible parts that caused the error FUSER UNIT PWBA MCU IMAGING CARTRIDGE (Y) HARNESS ASSY CRUM HARNESS ASSY FUSER CONNECTOR CRUM...
Page 102 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-21 TonerCart Error Magenta(M) FIP 1-22 TonerCart Error Cyan(C) Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (M) HARNESS ASSY CRUM IMAGING CARTRIDGE (C) HARNESS ASSY CRUM CONNECTOR CRUM...
Page 103 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-23 TonerCart Error Black(K) FIP 1-24 Service Req E100 (ROS Failure) Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (K) HARNESS ASSY CRUM ROS ASSY PWBA MCU CONNECTOR CRUM...
Page 104 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-25 Service Req E300 (Fuser Failure) Step Check Check after replacing the FUSER UNIT Go to Step [7]. End of procedure Possible parts that caused the error Replace the FUSER UNIT with a new one.
Page 105 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-26 Service Req E500 (Motor Failure) Possible parts that caused the error DRIVE ASSY MAIN HARNESS ASSY R SIDE DRIVE ASSY PH PWBA MCU Troubleshooting Step Check Check after turning the power OFF and ON.
Page 106 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-27 Service Req E550 (Fan Motor Failure) Step Check Check the continuity of the HARNESS ASSY Go to Step [6]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE. Is the continuity between P/J27 <=> P/J2720...
Page 107 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-28 Service Req E600 (ADC Sensor Error) Possible parts that caused the error TRANSFER UNIT HARNESS ASSY FRONT COVER PWBA MCU HARNESS ASSY R SIDE Troubleshooting Step Check Check after turning the power OFF and ON.
Page 108 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-29 Service Req E610 (Environment Sensor Error) Step Check Check the continuity of the HARNESS ASSY Go to Step [9]. Replace the Possible parts that caused the error HARNESS ASSY HUM. Is the continuity between P/J261 <=> P/J26...
Page 109 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-30 Service Req E900 (NV-RAM Error) FIP 1-31 Service Req E901 (Firmware Error) Possible parts that caused the error Possible parts that caused the error PWBA MCU FUSER UNIT PWBA MCU PWBA EEPROM XPRO TRANSFER UNIT...
Page 110 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-32 Service Req E998 (Engine communication error) FIP 1-33 DM Error 002 Possible parts that caused the error Possible parts that caused the error HARNESS ASSY ESS PWBA MCU HARNESS ASSY DUP UNIT PWBA DUP...
Page 111 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-34 Cassette2 Error 001 FIP 1-35 Replace Toner Yellow(Y) Possible parts that caused the error Possible parts that caused the error HARNESS ASSY FDR UNIT PWBA FEED-H IMAGING CARTRIDGE (Y) HARNESS ASSY LV TOP HARNESS ASSY R SIDE...
Page 112 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-36 Replace Toner Magenta(M) FIP 1-37 Replace Toner Cyan(C) Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (M) HARNESS ASSY LV TOP IMAGING CARTRIDGE (C) HARNESS ASSY LV TOP...
Page 113 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-38 Replace Toner Black(K) FIP 1-39 Replace Transfer Unit Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (K) HARNESS ASSY LV TOP TRANSFER UNIT PWBA MCU DISPENSER ASSY (K)
Page 114 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-40 Replace Fuser FIP-41 INSTALL YELLOW(Y) TNRCART Possible parts that caused the error Possible parts that caused the error FUSER UNIT PWBA MCU IMAGING CARTRIDGE (Y) HARNESS ASSY LV TOP DISPENSER ASSY (Y) PWBA MCU...
Page 115 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-42 Install Magenta(M) TnrCart FIP 1-43 Install Cyan(C) TnrCart Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (M) HARNESS ASSY LV TOP IMAGING CARTRIDGE (C) HARNESS ASSY LV TOP...
Page 116 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-44 Install Black(K) TnrCart Possible parts that caused the error IMAGING CARTRIDGE (K) HARNESS ASSY LV TOP DISPENSER ASSY (K) PWBA MCU Troubleshooting Step Check Check the toner tape Go to Step [2]. Pull out the toner tape.
Page 117 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-45 Printer Open / Close Front Cover Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error LV TOP HARNESS ASSY LV TOP. Is the continuity between P/J502 <=> P/J15...
Page 118 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-46 Wrong Toner Yellow(Y) FIP 1-47 Wrong Toner Magenta(M) Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (Y) PWBA MCU IMAGING CARTRIDGE (M) PWBA MCU Troubleshooting Troubleshooting Step Check...
Page 119 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-48 Wrong Toner Cyan(C) FIP 1-49 Wrong Toner Black(K) Possible parts that caused the error Possible parts that caused the error IMAGING CARTRIDGE (C) PWBA MCU IMAGING CARTRIDGE (K) PWBA MCU Troubleshooting Troubleshooting Step Check...
Page 120 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 1-50 Install Transfer Unit FIP 1-51 Install Fuser Possible parts that caused the error Possible parts that caused the error TRANSFER UNIT PWBA MCU FUSER UNIT PWBA MCU Troubleshooting Troubleshooting Step Check Step Check Check after replacing the TRANSFER UNIT...
Page 121: Level 2 Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.3.2 Level 2 FIP FIP 2-2 SOLENOID FEED MSI Possible parts that caused the error FIP 2-1 REGI SENSOR SOLENOID FEED MSI PWBA MCU Possible parts that caused the error HARNESS ASSY R SIDE HARNESS ASSY REGI SNR...
Page 122 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-3 CLUTCH ASSY PH TURN FIP 2-4 CLUTCH ASSY PH FEED Possible parts that caused the error Possible parts that caused the error CLUTCH ASSY PH TURN PWBA MCU CLUTCH ASSY PH FEED PWBA MCU...
Page 123 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-5 CLUTCH ASSY PH REGI FIP 2-6 DRIVE ASSY PH Possible parts that caused the error Possible parts that caused the error CLUTCH ASSY PH REGI PWBA MCU DRIVE ASSY PH PWBA MCU HARNESS ASSY R SIDE...
Page 124 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-7 MAIN MOTOR (DRIVE ASSY MAIN) FIP 2-8 SUB MOTOR (DRIVE ASSY MAIN) Possible parts that caused the error Possible parts that caused the error DRIVE ASSY MAIN PWBA MCU DRIVE ASSY MAIN PWBA MCU...
Page 125 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-9 DEVE MOTOR (DRIVE ASSY MAIN) FIP 2-10 EXIT CLUTCH (DRIVE ASSY MAIN) Possible parts that caused the error Possible parts that caused the error DRIVE ASSY MAIN PWBA MCU DRIVE ASSY MAIN HARNESS ASSY R SIDE...
Page 126 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-11 EXIT SENSOR (FUSER UNIT) Possible parts that caused the error FUSER UNIT PWBA MCU HARNESS ASSY FUSER Troubleshooting Step Check Check the connection of the Exit Sensor in Go to Step [2]. Reconnect P/J17...
Page 127 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-12 CLUTCH ASSY TURN OPT (550 PAPER FEEDER) Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE.
Page 128 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-13 CLUTCH ASSY FEED OPT (550 PAPER FEEDER) Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE.
Page 129 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-14 DRIVE ASSY OPT FDR Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE. Is the continuity between P/J27 <=> P/J273...
Page 130 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-15 DUP JAM SENSOR Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error DUP UNIT HARNESS ASSY DUP Is the continuity between P/J428 <=> P/J2720...
Page 131 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-16 CLUTCH DUP Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE. Is the continuity between P/J27 <=> P/J272...
Page 132 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP 2-17 MOTOR ASSY DUP Step Check Check the continuity of the HARNESS ASSY Go to Step [7]. Replace the Possible parts that caused the error R SIDE HARNESS ASSY R SIDE. Is the continuity between P/J27 <=> P/J272...
Page 133: Controller-Related Trouble Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.4 Controller-related Trouble FIP When a controller related error occurs, make sure to check the initial check items listed below first. If the error still occurs after that, replace the part given on an error basis in the Failed Parts List on the next page to perform troubleshooting.
Page 134 AcuLaser C2800/C2800D/C3800/C3800D Revision C Failed Parts List Error Description Code Error Description 1185 ROM module unsupported Code 1200 EEPROM writing error 0000- CPU exception (controller or software failure) 1210 EEPROM writing times limit 0799 1300 RTC failure 0800 IPL error (controller defect)
Page 135: Print Quality Trouble Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.5 Print Quality Trouble FIP To reliably judge and understand the trouble to perform the correct remedy efficiently when a print quality-related trouble occurs, make a test print, and use the FIPs described in the following pages.
Page 136: Cycle Of The Rollers
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.5.2 Cycle of the Rollers The table below shows the rolls and their diameter that have possibilities of causing print quality troubles and the intervals of their traces which appear on printouts. When horizontal stripes and spots appear at fixed intervals, it is...
Page 137: Print Quality Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.5.3 Print Quality FIP Step Check Check the laser beam path Remove the Go to Step [5]. FIP-P1 THE PRINTED IMAGE IS LIGHT OR FAINT foreign material. Is there any foreign material between the ROS ASSY and the IMAGING CARTRIDGE?
Page 138 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P2 A WHITE PAGE IS PRINTED Step Check Check the connection of the ROS ASSY Go to Step [6]. Reconnect the Symptom / Possible Parts harness correctly. Is the harness of the ROS ASSY securely Symptom connected? Nothing is printed on the paper.
Page 139 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P3 A BLACK PAGE IS PRINTED Step Check Check the installation of the IMAGING End of procedure Go to Step [6]. Symptom / Possible Parts CARTRIDGE (Y/M/C/K) Symptom Reinstall the IMAGING CARTRIDGE (Y/M/ The printed page is complete black.
Page 140 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P4 VERTICAL WHITE BANDS OR LINES APPEAR ON PRINTED Step Check PAGES Check the installation of the IMAGING End of procedure Go to Step [6]. CARTRIDGE (Y/M/C/K) Symptom / Possible Parts Reinstall the IMAGING CARTRIDGE (Y/M/ C/K) and make a test print.
Page 141 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P5 HORIZONTAL WHITE BANDS APPEAR ON PRINTED PAGES Step Check Check the connection of the ROS ASSY Go to Step [6]. Reconnect the Symptom / Possible Parts harness correctly. Is the harness of the ROS ASSY securely...
Page 142 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P6 VERTICAL LINES APPEAR ON PRINTED PAGES Step Check Check the connection of the ROS ASSY Go to Step [6]. Reconnect the Symptom / Possible Parts harness correctly. Is the harness of the ROS ASSY securely...
Page 143 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P7 HORIZONTAL LINES APPEAR ON PRINTED PAGES Step Check Check the connection of the ROS ASSY Go to Step [6]. Reconnect the Symptom / Possible Parts harness correctly. Is the harness of the ROS ASSY securely...
Page 144 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P8 IRREGULAR AREAS OF MISSING IMAGE APPEAR ON THE Step Check PRINTED PAGE Check the connection of the ROS ASSY Go to Step [6]. Reconnect the harness correctly. Is the harness of the ROS ASSY securely...
Page 145 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P9 TONER SMUDGES ACROSS THE PRINTED PAGES Step Check Check after replacing the ROS ASSY End of procedure Replace the Symptom / Possible Parts PWBA MCU. Replace the ROS ASSY (p.280) and make a test Symptom print.
Page 146 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P10 "GHOST IMAGES" APPEAR ON THE PRINTED PAGE Step Check Check after replacing the PWBA MCU End of procedure Replace the Symptom / Possible Parts BOARD ASSY, Replace the PWBA MCU (p.343) and make a MAIN.
Page 147 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P11 PRINTED PAGES HAVE A DARK OR DIRTY BACKGROUND Symptom / Possible Parts Symptom The entire page or part of the page is soiled with toner. It appears as extremely light gray dirt. Possible Parts IMAGING CARTRIDGE (Y/M/C/K)
Page 148 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P12 THE PRINTED IMAGE IS SKEWED Step Check Check the installation of the TRANSFER End of procedure Replace the Symptom / Possible Parts UNIT TRANSFER UNIT. (p.268) Symptom Reinstall the TRANSFER UNIT and make a Printed image is skewed.
Page 149 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P13 PRINTED PAGE IS WRINKLED, FOLDED, OR TORN Step Check Check the Paper Feed Rollers Go to Step [5]. Clean the rollers Symptom / Possible Parts and reinstall them 1. Are the rollers on the paper feed path not...
Page 150 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-P14 TONER IS NOT FUSED TO THE PRINT MEDIA FIP-P15 COLORS ARE DISPLACED Symptom / Possible Parts Symptom / Possible Parts Symptom Symptom The printed image is not sufficiently fixed to the paper. The printed Yellow or Black image does not accurately...
Page 151: Abnormal Noise-Related Trouble
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.6 Abnormal Noise-related Trouble 3.6.1 Abnormal Noise-related Troubleshooting Entry Chart Do you hear abnormal noise during Check the operation table at power-on, and check for foreign material or damage. (Refer to FIP-N1 (p 152)). initialization after power-on? Do you hear abnormal noise in Check the operation table in the Standby mode, and check for foreign material and damage.
Page 152: Abnormal Noise-Related Fip
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.6.2 Abnormal Noise-related FIP Step Check Is abnormal noise being Reinstall the Go to Step [5]. FIP-N1 AT POWER ON generated by the TRANSFER TRANSFER UNIT. UNIT? When the trouble still Possible parts that caused the error occurs, replace the TRANSFER UNIT.
Page 153 AcuLaser C2800/C2800D/C3800/C3800D Revision C FIP-N3 DURING PRINTING Step Check Is abnormal noise being Reinstall the DRIVE Go to Step [7]. Possible parts that caused the error generated by the DRIVE ASSY ASSY OPT FDR. When OPT FDR? the trouble still occurs,...
Page 154: Test Print
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.7 Test Print SCREW KNURLINGs 3.7.1 What is Test Print? In order to check the engine operation, you can print a test pattern embedded in a PWBA MCU without activating the controller. If no problem is found during printing the pattern, the cause of the trouble may be on the main controller (BOARD ASSY, MAIN) side.
Page 155 AcuLaser C2800/C2800D/C3800/C3800D Revision C Test print can also be performed by removing the BOARD ASSY, C H E C K P O I N T MAIN and shorting out the unmounted circuit pattern TPRINT (lower left of P10) on the PWBA MCU. See Figure 3-8 (p.155).
Page 156: Symptoms When Connectors Are Disconnected
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.8 Symptoms When Connectors are Disconnected CN501 CN601 CN602 BOARD ASSY, MAIN Table 3-4. BOARD ASSY, MAIN Connector Connected to Symptom CN405 CONTROL PANEL The engine starts to operate after turning the power on, however, nothing appears on the LCD panel.
Page 157 AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 3-5. PWBA MCU PWBA MCU Connector Table 3-5. PWBA MCU Connected to Symptom Connector DRIVE ASSY PH “Service Req E500” occurs after turning the power Connected to Symptom BOARD ASSY, MAIN “Service Req C0998” occurs after turning the SENSOR HUM “Service Req E610”...
Page 158: Reliability
AcuLaser C2800/C2800D/C3800/C3800D Revision C 3.8.1 Reliability SKEW This section describes the product specification values concerning paper feeding. Single-sided Printing Duplex Printing Use them as a guideline when fixing paper feed problems. Main scanning direction (|a-b|) 1.1 mm 1.1 mm Sub scanning direction (|c-d|) 1.0 mm...
Page 159: Chapter 4 Disassembly/Reassembly
C H A P T E R DISASSEMBLY/REASSEMBLY Confidential...
Page 160: Preliminary Check
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.1 Preliminary Check 4.1.2 Prohibited Disassembly Disassembling the parts described below is strictly prohibited. 4.1.1 Required Tools If not observed, it causes failure or malfunction of the printer. Consumable products/Periodic replacement parts/ASP Special tools are not required for maintenance of the equipment.
Page 161: Major Reassembly Unit
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.2 Major Reassembly Unit The figures below show the location of the major parts and units of AcuLaser C3800/C3800D. Disassembly procedures of these parts and units are explained in the pages that follow. COVER ASSY FRONT (p.192) COVER TOP (p.182)
Page 162 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSER UNIT (p.298) IMAGING CARTRIDGE (K), (C), (M), (Y) (p.271) CHUTE DUP GATE (p.298) TRANSFER UNIT (p.268) FEEDER ASSY DUP (p.349) DISASSEMBLY/REASSEMBLY Major Reassembly Unit Confidential...
Page 163: Disassembly Flowchart
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.3 Disassembly Flowchart COVER 1 Shows the step necessary for removing the next part. Shows the action to be performed. Shows the part to be removed. START Open the COVER Remove the CASSETTE COVER SIDE I/F...
Page 164 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER 2 IMAGING CARTRIDGE C, M, Y, K (p.198) COVER REAR (p.198) COVER SIDE I/F (p.199) COVER SIDE R (p.199) CONTROL PANEL PLATE LATCH COVER ASSY FRONT SPRING LATCH (p.206) (p.200) LATCH FRONT (p.208) CONTROL PANEL...
Page 165 AcuLaser C2800/C2800D/C3800/C3800D Revision C PAPER CASSETTE START Remove the CASSETTE ASSY 550 IOT (p.212) KIT ROLL ASSY HOLDER ASSY ACTUATOR NO GUIDE ASSY CST PLATE ASSY HANDLE CST GUIDE ASSY SIDE FEED SEC RETARD MSI (p.215) BOTTOM (p.216) PAPER MSI (p.218)
Page 166 AcuLaser C2800/C2800D/C3800/C3800D Revision C PAPER FEEDER 1 START Remove the CASSETTE ASSY 550 IOT (p.222) KIT ROLL ASSY FEED Open the COVER ASSY ROLL ASSY FEED MSI SEC (FEED, NUDGER) FRONT (p.222) (p.224) (p.225) TRANSFER UNIT IMAGING CARTRIDGE (p.223) C, M, Y, K (p.229)
Page 167 AcuLaser C2800/C2800D/C3800/C3800D Revision C PAPER FEEDER 2 TRANSFER UNIT (p.234) ROLL ASSY MSI (p.235) CLUTCH ASSY PH FEED (p.236) FEEDER ASSY (p.236) CLUTCH ASSY PH TURN ACTUATOR NO SENSOR PHOTO: CST ROLL REGI METAL PWBA OHP SNR (p.252) PAPER A4 (p.251)
Page 168 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRANSFER START Open the COVER ASSY FRONT (p.269) TRANSFER UNIT (p.269) DISASSEMBLY/REASSEMBLY Disassembly Flowchart Confidential...
Page 169 AcuLaser C2800/C2800D/C3800/C3800D Revision C XEROGRAPHICS START Open the COVER ASSY FRONT (p.282) IMAGING CARTRIDGE Y, M, C, K FUSER UNIT (p.282) (p.273) IMAGING CARTRIDGE Y, M, C, K VISOR ASSY LABEL / LEVER VISOR CRU COVER REAR (p.274) (p.283) LEVER VISOR CRU L / SPRING VISOR CRU (p.276)
Page 170 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSER & EXIT START Open the COVER ASSY FRONT (p.299) CHUTE DUP GATE CHUTE ASSY EXIT OUT FUSER UNIT (p.300) (p.299) (p.300) DISASSEMBLY/REASSEMBLY Disassembly Flowchart Confidential...
Page 171 AcuLaser C2800/C2800D/C3800/C3800D Revision C FRAME START Open the COVER ASSY Remove the CASSETTE FRONT (p.310) ASSY 550 IOT (p.302) COVER CST 550 IMAGING CARTRIDGE Open the COVER ASSY FUSER UNIT (p.303) C, M, Y, K (p.312) FRONT (p.303) (p.311) IMAGING CARTRIDGE...
Page 172 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE START Open the COVER ASSY FRONT Remove the CASSETTE ASSY 550 IOT (p.318) (p.318) FUSER UNIT Open the COVER ASSY FRONT (p.318) (p.319) IMAGING CARTRIDGE C, M, Y, K IMAGING CARTRIDGE C, M, Y, K (p.319)
Page 173 AcuLaser C2800/C2800D/C3800/C3800D Revision C ELECTRICAL START Open the COVER ASSY FRONT (p.328) FUSER UNIT IMAGING CARTRIDGE (p.329) C, M, Y, K (p.338) COVER REAR IMAGING CARTRIDGE (p.339) C, M, Y, K (p.329) COVER SIDE I/F COVER REAR (p.339) (p.330) COVER SIDE L COVER SIDE R (p.330)
Page 174 AcuLaser C2800/C2800D/C3800/C3800D Revision C DUPLEX START Open the COVER ASSY FRONT (p.351) TRANSFER UNIT (p.351) FEEDER ASSY DUP (p.352) COVER PWBA DUP (p.353) FAN DUP (p.356) ACTUATOR DUP (p.353) CLUTCH DUP (p.355) MOTOR ASSY DUP (p.357) PWBA DUP-H (p.354) SENSOR PHOTO: DUP, JAM MOTOR ASSY DUP (p.357)
Page 175 AcuLaser C2800/C2800D/C3800/C3800D Revision C 550 OPTION FEEDER 1 START Remove the CASSETTE Remove the CASSETTE ASSY 550 IOT (p.359) ASSY 550 OPT (p.365) 550 OPTION FEEDER COVER LEFT (p.365) COVER CST 550 (p.359) (p.362) Remove the CASSETTE COVER RIGHT (p.366) ASSY 550 OPT (p.360)
Page 176 AcuLaser C2800/C2800D/C3800/C3800D Revision C 550 OPTION FEEDER 2 GUIDE ASSY SIDE R 550 A4 KIT ROLL ASSY FEED HANDLE CST 550 OPT GUIDE ASSY CST KIT ROLL ASSY FEED COVER RIGHT (p.372) GUIDE ASSY SIDE L 550 A4 SEC (FEED, NUDGER) (p.379)
Page 177: Disassembly/Reassembly
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4 Disassembly/Reassembly 4.4.1 How to Read this Chapter PAGE CONFIGURATION Opening page Main page Guide Part Name Section Title Guide to indicate the procedual steps. Shows part to be disassembled or Shows title of the section.
Page 178 AcuLaser C2800/C2800D/C3800/C3800D Revision C 3) Go to main pages, find the column(s) that has the foregoing guide on the PROCEDURE upper left corner, and perform the operation described in the column(s). 1) Locate the part you want to remove in the table.
Page 179: Cover (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.2 COVER (PART 1) LOCATION DISASSEMBLED PARTS Table 4-1. List of Disassembled Parts COVER REAR Name Guide COVER REAR COVER EXTENSION 1 COVER EXTENSION 2 COVER SIDE IF COVER EXTENSION 1 COVER EXTENSION 2 COVER SIDE IF...
Page 180 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER EXTENSION 1 COVER REAR COVER EXTENSION 2 COVER EXTENSION 1 2)-2 COVER REAR 2)-1 Kmy03007EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit. 1. Open the COVER EXTENSION 1.
Page 181 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF COVER EXTENSION 2 5)-2 COVER SIDE IF 1)-1 5)-1 1)-2 1)-1 Kmy03082EA Kmy03008EA 4. Open the COVER EXTENSION 2. 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 182: Cover (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.3 COVER (PART 2) COVER TOP DISASSEMBLED PARTS Table 4-2. List of Disassembled Parts Name Guide COVER SIDE L COVER TOP COVER SIDE R LOCATION COVER SIDE R COVER SIDE L DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 183 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) COVER ASSY FRONT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER ASSY FRONT IMAGING CARTRIDGE LATCH 1) -2 1) -1 Kmy03044EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 184 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER REAR COVER SIDE L COVER SIDE L COVER REAR 4)-1 4)-1 4)-1 4)-1 4)-2 Kmy03006EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit. As the FUSER UNIT remains at hazardous temperature after turning the power off, be 2.
Page 185 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 4)-1 1)-1 4)-1 COVER SIDE IF 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 186 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSER UNIT COVER TOP COVER TOP FUSER UNIT 3)-1 3)-2 Kmy03046EA 1. Remove the four screws (silver, self-tapping, 10 mm) and the screw (silver, brimmed, self-tapping, Be careful not to burn yourself as the FUSER section remains at high temperature after 10 mm) that secure the COVER TOP to the main unit.
Page 187: Cover (Part 3)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.4 COVER (PART 3) LOCATION DISASSEMBLED PARTS Table 4-3. List of Disassembled Parts Name Guide COVER ASSY MSI COVER ASSY MSI COVER CST 550 KIT TRAY ASSY MSI SEC (LINK ASSY MSI L/TRAY ASSY MSI BASE/...
Page 188 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C CASSETTE ASSY 550 IOT LINK ASSY MSI L TRAY MSI TRAY ASSY MSI BASE LINK ASSY MSI R CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 189 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER ASSY MSI COVER CST 550 LEVER MSI 1 2)-2 2)-1 2)-2 2)-1 3)-1 3)-2 COVER CST 550 3)-1 2)-2 3)-2 2)-1 COVER ASSY MSI Kmy03014EA 1. Open the COVER ASSY MSI. Kmy03004EA Be careful not to drop or damage the COVER ASSY MSI.
Page 190 AcuLaser C2800/C2800D/C3800/C3800D Revision C 4)-2 KIT TRAY ASSY MSI SEC 2)-2 3)-1 2)-1 3)-2 4)-1 LEVER MSI 1 4)-1 3)-1 2)-2 LINK ASSY MSI L 2)-1 3)-2 LINK ASSY MSI R Kmy03016EA Kmy03015EA 3. Rotate the LINK ASSY MSI L and the LINK ASSY MSI R so that the cutouts of their shafts match the protrusions of the TRAY ASSY MSI BASE, and remove the LINK ASSY MSI L and the LINK 1.
Page 191 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRAY ASSY MSI BASE TRAY MSI Kmy03017EA 5. Turn over the TRAY ASSY MSI BASE and the TRAY MSI, and remove the SPRING TRAY. 6. Remove the TRAY MSI from the TRAY ASSY MSI BASE. DISASSEMBLY/REASSEMBLY...
Page 192: Cover (Part 4)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.5 COVER (PART 4) LOCATION DISASSEMBLED PARTS CONTROL Table 4-4. List of Disassembled Parts PANEL Name Guide CONTROL PANEL PLATE LATCH SPRING LATCH LATCH FRONT COVER ASSY FRONT SPRING LATCH PLATE LATCH KIT COVER ASSY FRONT SEC...
Page 193 AcuLaser C2800/C2800D/C3800/C3800D Revision C HARNESS ASSY-CON F COVER ASSY FRONT KIT COVER ASSY FRONT SEC HARNESS ASSY FRONT COVER DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 194 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D E A B C D E COVER ASSY FRONT TRANSFER UNIT COVER ASSY FRONT 1)-1 LATCH 1)-1 1) -2 1) -1 1)-2 Kmy03030EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 195 AcuLaser C2800/C2800D/C3800/C3800D Revision C CHUTE ASSY EXIT OUT TRANSFER UNIT 2)-2 2)-1 Kmy03031EA Kmy03045EA CHUTE ASSY EXIT OUT 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER 1. Remove the two screws (silver, brimmed, self-tapping, 10 mm) that secure the CHUTE ASSY EXIT ASSY FRONT, remove the guide pin on the left side of the TRANSFER UNIT from the hole on the OUT to the COVER ASSY FRONT.
Page 196 AcuLaser C2800/C2800D/C3800/C3800D Revision C B C D E CONTROL PANEL FEEDER ASSY DUP 1)-1 FEEDER ASSY DUP 1)-1 1)-2 1)-1 1)-2 Kmy03013EA CONTROL PANEL Kmy03075EA 1. Pull the lever of the FEEDER ASSY DUP, and raise the FEEDER ASSY DUP straight up.
Page 197 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE LATCH LATCH FRONT SPRING LATCH LATCH FRONT 4)-2 LATCH FRONT SPRING LATCH Figure-A 4)-1 4)-2 4)-1 PLATE LATCH Kmy03012EB Kmy03011EB Confirm if the PLATE LATCH moves smoothly by pressing the BUTTON TOP. 4. Hold down the tabs to release the LATCH FRONTs, and remove the LATCH FRONTs from the PLATE LATCH.
Page 198 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) C D E C D E COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03003EA Kmy03044EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 199 AcuLaser C2800/C2800D/C3800/C3800D Revision C C D E C D E COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 4)-1 1)-1 4)-1 COVER SIDE IF 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 200 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER ASSY FRONT Figure-B HARNESS ASSY-CON F Ground (White) Wire (Green) HARNESS ASSY FRONT COVER (Black) 6)-1 Kmy03087EA 6)-2 Kmy03009EC When performing the next step, be sure not to release the wire and harnesses from the DUCT DRV PH near the COVER ASSY FRONT (to the left of the dotted line indicated with A).
Page 201 AcuLaser C2800/C2800D/C3800/C3800D Revision C CONTROL PANEL 8)-1 9)-1 9)-2 1)-1 1)-1 8)-2 8)-3 COVER ASSY 8)-3 FRONT 8)-2 8)-1 9)-1 9)-2 1)-2 Kmy03010EB Kmy03013EA 7. Open the COVER ASSY MSI. CONTROL PANEL Be careful not to drop or damage the COVER ASSY FRONT.
Page 202 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE LATCH LATCH FRONT SPRING LATCH LATCH FRONT 4)-2 LATCH FRONT SPRING LATCH Figure-A 4)-1 4)-2 4)-1 PLATE LATCH Kmy03012EB Kmy03011EB Confirm if the PLATE LATCH moves smoothly by pressing the BUTTON TOP. 4. Hold down the tabs to release the LATCH FRONTs, and remove the LATCH FRONTs from the PLATE LATCH.
Page 203 AcuLaser C2800/C2800D/C3800/C3800D Revision C HARNESS ASSY FRONT COVER 5)-2 4)-2 4)-1 HARNESS ASSY-CON F (White) Figure-C 5)-1 5)-1 4)-1 Ground Wire (Green) HARNESS ASSY FRONT COVER (Black) Kmy03089EA Kmy03090EA 4. Release the two tabs of the connector (P/J2721) that connect the HARNESS ASSY FRONT COVER...
Page 204 AcuLaser C2800/C2800D/C3800/C3800D Revision C 9)-2 HARNESS ASSY-CON F 9)-1 Figure-C HARNESS ASSY-CON F (White) 9)-1 Ground Wire (Green) HARNESS ASSY FRONT COVER (Black) HARNESS ASSY FRONT COVER Kmy03092EA Kmy03091EA Route the HARNESS ASSY FRONT COVER (black) under the HARNESS ASSY-CON Open and close the COVER ASSY FRONT to check if the harnesses routed through the F (white) in the section indicated with A.
Page 205 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT COVER ASSY FRONT SEC KIT COVER ASSY FRONT SEC 3)-1 HARNESS 3)-2 ASSY-CON F 3)-1 Kmy03088EA Kmy03093EA 3. Remove the four screws (silver, self-tapping, 8 mm) that secure the KIT COVER ASSY HARN SEC 1. Remove the screw (silver, self-tapping, 10 mm) that secures the HARNESS ASSY FRONT COVER to the COVER ASSY FRONT.
Page 206 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE LATCH CONTROL PANEL SPRING LATCH LATCH FRONT SPRING LATCH Figure-A 1)-1 1)-1 1)-2 Kmy03013EA Kmy03011EB CONTROL PANEL Confirm if the PLATE LATCH moves smoothly by pressing the BUTTON TOP. Be careful not to drop or damage the CONTROL PANEL.
Page 207 AcuLaser C2800/C2800D/C3800/C3800D Revision C LATCH FRONT HARNESS ASSY-CON F 4)-2 LATCH FRONT Figure-C HARNESS ASSY-CON F (White) 4)-1 4)-2 4)-1 PLATE LATCH Ground Wire (Green) HARNESS ASSY FRONT COVER (Black) Kmy03012EB Kmy03092EA 4. Hold down the tabs to release the LATCH FRONTs, and remove the LATCH FRONTs from the Open and close the COVER ASSY FRONT to check if the harnesses routed through the PLATE LATCH.
Page 208 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE LATCH SPRING LATCH LATCH FRONT SPRING LATCH Figure-A HARNESS ASSY-CON F Kmy03011EB Kmy03093EA Confirm if the PLATE LATCH moves smoothly by pressing the BUTTON TOP. 3. Remove the four screws (silver, self-tapping, 8 mm) that secure the KIT COVER ASSY HARN SEC to the COVER ASSY FRONT.
Page 209 AcuLaser C2800/C2800D/C3800/C3800D Revision C LATCH FRONT HARNESS ASSY FRONT COVER 4)-2 LATCH FRONT HARNESS ASSY-CON F (White) Figure-C 4)-1 4)-2 4)-1 Ground Wire PLATE LATCH (Green) HARNESS ASSY FRONT COVER (Black) Kmy03012EB Kmy03089EA 4. Hold down the tabs to release the LATCH FRONTs, and remove the LATCH FRONTs from the Open and close the COVER ASSY FRONT to check if the harnesses routed through the PLATE LATCH.
Page 210 AcuLaser C2800/C2800D/C3800/C3800D Revision C 9)-2 9)-1 5)-2 4)-2 4)-1 5)-1 5)-1 9)-1 4)-1 HARNESS ASSY FRONT COVER Kmy03091EA Kmy03090EA 4. Release the two tabs of the connector (P/J2721) that connect the HARNESS ASSY FRONT COVER Route the HARNESS ASSY FRONT COVER (black) under the HARNESS ASSY-CON to the TRANSFER UNIT, and remove the connector (P/J2721) together with the HOLDER F (white) in the section indicated with A.
Page 211: Paper Cassette (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.6 PAPER CASSETTE (PART 1) LOCATION DISASSEMBLED PARTS Table 4-5. List of Disassembled Parts Name Guide GUIDE ASSY SIDE R 550 A4 GUIDE ASSY SIDE L 550 A4 PLATE ASSY BTM A4 GUIDE ASSY SIDE L 550 A4...
Page 212 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D CASSETTE ASSY 550 IOT GUIDE ASSY CST END 550 ROLL ASSY RETARD HOLDER ASSY RETARD MSI CASSETTE ASSY 550 IOT PLATE ASSY BOTTOM 1. Pull the CASSETTE ASSY 550 IOT out. DISASSEMBLY/REASSEMBLY...
Page 213 AcuLaser C2800/C2800D/C3800/C3800D Revision C GUIDE ASSY SIDE R 550 A4 GUIDE ASSY GUIDE ASSY SIDE L 550 A4 SIDE L 550 A4 3)-2 3)-1 1)-1 1)-2 GUIDE ASSY SIDE R 550 A4 :Tab GUIDE ASSY SIDE R 6) GUIDE ASSY SIDE L...
Page 214 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE ASSY BTM A4 PLATE ASSY BTM A4 4)-1 3)-1 4)-3 4)-2 3)-2 Kmy03206EA Kmy03207EA 4. Pull out the SHAFT PB A4 from the PLATE ASSY BTM A4 in the direction of the arrow, and 1. Remove the screw (silver, self-tapping, 10 mm) that secures the right PLATE GEAR LOCK 550 to remove the STOPPER PB and the GEAR BTM LOCK ONEWAY.
Page 215 AcuLaser C2800/C2800D/C3800/C3800D Revision C GUIDE ASSY CST END 550 HOLDER ASSY RETARD MSI HOLDER ASSY RETARD MSI 1)-2 1)-2 2)-2 2)-1 1)-1 GUIDE ASSY CST END 550 Kmy03210EA Kmy03200EA 1. Remove the screw (silver, brimmed, self-tapping, 8 mm) that secures the GUIDE ASSY CST END 1.
Page 216 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL ASSY RETARD PLATE ASSY BOTTOM PLATE ASSY BOTTOM ROLL ASSY RETARD 3)-2 2)-2 3)-1 2)-1 Kmy03201EA Kmy03202EA 1. Remove the SPRING RETARD that is attached to the HOLDER RETARD MSI. 1. Remove the SPRING NF MSI hitched on the ARM L, R.
Page 217: Paper Cassette (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.7 PAPER CASSETTE (PART 2) LOCATION DISASSEMBLED PARTS ACTUATOR NO PAPER MSI COVER FRONT MSI Table 4-6. List of Disassembled Parts Name Guide ACTUATOR NO PAPER MSI KIT ROLL ASSY FEED SEC (RETARD) HANDLE CST COVER FRONT MSI...
Page 218 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C CASSETTE ASSY 550 IOT ACTUATOR NO PAPER MSI ACTUATOR NO PAPER MSI CASSETTE ASSY 550 IOT Kmy03205EA 1. Pinch the ACTUATOR ASSY MSI as shown in the figure to release the tabs, and remove the ACTUATOR ASSY MSI from the HANDLE CST.
Page 219 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT ROLL ASSY FEED SEC (RETARD) HANDLE CST KIT ROLL ASSY FEED SEC (RETARD) HANDLE CST 2)-1 1)-2 2)-2 1)-1 1)-2 1)-2 1)-1 1)-1 1)-1 Kmy03018EA Kmy03204EA 1. Turn the CASSETTE ASSY 550 IOT over, release the two protrusions with a mini screwdriver or a KIT ROLL ASSY FEED SEC consists of three rollers;...
Page 220 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER FRONT MSI 1)-2 COVER FRONT MSI 1)-1 1)-2 Kmy03203EA 1. While lifting up the ACTUATOR NO PAPER MSI, pull out the shaft on both ends of the COVER FRONT MSI from the HANDLE CST, and remove the COVER FRONT MSI.
Page 221: Paper Feeder (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.8 PAPER FEEDER (PART 1) LOCATION KIT ROLL ASSY FEED SEC (FEED, NUDGER) DISASSEMBLED PARTS Table 4-7. List of Disassembled Parts Name Guide SENSOR PHOTO:MSI NO PAPER ROLL ASSY FEED MSI KIT ROLL ASSY FEED SEC (FEED, NUDGER)
Page 222 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C CASSETTE ASSY 550 IOT COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 223 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRANSFER UNIT 2)-2 TRANSFER UNIT 1)-1 1)-1 2)-1 1)-2 Kmy03031EA Kmy03030EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER Do not touch or damage the BELT section of the TRANSFER UNIT.
Page 224 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:MSI NO PAPER ROLL ASSY FEED MSI 3)-1 1)-2 1)-1 3)-2 SENSOR PHOTO: MSI NO PAPER 2)-1 2)-2 ROLL ASSY FEED MSI Kmy03023EA Kmy03022EA 1. Release the tab of the COVER SNR. 1. Release the tab on the ROLL CORE MSI located on the right side of the ROLL ASSY FEED MSI, and slide the ROLL CORE MSI in the direction of the arrow.
Page 225 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT ROLL ASSY FEED SEC (FEED, NUDGER) 1)-1 1)-2 KIT ROLL ASSY 1)-1 FEED SEC (FEED) 1)-2 KIT ROLL ASSY FEED SEC (NUDGER) Kmy03029EA KIT ROLL ASSY FEED SEC consists of three rollers; one is installed in the CASSETTE ASSY 550 IOT and the other two in the FEEDER ASSY, and is provided in a set.
Page 226: Paper Feeder (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.9 PAPER FEEDER (PART 2) LOCATION DISASSEMBLED PARTS Table 4-8. List of Disassembled Parts Name Guide CLUTCH ASSY PH REGI CLUTCH ASSY PH REGI CLUTCH ASSY PH FEED FEEDER ASSY ROLL REGI METAL ROLL REGI RUBBER...
Page 227 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL REGI METAL ROLL ASSY MSI ROLL REGI RUBBER FEEDER ASSY DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 228 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D CASSETTE ASSY 550 IOT COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 229 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C D A B C D COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03044EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 230 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 231 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE ASSY PH HARNESS ASSY-CON F (White) Figure-B KIT MOT ASSY PH KIT GEAR ASSY PH Ground Wire Attach to the (Green) main unit HARNESS ASSY FRONT COVER (Black) Attach to GEAR MSI 2)-1 2)-2 Kmy03094EA Kmy03019EA 3.
Page 232 AcuLaser C2800/C2800D/C3800/C3800D Revision C 8)-2 DRIVE ASSY PH 8)-1 Kmy03061EB Kmy03060EB 9. Remove the four screws (silver, self-tapping, 10 mm) that secure the DRIVE ASSY PH to the main Make sure that the ground wire (green), HARNESS ASSY-CON F (white), and HARNESS unit.
Page 233 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT MOT ASSY PH CLUTCH ASSY PH REGI Gray Gray Gray Kmy03024EB CLUTCH ASSY PH REGI The mid connector should remain connected to the main unit. C H E C K P O I N T...
Page 234 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRANSFER UNIT 2)-2 TRANSFER UNIT 1)-1 1)-1 2)-1 1)-2 Kmy03031EA Kmy03030EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER Do not touch or damage the BELT section of the TRANSFER UNIT.
Page 235 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL ASSY MSI 3)-1 3)-2 3)-1 3)-2 Attach to the main unit Attach to GEAR MSI White 2)-1 2)-2 Black Kmy03021EA ROLL ASSY MSI Kmy03080EA 1. Remove the SPRING FEED MSI from the main unit. Mind the correct orientations when installing the SPRING FEED MSI.
Page 236 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH ASSY PH FEED FEEDER ASSY Yellow Yellow Kmy03026EA CLUTCH ASSY PH FEED Yellow Kmy03025EB It is not necessary to remove the SENSOR PHOTO:MSI NO PAPER and the COVER SNR C H E C K P O I N T when performing the following work.
Page 237 AcuLaser C2800/C2800D/C3800/C3800D Revision C Blue Blue 7)-1 7)-2 FEEDER ASSY Kmy03028EA 7)-2 If your screwdriver is not long enough to perform the following work, close the COVER C H E C K P O I N T ASSY FRONT for easier operation.
Page 238 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL REGI METAL ROLL REGI RUBBER ROLL REGI METAL ROLL REGI RUBBER 4) (Black) 6) (White) 7) (Long, Yellow) 5) (White) 7) (Short, Metallic color) Kmy03212EA 2) (Black) Kmy03211EA 9. Temporarily slide the ROLL REGI METAL toward right, pull out the left end of the ROLL REGI 1.
Page 239 AcuLaser C2800/C2800D/C3800/C3800D Revision C SOLENOID FEED MSI Attach to the main unit Attach to 3)-1 GEAR MSI 2)-1 2)-2 3)-2 Kmy03020EB SOLENOID FEED MSI Kmy03019EA 10mm 1. Remove the SPRING FEED MSI. Mind the correct orientations when installing the SPRING FEED MSI.
Page 240: Paper Feeder (Part 3)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.10 PAPER FEEDER (PART 3) LOCATION DISASSEMBLED PARTS PWBA OHP SNR SENSOR PHOTO:CST NO PAPER Table 4-9. List of Disassembled Parts Name Guide SENSOR PHOTO:CST NO PAPER ACTUATOR NO PAPER A4 PWBA OHP SNR ACTUATOR NO PAPER A4...
Page 241 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C CASSETTE ASSY 550 IOT COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 242 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03003EA Kmy03044EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 243 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 244 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE ASSY PH HARNESS ASSY-CON F (White) Figure-B KIT MOT ASSY PH KIT GEAR ASSY PH Ground Wire Attach to the (Green) main unit HARNESS ASSY FRONT COVER (Black) Attach to GEAR MSI 2)-1 2)-2 Kmy03094EA Kmy03019EA 3.
Page 245 AcuLaser C2800/C2800D/C3800/C3800D Revision C 8)-2 DRIVE ASSY PH 8)-1 Kmy03061EB Kmy03060EB 9. Remove the four screws (silver, self-tapping, 10 mm) that secure the DRIVE ASSY PH to the main Make sure that the ground wire (green), HARNESS ASSY-CON F (white), and HARNESS unit.
Page 246 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT MOT ASSY PH CLUTCH ASSY PH REGI Gray Gray Gray Kmy03024EB CLUTCH ASSY PH REGI The mid connector should remain connected to the main unit. C H E C K P O I N T...
Page 247 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRANSFER UNIT 2)-2 TRANSFER UNIT 1)-1 1)-1 1)-2 2)-1 Kmy03031EA Kmy03030EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER Do not touch or damage the BELT section of the TRANSFER UNIT.
Page 248 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL ASSY MSI 3)-1 3)-2 3)-1 3)-2 Attach to the main unit Attach to GEAR MSI White 2)-1 2)-2 Black Kmy03021EA ROLL ASSY MSI Kmy03080EA 1. Remove the SPRING FEED MSI from the main unit. Mind the correct orientations when installing the SPRING FEED MSI.
Page 249 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH ASSY PH FEED FEEDER ASSY Yellow Yellow Kmy03026EA CLUTCH ASSY PH FEED Yellow Kmy03025EB It is not necessary to remove the SENSOR PHOTO:MSI NO PAPER and the COVER SNR C H E C K P O I N T when performing the following work.
Page 250 AcuLaser C2800/C2800D/C3800/C3800D Revision C Blue Blue 7)-1 7)-2 FEEDER ASSY Kmy03028EA 7)-2 If your screwdriver is not long enough to perform the following work, close the COVER C H E C K P O I N T ASSY FRONT for easier operation.
Page 251 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:CST NO PAPER ACTUATOR NO PAPER A4 HOLDER NO ACTUATOR PAPER L A4 NO PAPER A4 ACTUATOR NO PAPER A4 SENSOR PHOTO: 3) (J2321) Stopper CST NO PAPER 1)-2 Kmy03217EA 1. Remove the screw (silver, 6 mm) that secures the HOLDER NO SNR to the FEEDER ASSY, and 1)-1 remove the HOLDER NO SNR.
Page 252 AcuLaser C2800/C2800D/C3800/C3800D Revision C PWBA OHP SNR 3) (J2411) PWBA OHP SNR Kmy03221EA 1. Insert a mini screwdriver or a similar tool into the square hole of the COVER OHP SNR to release the tab, and remove the COVER OHP SNR.
Page 253: Paper Feeder (Part 4)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.11 PAPER FEEDER (PART 4) DISASSEMBLED PARTS ACTUATOR A Table 4-10. List of Disassembled Parts Name Guide CLUTCH ASSY PH TURN ROLL ASSY TURN ACTUATOR A ACTUATOR B ACTUATOR B SENSOR PHOTO:REGI PWBA OHP LED LOCATION...
Page 254 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C CASSETTE ASSY 550 IOT COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 255 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03003EA Kmy03044EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 256 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 257 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE ASSY PH HARNESS ASSY-CON F (White) Figure-B KIT MOT ASSY PH KIT GEAR ASSY PH Ground Wire Attach to the (Green) main unit HARNESS ASSY FRONT COVER (Black) Attach to GEAR MSI 2)-1 2)-2 Kmy03094EA Kmy03019EA 3.
Page 258 AcuLaser C2800/C2800D/C3800/C3800D Revision C 8)-2 DRIVE ASSY PH 8)-1 Kmy03061EB Kmy03060EB 9. Remove the four screws (silver, self-tapping, 10 mm) that secure the DRIVE ASSY PH to the main Make sure that the ground wire (green), HARNESS ASSY-CON F (white), and HARNESS unit.
Page 259 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT MOT ASSY PH CLUTCH ASSY PH REGI Gray Gray Gray Kmy03024EB CLUTCH ASSY PH REGI The mid connector should remain connected to the main unit. C H E C K P O I N T...
Page 260 AcuLaser C2800/C2800D/C3800/C3800D Revision C TRANSFER UNIT 2)-2 TRANSFER UNIT 1)-1 1)-1 1)-2 2)-1 Kmy03031EA Kmy03030EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER Do not touch or damage the BELT section of the TRANSFER UNIT.
Page 261 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROLL ASSY MSI 3)-1 3)-2 3)-1 3)-2 Attach to the main unit Attach to GEAR MSI White 2)-1 2)-2 Black Kmy03021EA ROLL ASSY MSI Kmy03080EA 1. Remove the SPRING FEED MSI from the main unit. Mind the correct orientations when installing the SPRING FEED MSI.
Page 262 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH ASSY PH FEED FEEDER ASSY Yellow Yellow Kmy03026EA CLUTCH ASSY PH FEED Yellow Kmy03025EB It is not necessary to remove the SENSOR PHOTO:MSI NO PAPER and the COVER SNR C H E C K P O I N T when performing the following work.
Page 263 AcuLaser C2800/C2800D/C3800/C3800D Revision C Blue Blue 7)-1 7)-2 FEEDER ASSY Kmy03028EA 7)-2 If your screwdriver is not long enough to perform the following work, close the COVER C H E C K P O I N T ASSY FRONT for easier operation.
Page 264 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH ASSY PH TURN ROLL ASSY TURN ROLL ASSY TURN 3) (Black) CLUTCH ASSY PH TURN 2) (White) Kmy03215EA Kmy03218EA 1. Loosen the two clamps that secure the harness of the CLUTCH ASSY PH TURN, and detach the 1.
Page 265 AcuLaser C2800/C2800D/C3800/C3800D Revision C ACTUATOR A ACTUATOR B 2)-1 ACTUATOR A 3)-2 2)-2 3)-1 Kmy03214EA 3)-1 ACTUATOR B Kmy03213EB 3. Release the tab on the downside of the COVER ACTUATOR with a mini screwdriver or a similar 1. Remove the three screws (silver, self-tapping, 8 mm) that secure the CHUTE ASSY REGI UPPER.
Page 266 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:REGI 2)-1 2)-2 4) (J2322) Kmy03216EA Kmy03213EB SENSOR PHOTO:REGI 3. Release the three tabs that secure the SENSOR PHOTO:REGI to the CHUTE ASSY REGI UPPER, 1. Remove the three screws (silver, self-tapping, 8 mm) that secure the CHUTE ASSY REGI UPPER.
Page 267 AcuLaser C2800/C2800D/C3800/C3800D Revision C PWBA OHP LED 2)-1 Groove Groove Kmy03220EB PWBA OHP LED 2)-2 4) (J2412) Kmy03213EB 3. Remove the two screws (silver, self-tapping, 8 mm) that secure the PWBA OHP LED to the CHUTE 1. Remove the three screws (silver, self-tapping, 8 mm) that secure the CHUTE ASSY REGI UPPER.
Page 268: Transfer (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.12 TRANSFER (PART 1) LOCATION DISASSEMBLED PARTS Table 4-11. List of Disassembled Parts Name Guide TRANSFER UNIT TRANSFER UNIT DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 269 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER ASSY FRONT TRANSFER UNIT COVER ASSY FRONT LATCH 1)-1 1)-1 1) -2 1) -1 1)-2 Kmy03030EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT. Do not touch or damage the BELT section of the TRANSFER UNIT.
Page 270 AcuLaser C2800/C2800D/C3800/C3800D Revision C 2)-2 TRANSFER UNIT 2)-1 Kmy03031EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER ASSY FRONT, remove the guide pin on the left side of the TRANSFER UNIT from the hole on the COVER ASSY FRONT, and remove the TRANSFER UNIT.
Page 271: Xerographics (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.13 XEROGRAPHICS (PART 1) LOCATION IMAGING CARTRIDGE (K), (C), (M), (Y) DISASSEMBLED PARTS Table 4-12. List of Disassembled Parts Name Guide IMAGING CARTRIDGE (K), (C), (M), (Y) DISPENSER ASSY (K), (C), (M), (Y) VISOR ASSY LABEL...
Page 272 AcuLaser C2800/C2800D/C3800/C3800D Revision C LEVER VISOR LEVER VISOR CRU L CRU R SPRING VISOR CRU Kmy03085EA SENSOR ASSY CRU (C), (M), (Y) LED ASSY VISOR ASSY LABEL DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 273 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C D A B C D COVER ASSY FRONT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER ASSY FRONT IMAGING CARTRIDGE LATCH 1) -2 1) -1 Kmy03044EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 274 AcuLaser C2800/C2800D/C3800/C3800D Revision C A C D COVER REAR COVER SIDE L COVER SIDE L COVER REAR 4)-1 4)-1 4)-1 4)-1 4)-2 Kmy03006EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 275 AcuLaser C2800/C2800D/C3800/C3800D Revision C DISPENSER ASSY (K), (C), (M), (Y) DISPENSER ASSY (K) DISPENSER ASSY (C) DISPENSER ASSY (M) DISPENSER ASSY (Y) Kmy03038EA Kmy03039EA There are four MOTOR ASSY Gasps and they can be removed in the same manner. C H E C K P O I N T 4.
Page 276 AcuLaser C2800/C2800D/C3800/C3800D Revision C VISOR ASSY LABEL LEVER VISOR CRU R LEVER VISOR CRU L SPRING VISOR CRU VISOR ASSY LABEL Kmy03084EA Kmy03083EA 3. Slide the LEVER VISOR CRU R and the LEVER VISOR CRU L inward, and remove the VISOR 1.
Page 277 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF LEVER VISOR CRU L LEVER VISOR CRU R COVER SIDE IF SPRING VISOR CRU 1)-1 SPRING VISOR CRU 1)-2 1)-1 Kmy03085EA Kmy03008EA 4. Turn the LEVER VISOR CRU R, and remove the LEVER VISOR CRU R aligning its shaft with the 1.
Page 278 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE R SENSOR ASSY CRU (C), (M), (Y) COVER SIDE R SENSOR ASSY CRU (C) 4)-1 4)-1 SENSOR ASSY CRU (M) SENSOR ASSY CRU (Y) 4)-1 4)-1 4)-2 Kmy03036EB Kmy03005EA Remove the screw (silver, self-tapping, 10 mm) that secures the SENSOR ASSY CRU to the main unit.
Page 279 AcuLaser C2800/C2800D/C3800/C3800D Revision C LED ASSY 4)-1 LED ASSY 4)-2 4)-1 Kmy03041EA 1. Remove the two screws (silver, self-tapping, 8 mm) that secure the DUCT SIDE L to the main unit. 2. Remove the DUCT SIDE L from the main unit.
Page 280: Xerographics (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.14 XEROGRAPHICS (PART 2) LOCATION DISASSEMBLED PARTS SENSOR ASSY CRU (K) Table 4-13. List of Disassembled Parts Name Guide SENSOR ASSY CRU (K) CONNECTOR CRUM ROS ASSY HVPS HOUSING ASSY B SENSOR PHOTO:TONER CARTRIDGE CONNECTOR CRUM...
Page 281 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROS ASSY HOUSING ASSY B HVPS SENSOR PHOTO:TONER CARTRIDGE DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 282 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D COVER ASSY FRONT FUSER UNIT FUSER UNIT COVER ASSY FRONT LATCH 1) -2 1) -1 Kmy03046EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 283 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C D A B C D COVER REAR IMAGING CARTRIDGE (M) IMAGING IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03044EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 284 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D COVER SIDE L COVER SIDE IF COVER SIDE L COVER SIDE IF 4)-1 4)-1 1)-1 1)-2 4)-1 1)-1 4)-1 4)-2 Kmy03006EA Kmy03008EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 285 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D COVER SIDE R COVER TOP COVER TOP COVER SIDE R 3)-1 4)-1 4)-1 3)-2 4)-1 4)-1 4)-2 Kmy03005EA 1. Remove the four screws (silver, self-tapping, 10 mm) and the screw (silver, brimmed, self-tapping, As the FUSER UNIT remains at hazardous temperature after turning the power off, be 10 mm) that secure the COVER TOP to the main unit.
Page 286 AcuLaser C2800/C2800D/C3800/C3800D Revision C HARNESS ASSY INTERLOCK 2)-1 2)-2 2)-1 HARNESS ASSY INTERLOCK Kmy03064EA 1. Disconnect the connector (P/J44) of the HARNESS ASSY INTERLOCK on the LVPS. 2. Loosen the clamp attached to the SHIELD LVPS that secures the harness of the HARNESS ASSY INTERLOCK.
Page 287 AcuLaser C2800/C2800D/C3800/C3800D Revision C 1. Release the harness of the HARNESS ASSY USB from the DUCT DRV MAIN. 2. Remove the two screws (silver, self-tapping, 10 mm) that secure the BRACKET FUSER to the main unit. DRIVE ASSY MAIN Do not pull the BRACKET FUSER too far from the main unit as they are connected with a harness.
Page 288 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR ASSY CRU (K) SENSOR ASSY CRU (K) Kmy03059EA Kmy03035EA DRIVE ASSY MAIN 9. Remove the six screws (silver, self-tapping, 10 mm) that secure the DRIVE ASSY MAIN to the main 1. Remove the screw (silver, self-tapping, 10 mm) that secures the SENSOR ASSY CRU (K) to the unit.
Page 289 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR ASSY CRU (C), (M), (Y) CONNECTOR CRUM 1)-2 SENSOR ASSY CRU (C) 1)-1 SENSOR ASSY CRU (M) SENSOR ASSY CRU (Y) CONNECTOR CRUM Kmy03036EB Kmy03034EB Remove the screw (silver, self-tapping, 10 mm) that secures the SENSOR ASSY CRU to the main unit.
Page 290 AcuLaser C2800/C2800D/C3800/C3800D Revision C FAN MAIN SHIELD ASSY ESS LABEL Kmy03067EC Kmy03073EC FAN MAIN 1. Disconnect the connector (P/J503) of the FAN MAIN on the LVPS. Do not remove/install the board in areas where static sparks may be generated. 2. Loosen the clamp that secures the harness of the FAN MAIN, and detach the harness.
Page 291 AcuLaser C2800/C2800D/C3800/C3800D Revision C SHIELD ASSY ESS 5) 5) Kmy03074EC 3. Disconnect all the connectors on the BOARD ASSY, MAIN. 4. Loosen the clamp that secures the harness connected to CN501 connector on the BOARD ASSY, MAIN. 5. Remove the two screws (silver, washer, 6 mm) that secure the ground wires of the HARNESS ASSY- CON R and the HARNESS ASSY USB to the SHIELD ASSY ESS E.
Page 292 AcuLaser C2800/C2800D/C3800/C3800D Revision C Do not remove/install the board in areas where static sparks may be generated. (e.g. on a carpet) Be sure to touch a metal part to discharge any static electricity you might LVPS have before removing/installing the board.
Page 293 AcuLaser C2800/C2800D/C3800/C3800D Revision C ROS ASSY LVPS 2)-2 2)-1 Kmy03066EB Kmy03032EA 5. Remove the six screws (silver, 6 mm) that secure the LVPS to the SHIELD LVPS. 1. Disconnect connector of the ROS ASSY (P/J12) on the PWBA MCU. 6. Remove the LVPS from the SHIELD LVPS.
Page 294 AcuLaser C2800/C2800D/C3800/C3800D Revision C Handle HVPS ROS ASSY 1)-2 1)-1 Kmy03042EA Kmy03033EA 3. Remove the four screws (silver, self-tapping, 10 mm) that secure the two SPRING ROSes to the main unit. Do not remove/install the board in areas where static sparks may be generated.
Page 295 AcuLaser C2800/C2800D/C3800/C3800D Revision C LED ASSY 5)-2 4)-1 LED ASSY 5)-1 4)-2 4)-1 Kmy03043EA HVPS Kmy03041EA 2. Remove the two screws (silver, washer, 6 mm) that secure the two harnesses coming out of the HVPS. Secure the red harness to the upper side and the white harness to the downside of the 1.
Page 296 AcuLaser C2800/C2800D/C3800/C3800D Revision C HOUSING ASSY B Kmy03040EA Kmy03081EA HOUSING ASSY B 4. Remove the screw (silver, self-tapping, 10 mm) that secures the SPRING ESA ROLL to the The mid-connector should remain connected to the main unit. C H E C K P O I N T HOUSING ASSY B.
Page 297 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:TONER CARTRIDGE 1)-2 1)-1 1)-3 SENSOR PHOTO: TONER CARTRIDGE Kmy03037EA There are four SENSOR PHOTO:TONER CARTRIDGEs and they can be removed in the C H E C K P O I N T same manner.
Page 298: Fuser & Exit (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.15 FUSER & EXIT (PART 1) FUSER UNIT DISASSEMBLED PARTS Table 4-14. List of Disassembled Parts Name Guide CHUTE ASSY EXIT OUT FUSER UNIT CHUTE DUP GATE LOCATION CHUTE ASSY EXIT OUT CHUTE DUP GATE DISASSEMBLY/REASSEMBLY...
Page 299 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C COVER ASSY FRONT CHUTE ASSY EXIT OUT COVER ASSY FRONT LATCH 1) -2 1) -1 Kmy03045EA CHUTE ASSY EXIT OUT 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 300 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSER UNIT CHUTE DUP GATE CHUTE DUP GATE FUSER UNIT 1)-2 1)-1 Kmy03046EA Kmy03047EA Be careful not to burn yourself as the FUSER section remains at high temperature after Be careful not to burn yourself as the FUSER section remains at high temperature after turning the power off.
Page 301: Frame (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.16 FRAME (PART 1) LOCATION DISASSEMBLED PARTS Table 4-15. List of Disassembled Parts Name Guide GUIDE TRAY R 550 SWITCH ASSY SIZE GUIDE ASSY L 550 GUIDE TRAY R 550 SWITCH ASSY SIZE DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 302 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C CASSETTE ASSY 550 IOT GUIDE ASSY L 550 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 303 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C COVER ASSY FRONT COVER CST 550 COVER ASSY FRONT LATCH 1) -2 1) -1 2)-2 2)-1 Kmy03004EA COVER CST 550 1. Pull the COVER CST 550 toward you as far as it will go.
Page 304 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C A B C COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03003EA Kmy03044EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 305 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 306 AcuLaser C2800/C2800D/C3800/C3800D Revision C SWITCH ASSY SIZE GUIDE TRAY R 550 2)-2 2)-1 SWITCH ASSY SIZE Kmy03053EB Kmy03055EB 1. Loosen the clamp attached to the SWITCH ASSY SIZE and release the harness. 1. Remove the screw (silver, brimmed, self-tapping, 8 mm) that secures the GUIDE TRAY R 550 to the main unit.
Page 307 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE L COVER SIDE L 4)-1 4)-1 GUIDE TRAY R 550 4)-1 Kmy03054EB 4)-1 4)-2 Kmy03006EA 3. Remove the GUIDE TRAY R 550 from the rear side of the main unit by laying the GUIDE TRAY R As the FUSER UNIT remains at hazardous temperature after turning the power off, be 550 inward.
Page 308 AcuLaser C2800/C2800D/C3800/C3800D Revision C GUIDE ASSY L 550 2)-2 GUIDE ASSY L 550 Kmy03057EB 2)-1 Kmy03056EB 3. Remove the GUIDE ASSY L 550 from the rear side of the main unit by laying the GUIDE ASSY L 1. Remove the screw (silver, brimmed, self-tapping, 8 mm) that secures the GUIDE ASSY L 550 to the 550 inward.
Page 309: Frame (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.17 FRAME (PART 2) LOCATION DISASSEMBLED PARTS HOLDER ASSY WHEEL STAR Table 4-16. List of Disassembled Parts Name Guide HOLDER ASSY WHEEL STAR LINK L KIT HOLDER ASSY DAMPER L LEVER RELEASE LINK R KIT HOLDER ASSY DAMPER R...
Page 310 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT HOLDER ASSY DAMPER L A B C COVER ASSY FRONT LEVER RELEASE COVER ASSY FRONT LATCH LINK L 1) -2 1) -1 KIT HOLDER ASSY DAMPER R LEVER RELEASE 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 311 AcuLaser C2800/C2800D/C3800/C3800D Revision C FUSER UNIT HOLDER ASSY WHEEL STAR HOLDER ASSY WHEEL STAR FUSER UNIT Kmy03046EA Kmy03048EA Be careful not to burn yourself as the FUSER section remains at high temperature after HOLDER ASSY WHEEL STAR on the other side can be removed in the same manner.
Page 312 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) COVER REAR IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER REAR IMAGING CARTRIDGE Kmy03044EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 313 AcuLaser C2800/C2800D/C3800/C3800D Revision C LINK L KIT HOLDER ASSY DAMPER L COVER SIDE L LEVER RELEASE COVER SIDE L 4)-1 4)-1 4)-1 1)-1 1)-3 4)-1 4)-2 Kmy03006EA Kmy03049EA 1)-2 1. Release the tab on the SHAFT PIVOT that secures the LINK L to the COVER ASSY FRONT, pull As the FUSER UNIT remains at hazardous temperature after turning the power off, be out the SHAFT PIVOT, and remove the LINK L from the COVER ASSY FRONT.
Page 314 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF (Black) COVER SIDE IF 1)-1 1)-2 LEVER RELEASE KIT HOLDER ASSY 1)-1 DAMPER L LINK L Kmy03050EB Kmy03008EA 4. Remove the LEVER RELEASE from the main unit. 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 315 AcuLaser C2800/C2800D/C3800/C3800D Revision C LINK R KIT HOLDER ASSY DAMPER L COVER SIDE R LEVER RELEASE COVER SIDE R 4)-1 4)-1 4)-1 1)-3 1)-1 4)-1 4)-2 1)-2 Kmy03051EA Kmy03005EA 1. Release the tab on the SHAFT PIVOT that secures the LINK R to the COVER ASSY FRONT, pull As the FUSER UNIT remains at hazardous temperature after turning the power off, be out the SHAFT PIVOT, and remove the LINK R from the COVER ASSY FRONT.
Page 316 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT HOLDER ASSY DAMPER R Yellow LEVER RELEASE LINK R Kmy03052EB 4. Remove the LEVER RELEASE from the main unit. Mind the correct orientation when installing the LEVER RELEASE. Install the LEVER RELEASE in reference to the illustration.
Page 317: Drive
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.18 DRIVE LOCATION DISASSEMBLED PARTS KIT MOT ASSY PH Table 4-17. List of Disassembled Parts Name Guide DRIVE ASSY PH KIT MOT ASSY PH KIT GEAR ASSY PH KIT GEAR ASSY PH DRIVE ASSY MAIN DRIVE ASSY PH...
Page 318 AcuLaser C2800/C2800D/C3800/C3800D Revision C CASSETTE ASSY 550 IOT COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 CASSETTE ASSY 550 IOT 1. Pull the CASSETTE ASSY 550 IOT out. 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 319 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) FUSER UNIT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) FUSER UNIT IMAGING CARTRIDGE Kmy03046EA Kmy03044EA Be careful not to burn yourself as the FUSER section remains at high temperature after There are four IMAGING CARTRIDGEs and they can be removed in he same manner.
Page 320 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER REAR COVER SIDE L COVER SIDE L COVER REAR 4)-1 4)-1 4)-1 4)-1 4)-2 Kmy03006EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit. As the FUSER UNIT remains at hazardous temperature after turning the power off, be 2.
Page 321 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 322 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE ASSY PH HARNESS ASSY-CON F (White) Figure-B KIT MOT ASSY PH KIT GEAR ASSY PH Ground Wire Attach to the (Green) main unit HARNESS ASSY FRONT COVER (Black) Attach to GEAR MSI 2)-1 2)-2 Kmy03094EA Kmy03019EA 3.
Page 323 AcuLaser C2800/C2800D/C3800/C3800D Revision C 8)-2 DRIVE ASSY PH 8)-1 Kmy03061EB Kmy03060EB 9. Remove the four screws (silver, self-tapping, 10 mm) that secure the DRIVE ASSY PH to the main Make sure that the ground wire (green), HARNESS ASSY-CON F (white), and HARNESS unit.
Page 324 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT MOT ASSY PH COVER TOP COVER TOP 3)-1 3)-2 KIT GEAR ASSY PH Kmy03086EB 12. Remove the three screws (silver, 6 mm) that secure the KIT MOT ASSY PH to the KIT GEAR 1. Remove the four screws (silver, self-tapping, 10 mm) and the screw (silver, brimmed, self-tapping, ASSY PH.
Page 325 AcuLaser C2800/C2800D/C3800/C3800D Revision C HARNESS ASSY INTERLOCK DRIVE ASSY MAIN 2)-1 2)-2 2)-1 HARNESS ASSY INTERLOCK 6)-1 6)-2 8)-1 8)-1 8)-2 Kmy03064EA Kmy03058EA 1. Disconnect the connector (P/J44) of the HARNESS ASSY INTERLOCK on the LVPS. 1. Release the harness of the HARNESS ASSY USB from the DUCT DRV MAIN.
Page 326 AcuLaser C2800/C2800D/C3800/C3800D Revision C DRIVE ASSY MAIN Kmy03059EA 6. Release the guide pin of the DUCT DRV MAIN, slide the DUCT DRV MAIN to the rear side of the printer, and remove the DRIVE ASSY MAIN. 7. Disconnect the following connectors: connector of the MAIN MOTOR (P/J211) inside the DRIVE ASSY MAIN, connector of the SUB MOTOR (P/J221), connector of the DEVE MOTOR (P/J222), and connector of the EXIT CLUTCH (P/J2761).
Page 327: Electrical (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.19 ELECTRICAL (PART 1) LOCATION HARNESS ASSY INTERLOCK DISASSEMBLED PARTS Table 4-18. List of Disassembled Parts Name Guide HARNESS ASSY INTERLOCK FAN MAIN LVPS HARNESS ASSY INLET FAN MAIN DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 328 AcuLaser C2800/C2800D/C3800/C3800D Revision C LVPS A B C COVER ASSY FRONT COVER ASSY FRONT LATCH 1) -2 1) -1 HARNESS ASSY INLET 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT. DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 329 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C A B C FUSER UNIT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) FUSER UNIT IMAGING CARTRIDGE Kmy03046EA Kmy03044EA Be careful not to burn yourself as the FUSER section remains at high temperature after There are four IMAGING CARTRIDGEs and they can be removed in the same manner.
Page 330 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C COVER REAR COVER SIDE L COVER REAR COVER SIDE L 4)-1 4)-1 4)-1 4)-1 4)-2 Kmy03006EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 331 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C COVER SIDE IF COVER SIDE R COVER SIDE R 4)-1 1)-1 4)-1 1)-2 COVER SIDE IF 4)-1 1)-1 4)-1 4)-2 Kmy03008EA Kmy03005EA 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 332 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C COVER TOP HARNESS ASSY INTERLOCK 2)-1 COVER TOP 2)-2 2)-1 HARNESS ASSY 3)-1 INTERLOCK 3)-2 Kmy03064EA 1. Remove the four screws (silver, self-tapping, 10 mm) and the screw (silver, brimmed, self-tapping, 1. Disconnect the connector (P/J44) of the HARNESS ASSY INTERLOCK on the LVPS.
Page 333 AcuLaser C2800/C2800D/C3800/C3800D Revision C FAN MAIN LABEL Kmy03067EC FAN MAIN 1. Disconnect the connector (P/J503) of the FAN MAIN on the LVPS. 2. Loosen the clamp that secures the harness of the FAN MAIN, and detach the harness. 3. Release the harness of the FAN MAIN from the tab on the main unit.
Page 334 AcuLaser C2800/C2800D/C3800/C3800D Revision C Do not remove/install the board in areas where static sparks may be generated. (e.g. on a carpet) Be sure to touch a metal part to discharge any static electricity you might LVPS have before removing/installing the board.
Page 335 AcuLaser C2800/C2800D/C3800/C3800D Revision C LVPS Kmy03066EB 5. Remove the six screws (silver, 6 mm) that secure the LVPS to the SHIELD LVPS. 6. Remove the LVPS from the SHIELD LVPS. DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 336 AcuLaser C2800/C2800D/C3800/C3800D Revision C 1. Disconnect the connector (P/J48) of the HARNESS ASSY INLET on the LVPS. 2. Disconnect the connector (P/J481) connected to the SWITCH POWER. HARNESS ASSY INLET 3. Remove the screw (silver, external tooth washer, 6 mm) that secures the ground terminal of the HARNESS ASSY INLET to the main unit.
Page 337: Electrical (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.20 ELECTRICAL (PART 2) DISASSEMBLED PARTS SWITCH POWER PWBA USB Table 4-19. List of Disassembled Parts Name Guide PWBA EEPROM XPRO PWBA USB SWITCH POWER BOARD ASSY, MAIN LOCATION PWBA EEPROM XPRO BOARD ASSY, MAIN DISASSEMBLY/REASSEMBLY...
Page 338 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) A B C D A B C D COVER ASSY FRONT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER ASSY FRONT LATCH IMAGING CARTRIDGE 1) -2 1) -1 Kmy03044EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 339 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D A B C D COVER REAR COVER SIDE IF COVER REAR 1)-1 1)-2 COVER SIDE IF 1)-1 Kmy03008EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit.
Page 340 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D COVER SIDE R PWBA EEPROM XPRO (XPRO) COVER SIDE R PWBA EEPROM XPRO (XPRO) 4)-1 4)-1 4)-1 4)-1 4)-2 Kmy03062EB Kmy03005EA 1. Disconnect the connector (P/J274) of the PWBA EEPROM XPRO. As the FUSER UNIT remains at hazardous temperature after turning the power off, be careful not to burn yourself.
Page 341 AcuLaser C2800/C2800D/C3800/C3800D Revision C PWBA USB SWITCH POWER PWBA USB SWITCH POWER 2)-2 2)-1 2)-1 Kmy03070EB Kmy03063EA 1. Disconnect the connector (CN2) of the PWBA USB. 1. Disconnect connector (P/J481) of the SWITCH POWER. 2. Remove the two screws (silver, 6 mm) that secure the PWBA USB to the main unit.
Page 342 AcuLaser C2800/C2800D/C3800/C3800D Revision C BOARD ASSY, MAIN BOARD ASSY, MAIN Kmy03071EB Kmy03072EB 4. Remove the screw that secures the USB connector of the BOARD ASSY, MAIN. Do not remove/install the board in areas where static sparks may be generated. 5. Remove the four screws (silver, 6 mm) that secure the SHIELD ASSY IF E to the main unit.
Page 343: Electrical (Part 3)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.21 ELECTRICAL (PART 3) DISASSEMBLED PARTS Table 4-20. List of Disassembled Parts Name Guide SHIELD ASSY ESS SENSOR HUM PWBA MCU LOCATION SENSOR HUM PWBA MCU SHIELD ASSY ESS DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 344 AcuLaser C2800/C2800D/C3800/C3800D Revision C IMAGING CARTRIDGE (K) IMAGING CARTRIDGE (C) COVER ASSY FRONT IMAGING CARTRIDGE (M) IMAGING CARTRIDGE (Y) COVER ASSY FRONT IMAGING CARTRIDGE LATCH 1) -2 1) -1 Kmy03044EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 345 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER REAR COVER SIDE IF COVER REAR 1)-1 1)-2 COVER SIDE IF 1)-1 Kmy03008EA Kmy03003EA 1. Remove the four screws (silver, self-tapping, 10 mm) that secure the COVER REAR to the main unit. 1. Release the two tabs on the COVER SIDE IF, and remove the COVER SIDE IF.
Page 346 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER SIDE R COVER SIDE L COVER SIDE L COVER SIDE R 4)-1 4)-1 4)-1 4)-1 4)-1 4)-1 4)-1 4)-1 4)-2 4)-2 Kmy03006EA Kmy03005EA As the FUSER UNIT remains at hazardous temperature after turning the power off, be As the FUSER UNIT remains at hazardous temperature after turning the power off, be careful not to burn yourself.
Page 347 AcuLaser C2800/C2800D/C3800/C3800D Revision C SHIELD ASSY ESS SHIELD ASSY ESS 5) 5) Kmy03073EC Kmy03074EC 3. Disconnect all the connectors on the BOARD ASSY, MAIN. Do not remove/install the board in areas where static sparks may be generated. 4. Loosen the clamp that secures the harness connected to CN501 and CN601 connector on the BOARD (e.g.
Page 348 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR HUM PWBA MCU (P12) (P16) (P17) (P14) 1)-1 (P19) SENSOR HUM (P15) 1)-2 (P10) (P18) (P22) (P21) (P25) (P101) Kmy03068EC (P23) (P31) (P24) (P26) (P27) PWBA MCU Kmy03069EC Do not remove/install the board in areas where static sparks may be generated.
Page 349: Duplex
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.22 DUPLEX LOCATION DISASSEMBLED PARTS FEEDER ASSY DUP Table 4-21. List of Disassembled Parts Name Guide FEEDER ASSY DUP COVER PWBA DUP ACTUATOR DUP SENSOR PHOTO: DUP, JAM PWBA DUP-H COVER PWBA DUP CLUTCH DUP ROLL ASSY DUP-1...
Page 350 AcuLaser C2800/C2800D/C3800/C3800D Revision C ACTUATOR DUP CLUTCH DUP SENSOR PHOTO: DUP, JAM ROLL ASSY DUP-1 PWBA DUP-H DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 351 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D E A B C D E COVER ASSY FRONT TRANSFER UNIT COVER ASSY FRONT LATCH 1)-1 1)-1 1) -2 1) -1 1)-2 Kmy03030EA 1. Press the latch on the COVER ASSY FRONT and open the COVER ASSY FRONT.
Page 352 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D E FEEDER ASSY DUP 2)-2 TRANSFER UNIT FEEDER ASSY DUP 1)-2 1)-1 2)-1 Kmy03031EA Kmy03075EA 2. Disengage the guide pin on the right side of the TRANSFER UNIT from the cutout of the COVER 1.
Page 353 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D E COVER PWBA DUP ACTUATOR DUP COVER PWBA DUP 1)-2 FEEDER ASSY DUP 1)-1 1)-1 1)-1 1)-1 Kmy03222EA Kmy03225EA 1. Release the four tabs that secure the COVER PWBA DUP to the FEEDER ASSY DUP, and remove 1.
Page 354 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:DUP, JAM PWBA DUP-H 1)-1 PWBA DUP-H (P427) (P429) (P430) (P428) (P431) SENSOR PHOTO:DUP, JAM 1)-2 Ground Wire Kmy03224EA Kmy03223EA 1. Release the three tabs that secure the SENSOR PHOTO:DUP, JAM to the HOLDER SENSOR DUP, 1.
Page 355 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH DUP ROLL ASSY DUP-1 (J431) CLUTCH DUP Kmy03228EA Kmy03227EA 1. Disconnect the connector (P/J431) of the CLUTCH DUP on the PWBA DUP-H. 1. Remove the SPRING DUP from the BRACKET CLUTCH DUP. 2. Loosen the two clamps that secure the harness of the CLUTCH DUP to the FEEDER ASSY DUP, 2.
Page 356 AcuLaser C2800/C2800D/C3800/C3800D Revision C FAN DUP ROLL ASSY DUP-1 2)(J427) Label Side Kmy03229EA FAN DUP Kmy03226EB 1. Release the four tabs that secure the COVER HARNESS CHUTE, and remove the COVER HARNESS CHUTE. 2. Disconnect the connector (P/J427) of the FAN DUP on the PWBA DUP-H.
Page 357 AcuLaser C2800/C2800D/C3800/C3800D Revision C MOTOR ASSY DUP ROLL ASSY DUP-2 ROLL ASSY DUP-2 MOTOR ASSY DUP 3)-2 Ground Wire (J429) Kmy03231EB 3)-1 Kmy03230EA 1. Loosen the three clamps to remove the harness of the MOTOR ASSY DUP. 1. Remove the three screws (silver, self-tapping, 10 mm) that secure the BRACKET MOTOR DUP to the FEEDER ASSY DUP, and remove the BRACKET MOTOR DUP.
Page 358: Option Feeder (Part 1)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.23 550 OPTION FEEDER (PART 1) DISASSEMBLED PARTS Table 4-22. List of Disassembled Parts Name Guide COVER CST 550 (OPT) GUIDE TRAY R 550 550 OPTION FEEDER GUIDE ASSY 550 L 550 OPTION FEEDER LOCATION COVER CST 550 (OPT)
Page 359 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C CASSETTE ASSY 550 IOT COVER CST 550 COVER CST 550 2)-2 2)-1 CASSETTE ASSY 550 IOT Kmy03004EA 1. Pull the CASSETTE ASSY 550 IOT out. 1. Pull the COVER CST 550 toward you as far as it will go.
Page 360 AcuLaser C2800/C2800D/C3800/C3800D Revision C CASSETTE ASSY 550 OPT COVER CST 550 (OPT) 2)-2 2)-1 CASSETTE ASSY 550 OPT Kmy03077EA COVER CST 550 (OPT) 1. Remove the CASSETTE ASSY 550 OPT. 1. Pull the COVER CST 550 (OPT) toward you as far as it will go.
Page 361 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER RIGHT SWITCH ASSY SIZE 1) (J4211) SWITCH ASSY SIZE COVER RIGHT Kmy03236EA Kmy03235EA 1. Remove the four screws (silver, brimmed, 8 mm) that secure the COVER RIGHT to the FRAME 1. Disconnect the connector (P/J4211) that is connected to the SWITCH ASSY SIZE.
Page 362 AcuLaser C2800/C2800D/C3800/C3800D Revision C GUIDE TRAY R 550 550 OPTION FEEDER 550 OPTION FEEDER GUIDE TRAY R 550 Kmy03076EA Kmy03239EB 1. Remove the screw (silver, self-tapping, 8 mm) that secures the GUIDE TRAY R 550 to the FRAME 1. Remove the two SCREW JOINTs that secure 550 OPTION FEEDER to the main unit.
Page 363 AcuLaser C2800/C2800D/C3800/C3800D Revision C COVER LEFT GUIDE ASSY 550 L 2)-1 2)-2 2)-3 GUIDE ASSY 550 L COVER LEFT 2)-4 Kmy03232EA Kmy03240EB 1. Remove the two screws (silver, brimmed, 8 mm) that secure the COVER LEFT to the FRAME 1. Remove the screw (silver, self-tapping, 8 mm) that secures the GUIDE ASSY 550 L to the FRAME ASSY OPT.
Page 364: Option Feeder (Part 2)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.24 550 OPTION FEEDER (PART 2) DISASSEMBLED PARTS FEEDER ASSY UNIT OPT Table 4-23. List of Disassembled Parts Name Guide COVER LEFT FEEDER ASSY UNIT OPT ROLL ASSY TURN SENSOR PHOTO: CST NO PAPER SENSOR PHOTO:...
Page 365 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C CASSETTE ASSY 550 OPT COVER LEFT CASSETTE ASSY 550 OPT COVER LEFT Kmy03232EA 1. Remove the CASSETTE ASSY 550 OPT. 1. Remove the two screws (silver, brimmed, 8 mm) that secure the COVER LEFT to the FRAME ASSY OPT.
Page 366 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C COVER RIGHT CLUTCH ASSY TURN OPT CLUTCH ASSY TURN OPT 1) (J4201) COVER RIGHT Kmy03233EB Kmy03235EA 1. Remove the four screws (silver, brimmed, 8 mm) that secure the COVER RIGHT to the FRAME 1.
Page 367 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C A B C CLUTCH ASSY FEED OPT FEEDER ASSY UNIT OPT CLUTCH ASSY FEED OPT 1) (J4212) 1) (J4213) Kmy03234EA Kmy03241EA 1. Disconnect the connector (P/J4213) on the harness of the CLUTCH ASSY FEED OPT.
Page 368 AcuLaser C2800/C2800D/C3800/C3800D Revision C FEEDER ASSY UNIT OPT ROLL ASSY TURN 4)-2 4)-2 ROLL ASSY TURN 2) (White) 3) (Black) 4)-1 4)-1 Kmy03243EA Kmy03242EA 4. Release the protrusions on the left and right ends of the FEEDER ASSY UNIT OPT from the 1.
Page 369 AcuLaser C2800/C2800D/C3800/C3800D Revision C SENSOR PHOTO:CST NO PAPER ACTUATOR NO PAPER A4 ACTUATOR NO PAPER A4 1)-1 4) (J42121) 1)-2 HOLDER NO SENSOR PHOTO:CST NO PAPER PAPER L A4 1)-2 1)-1 ACTUATOR NO PAPER A4 Stopper Kmy03245EA Kmy03244EB 1. Loosen the HARNESS ASSY C2 NO PAPER wrapped around the FEEDER ASSY UNIT OPT, and 1.
Page 370: Option Feeder (Part 3)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.25 550 OPTION FEEDER (PART 3) LOCATION DISASSEMBLED PARTS Table 4-24. List of Disassembled Parts Name Guide COVER RIGHT CLUTCH ASSY TURN OPT DRIVE ASSY OPT FDR COVER RIGHT CLUTCH ASSY FEED OPT SWITCH ASSY SIZE...
Page 371 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D CASSETTE ASSY 550 OPT CLUTCH ASSY FEED OPT SWITCH ASSY SIZE CASSETTE ASSY 550 OPT 1. Remove the CASSETTE ASSY 550 OPT. PWBA FEED-H DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 372 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D COVER RIGHT CLUTCH ASSY TURN OPT CLUTCH ASSY TURN OPT 1) (J4201) COVER RIGHT Kmy03233EB Kmy03235EA 1. Remove the four screws (silver, brimmed, 8 mm) that secure the COVER RIGHT to the FRAME 1.
Page 373 AcuLaser C2800/C2800D/C3800/C3800D Revision C CLUTCH ASSY FEED OPT DRIVE ASSY OPT FDR CLUTCH ASSY FEED OPT 1) (J4222) 1) (J4221) 1) (J4213) DRIVE ASSY OPT FDR Kmy03234EA Kmy03238EB 1. Disconnect the connector (P/J4213) on the harness of the CLUTCH ASSY FEED OPT.
Page 374 AcuLaser C2800/C2800D/C3800/C3800D Revision C SWITCH ASSY SIZE PWBA FEED-H 1) (J4211) (P/J421) (P/J422) (P/J420) (P/J419) PWBA FEED-H SWITCH ASSY SIZE Kmy03236EA Kmy03237EA 1. Disconnect the connector (P/J4211) that is connected to the SWITCH ASSY SIZE. 1. Disconnect all the connectors on the PWBA FEED-H. (P/J419, P/J420, P/J421, P/J422) 2.
Page 375: Option Feeder (Part 4)
AcuLaser C2800/C2800D/C3800/C3800D Revision C 4.4.26 550 OPTION FEEDER (PART 4) LOCATION DISASSEMBLED PARTS KIT ROLL ASSY FEED SEC (RETARD) Table 4-25. List of Disassembled Parts Name Guide GUIDE ASSY SIDE L 550 A4 GUIDE ASSY SIDE R 550 A4 GUIDE ASSY SIDE L 550 A4...
Page 376 AcuLaser C2800/C2800D/C3800/C3800D Revision C A B C D E CASSETTE ASSY 550 OPT GUIDE ASSY CST END 550 CASSETTE ASSY 550 OPT 1. Remove the CASSETTE ASSY 550 OPT. ROLL ASSY FEED (FEED, NUDGER) DISASSEMBLY/REASSEMBLY Disassembly/Reassembly Confidential...
Page 377 AcuLaser C2800/C2800D/C3800/C3800D Revision C GUIDE ASSY SIDE R 550 A4 GUIDE ASSY SIDE L 550 A4 GUIDE ASSY SIDE L 550 A4 1)-1 5) GUIDE ASSY SIDE R 3)-2 3)-1 1)-2 6) GUIDE ASSY SIDE L :Tab GUIDE ASSY SIDE R 550 A4...
Page 378 AcuLaser C2800/C2800D/C3800/C3800D Revision C PLATE ASSY BTM A4 PLATE ASSY BTM A4 4)-1 3)-1 4)-3 4)-2 3)-2 Kmy03248EA Kmy03247EA 4. Remove the SHAFT PB A4 from the PLATE ASSY BTM A4, and remove the STOPPER PB and the 1. Remove the screw (silver, self-tapping, 10 mm) that secures the PLATE GEAR LOCK 550 on the GEAR BTM LOCK ONEWAY.
Page 379 AcuLaser C2800/C2800D/C3800/C3800D Revision C HANDLE CST 550 OPT GUIDE ASSY CST END 550 GUIDE ASSY CST END 550 1)-1 1)-1 HANDLE CST 550 OPT 2)-2 1)-2 2)-1 1)-2 Kmy03246EA Kmy03210EA 1. Turn over the CASSETTE ASSY 550 OPT, release the two guide pins with a mini screwdriver or a 1.
Page 380 AcuLaser C2800/C2800D/C3800/C3800D Revision C KIT ROLL ASSY FEED SEC (FEED, NUDGER) KIT ROLL ASSY FEED SEC (RETARD) KIT ROLL ASSY FEED SEC (RETARD) 2)-1 1)-1 2)-2 1)-2 1)-1 1)-2 1)-1 1)-1 1)-2 Kmy03078KA Kmy03079EA KIT ROLL ASSY FEED SEC (FEED, NUDGER) KIT ROLL ASSY FEED SEC consists of three rollers;...
Page 381: Chapter 5 Adjustment
C H A P T E R ADJUSTMENT Confidential...
Page 382: Adjustment Items
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 5.1 Adjustment Items The following table shows the adjustment items required after fixing or replacing certain parts (units). Table 5-1. Adjustment Items Parts Timing Adjustment Item Procedure Required Tools or Program Reference When the printer is transported without replacing Color Registration Alignment (Auto) Execute from the control panel.
Page 383: Adjustment
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 5.2 Adjustment 5.2.1 Adjusting Color Registration Alignment (Auto) PURPOSE Automatically adjusts the registration position of each color precisely relative to black. ADJUSTING COLOR REGISTRATION 1) Make sure the LCD panel displays Ready, then press the [ ] button to access the control panel menus.
Page 384: Adjusting Color Registration Alignment (Manual)
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 5.2.2 Adjusting Color Registration Alignment (Manual) Adjustment 1) Enter Print Adjust Menu. PURPOSE 2) Select XXXX Regist item for the color (Cyan, Magenta, or Yellow) that needs adjustment, then press the [ ] button. After placing/resetting the printer after purchase or after long-distance transport, make...
Page 385: Writing Usb Id
1) Copy all the files related to “PPInitSetting” program and save them into one PURPOSE folder. AcuLaser C2800/C2800D/C3800/C3800D comes with the USB interface as a Be sure to save a complete set of files related to “PPInitSetting” standard, and the computer connected to the AcuLaser C2800/C2800D/C3800/...
Page 386 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C WRITING METHOD The method for writing USB ID varies according to the conditions of the main board. Be sure to figure out the appropriate method with reference to the following table. For details on how to write the ID, follow the instructions shown in the program.
Page 387: Mcu Maintenance Program
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 5.2.4 MCU Maintenance Program TOOL Program PURPOSE MCU Maintenance Program EEPROM on a PWBA MCU stores information unique to each printer. System requirements When replacing the PWBA MCU, follow the procedure below to back up the...
Page 388 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 3) MCU Initialize OUTLINE OF FUNCTION Initializes a EEPROM on a PWBA MCU. When replacing a PWBA MCU due to an error Service Req E900, do not perform “EEPROM Data Backup” or “EEPROM Data Restore”. If data corruption has causing the error, the same error may arise after executing the operations.
Page 389: Chapter 6 Maintenance
C H A P T E R MAINTENANCE Confidential...
Page 390: Consumable Products/Products That Require Periodic Replacement
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 6.1 Consumable Products/Products that Require Periodic Replacement Note that the values (printable pages) given in the following tables are guidelines, not an absolute specifications. The life could become less than a half of the given numbers due to many factors; such as intermittent printing (repeating to print only a few copies for each print job), paper type (especially thick paper), paper size, paper orientation, print data (image or document), frequent power-on/off, and so on.
Page 391 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C AcuLaser C3800/C3800D Table 6-2. Consumable Products Product Service Life Replacement Product Name Configuration Remark Code (printable pages) Massage Replace Toner Y High capacity imaging cartridge Yellow Toner hopper 1124 9,000 Outer dimensions of high capacity imaging...
Page 392: Cleaning
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 6.2 Cleaning MAIN UNIT Outer cover While at maintenance work, perform the cleaning procedure as described below. Clean it with a soft, clean cloth moistened with a mild detergent. Table 6-4. Cleaning Unit Part Timing...
Page 393 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C MP TRAY STANDARD LOWER PAPER CASSETTE Feed roller Feed roller/Nudger roller Pull out the standard lower paper cassette. Pull out the standard lower paper cassette. Gently wipe the rubber parts of the feed roller with a well-wrung wet cloth.
Page 394 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 550-SHEET PAPER CASSETTE UNIT Feed roller/Nudger roller Retard roller Pull out the 550-sheet paper cassette unit. Pull out the 550-sheet paper cassette unit. Gently wipe the rubber parts of the feed roller and the nudger roller with a well- Gently wipe the rubber parts of the retard roller with a well-wrung wet cloth.
Page 395: Chapter 7 Appendix
C H A P T E R APPENDIX Confidential...
Page 396: Connectors
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.1 Connectors 7.1.1 List of Plugs and Jacks MAIN UNIT Coordinates Connection CN No. H-106 FUSER and HARNESS ASSY FUSER H-107 DRIVE ASSY MAIN (Main Motor) and HARNESS ASSY R SIDE H-108 DRIVE ASSY MAIN (Sub Motor) and HARNESS ASSY R SIDE...
Page 397 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Coordinates Connection CN No. H-122 ROS ASSY and HARNESS ASSY ROS H-124 SENSOR ASSY CRU (Y) and HARNESS ASSY TNR SNR H-124 SENSOR ASSY CRU (M) and HARNESS ASSY TNR SNR H-122 SENSOR ASSY CRU (K) and HARNESS ASSY TNR SNR...
Page 398 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Coordinates Connection CN No. I-136 LED ASSY and HARNESS ASSY LV TOP G-136 HVPS and PWBA MCU (P161 is soldered onto the board.) I-139 DISPENSER ASSY (Y) and HARNESS ASSY LV TOP H-138 DISPENSER ASSY (M) and HARNESS ASSY LV TOP...
Page 399 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C P/J CN Coordinates Connection D-157 PWBA MCU and HARNESS ASSY ESS D-156 PWBA MCU and HARNESS ASSY VIDEO C-156 PWBA MCU and HARNESS ASSY ROS C-156 PWBA MCU and HARNESS ASSY LV TOP B-157 PWBA MCU and HARNESS ASSY LV TOP...
Page 400 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C DUPLEX UNIT P/J CN Coordinates Connection E-168 Not used F-168 PWBA DUP and FAN DUP F-168 PWBA DUP and HARNESS ASSY DUP UNIT F-169 PWBA DUP and MOTOR ASSY DUP 4301 F-168 PWBA DUP and HARNESS ASSY DUP SNR...
Page 401 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 550-SHEET PAPER CASSETTE UNIT P/J CN Coordinates Connection G-180 Not used H-183 550 OPTION FEEDER (HARNESS ASSY FDR UNIT) and PRINTER G-180 PWBA FEED-H and HARNESS ASSY FDR UNIT G-180 PWBA FEED-H and HARNESS ASSY C2 TURN...
Page 402: Control Panel Special Features
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.2 Control Panel Special Features The control panel of AcuLaser C3800/C3800D has the special features as described in the table below. Do not disclose this information (except for Support mode) to users as these features are for product development and servicing.
Page 403: Special Menu
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.2.2 Special Menu The underlined values in the following tables are default factory C H E C K P O I N T settings. SUPPORT MENU Selects the control on the backlight of the LCD panel.
Page 404 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C PRINTER ADJUST MENU Menu Option Function Normal 0 ~ 1 Selects the paper type to be notified to the engine when Normal is selected for paper type. 0: PlainPaper-L (full speed) 1: PlainPaper-H (full speed)
Page 405 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Menu Option Function Color Regist Sheet Prints a Color Registration Sheet. Examine the printout patterns for each of the three colors, and select the number for the most densely printed line or the number for the most closely aligned line with black one. Then, enter those numbers for Yellow, Magenta, and Cyan Regist.
Page 406: Firmware Update
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.3 Firmware Update OVERVIEW Firmware update is performed by transmitting the firmware data file from computer to AcuLaser C2800/C2800D/C3800/C3800D via USB interface. Operation Unit Data Format Panel Operation Tool Main Controller Not required Required Required...
Page 407 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C MAIN CONTROLLER FIRMWARE UPDATE Method 1 Method 2 Procedure LCD Panel (RCC) (CRB) Check the current Print a status sheet, and check the current firmware Print a status sheet, and check the current firmware firmware version version.
Page 408 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Method 1 Method 2 Procedure LCD Panel (RCC) (CRB) Click [Send] on the Firmware Update Tool window. Click [Send] on the Firmware Update Tool window. Program Device Version XX.XX OLD: XXXX NEW: XXXX Transmit the data...
Page 409 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Method 1 Method 2 Procedure LCD Panel (RCC) (CRB) Print a status sheet Print a status sheet. Print a status sheet. Confirm that the firmware has been updated properly by Confirm that the program firmware version has been Check the firmware comparing the status sheet with the one printed in step 1.
Page 410 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C ENGINE CONTROLLER FIRMWARE UPDATE Procedure Method LCD Panel Check the current firmware version Print a status sheet or a engine status sheet, and check the current firmware version. Turn off both the printer and the computer, and connect them with a USB cable.
Page 411 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Procedure Method LCD Panel Run the Firmware Update Tool. Select the port and firmware data file on the Firmware Update Tool window. Prepare to transmit the file Click [Send] on the Firmware Update Tool screen.
Page 412 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Procedure Method LCD Panel Press the [ ] button on the control panel of the printer. Writing: Erasing A “Completion” pop-up window will appear when the transmission is finished. Click the [OK]. Perform the update Writing: Size=XXX When updating the program data is finished, the checksum will be indicated on the LCD panel.
Page 413: Information Sheets
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.4 Information Sheets 7.4.1 Status Sheet Table 7-2. Status Sheet Location Item Description Information Shows the information on consumable products and the number of printed pages. Default settings Shows the settings acquired from and set through the control panel.
Page 414: Engine Status Sheet
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.4.2 Engine Status Sheet Table 7-3. Engine Status Sheet Location Item Unit Description Table 7-3. Engine Status Sheet Transfer offset, Normal Set values of transfer normal and temp Location Item Unit Description fuser offset normal...
Page 415 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C INTERPRETING ERROR LOG Indicates the location of the paper jam using an 8-digit hexadecimal number. Table 7-4 Paper Jam Code (p416) on analyzing jam codes. Size Indicates the paper size in English character strings as shown on the LCD panel.
Page 416 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Table 7-4. Paper Jam Code Hexadecimal number Binary number Description (Engine status indication) 00040000 18 100 00000000 00000000 Remain at Dup 00020000 17 10 00000000 00000000 Remain at Exit 00010000 16 1 00000000 00000000 Remain at Reg...
Page 417: Print Log Report
Number of printed monochrome duplex cartridge from the exchange before last. pages Color simplex Number of printed color simplex pages * : AcuLaser C2800/C2800D only. duplex Number of printed color duplex pages Print of mode Pages Total number of printed pages per print mode...
Page 418 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C * : AcuLaser C2800/C2800D only. APPENDIX Information Sheets Confidential...
Page 419: Exploded Diagrams And Parts List
EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C 7.5 Exploded diagrams and Parts List The exploded diagrams and the parts list of AcuLaser C3800/C3800D are shown on the pages that follow. (Total: 44 pages) APPENDIX Exploded diagrams and Parts List Confidential...
Page 420 C648-CASE-011 Only numbered Service Parts are available. 01-01-03 01-01-02 01-01-01 01-01-04 01-01-07 01-01-05 01-01-10 Front 01-01-06 Kmy05001EB FOR EPSON AcuLaserC3800N/DN NO.1-1 Rev.01 C648...
Page 421 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 01-01-01 COVER TOP ASSY E 01-01-02 COVER EXTENTION 1 E 01-01-03 COVER EXTENTION 2 E 01-01-04 COVER REAR E 01-01-05 COVER CST 550 E 01-01-06 COVER SIDE R E 01-01-07 COVER SIDE L E...
Page 422 01-02-04 (P2720) 01-02-100 01-02-05 (J272) 01-02-36 01-02-08 01-02-31 01-02-08 01-02-07 01-02-17 01-02-21 Front 01-02-09 01-02-17 01-02-22 01-02-18 01-02-19 01-02-20 01-02-23 01-02-24 (with 29,32) 01-02-32 01-02-30 01-02-30 01-02-29 Kmy05002EC Only numbered Service Parts are available. FOR EPSON AcuLaserC3800N/DN NO.1-2 Rev.01 C648...
Page 423 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 01-02-03 SPRING LATCH 01-02-04 LATCH FRONT 01-02-05 KIT COVER ASSY HARN SEC 01-02-07 CONTACT FRONT 01-02-08 SHAFT PIVOT 01-02-09 KIT COVER ASSY FRONT SEC 01-02-100 LOGO PLATE,13X54;C 01-02-11 HARNESS ASSY FRONT COVER...
Page 424 C648-ELEC-011 Only numbered Service Parts are available. 09-01-08 09-01-05 (J44) (J503) 09-01-11 09-01-03 09-01-01 (P274) 09-01-19 09-01-24 (J481) 09-01-20 (J48) 09-01-80 Front 09-01-21 (only ECC,ETT) Kmy05012EC FOR EPSON AcuLaserC3800N/DN NO.9-1 Rev.01 C648...
Page 425 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 09-01-01 PWBA EEPROM XPRO 09-01-03 BOARD ASSY I/F6202A,WW 09-01-05 HARNESS ASSY INTERLOCK 09-01-08 PSLV 200V STD 09-01-11 FAN MAIN 09-01-19 SENSOR HUM 09-01-20 PWBA MCU KMY S 09-01-21 POWER CORD 09-01-22...
Page 426 Only numbered Service Parts are available. C648-ELEC-021 09-02-03 09-02-03 09-02-07 09-02-08 Front 09-02-09 09-02-11 09-02-10 09-02-17 09-02-15 09-02-14 Kmy05020EB FOR EPSON AcuLaserC3800N/DN NO.9-2 Rev.01 C648...
Page 427 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 09-02-03 SCREW KNURLING 09-02-07 BOARD ASSY.,MEMORY 09-02-08 SDRAMDIMM 09-02-09 BOARD ASSY,MAIN6191B,ASP 09-02-10 NETWORK BOARD 09-02-11 GUIDE RAIL 09-02-14 HARNESSMAIN-HARNESS 09-02-15 HARNESSMAIN-USB MEMORY 09-02-17 GROUNDING SPRING,TYPE-B APPENDIX Exploded diagrams and Parts List...
Page 428 C648-MECH-011 Only numbered Service Parts are available. [Ref PL2.2.1] 02-01-02 (with 3,12-24) 02-01-03 02-01-12 02-01-12 02-01-13 02-01-14 02-01-15 02-01-13 02-01-16 02-01-17 02-01-21 02-01-17 02-01-18 02-01-20 02-02-24 Front Kmy05003EB FOR EPSON AcuLaserC3800N/DN NO.2-1 Rev.01 C648...
Page 429 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-01-02 CASSETTE ASSY FRONT 550 E 02-01-03 HOLDER ASSY RETARD MSI E 02-01-12 ROLL PINCH TURN 02-01-13 SPRING PINCH TURN 02-01-14 FOLLOWER L 02-01-15 FOLLOWER R 02-01-16 ARM L 02-01-17 SPRING N/F...
Page 430 C648-MECH-021 Only numbered Service Parts are available. 02-02-01 (without 80) 02-02-02 02-02-09 02-02-13 02-02-12 02-02-80 (with PL2.2.a+PL3.2.ax2) 02-02-23 02-02-23 02-02-23 02-02-26 Front Kmy05004EB FOR EPSON AcuLaserC3800N/DN NO.2-2 Rev.01 C648...
Page 431 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-02-01 CASSETTE ASSY REAR 550 E 02-02-02 PLATE ASSY BTM A4 E 02-02-09 GUIDE ASSY SIDE R 550 E 02-02-12 HOLDER ASSY RETARD E 02-02-13 COVER RTD CST (MAT) E 02-02-23...
Page 432 C648-MECH-031 Only numbered Service Parts are available. (J233) 03-01-19 [Ref PL3.2.1] (J235) 03-01-20 (J236) 03-01-03 03-01-05 03-01-04 03-01-10 03-01-15 MSI NO PAPER (J275) SENSOR (P2751) (J2751) 03-01-17 Front Kmy05005EA FOR EPSON AcuLaserC3800N/DN NO.3-1 Rev.01 C648...
Page 433 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 03-01-03 SOLENOID FEED MSI 03-01-04 SPRING FEED MSI 03-01-05 GEAR MSI 03-01-10 ROLL ASSY FEED 03-01-15 SENSOR UPPER PASS 03-01-17 HARNESS ASSY MSI NPP 03-01-19 CLUTCH ASSY PH REGI 03-01-20 CLUTCH ASSY PH FEED...
Page 434 03-02-27 03-02-25 03-02-30 REGI 03-02-32 (P2322) SENSOR 03-02-54 (P2412) (J24) (J232) (J2322) (J2321) 03-02-37 (P241) 03-02-30 CST NO PAPER (P2411) 03-02-58 (P2321) SENSOR 03-02-56 (J2411) (J241) (J2412) 03-02-57 03-02-80 (with PL2.2.a+PL3.2.ax2) 03-02-49 Front Kmy05006EB FOR EPSON AcuLaserC3800N/DN NO.3-2 Rev.01 C648...
Page 435 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 03-02-01 FEEDER ASSY SE 03-02-04 SPRING REGI L 03-02-05 SPRING REGI R 03-02-07 ROLL REGI RUBBER 03-02-13 ACTUATOR A 03-02-14 SPRING REGI SNSR A 03-02-15 ACTUATOR B 03-02-16 SPRING REGI SNSR B...
Page 436 (P141) 05-01-03 (P313) (J184) 05-01-12 05-01-03 (P312) 05-01-03 (J182) (P311) 05-01-12 05-01-15 (J181) 05-01-23 05-01-25 05-01-24 05-01-26 05-01-26 05-01-06 05-01-05 05-01-08 TONER CARTRIDGE (P193) (K) SENSOR (P194) (C) (P192) (M) (P191) (Y) Kmy05008EC Front FOR EPSON AcuLaserC3800N/DN NO.5-1 Rev.01 C648...
Page 437 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 05-01-02 ROS ASSY SEC 05-01-03 CONNECTOR CRUM 05-01-05 ACTUATOR SENSOR CRU 05-01-06 SPRING CRU 05-01-08 SENSOR UPPER PASS 05-01-12 DISPENSER ASSY 05-01-15 LED ASSY 05-01-17 PSHV STD 05-01-23 VISOR ASSY LABEL...
Page 438 C648-MECH-061 Only numbered Service Parts are available. [Ref PL1.2.9] 06-01-01 06-01-02 06-01-02 06-01-02 06-01-02 06-01-04 06-01-03 06-01-05 06-01-03 06-01-03 06-01-03 06-01-06 06-01-11 (J47) (P171) (J171) (J17) 06-01-13 Front Kmy05009EA FOR EPSON AcuLaserC3800N/DN NO.6-1 Rev.01 C648...
Page 439 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 06-01-01 CHUTE ASSY EXIT OUT 06-01-02 SPRING PINCH EXIT OUT 06-01-03 ROLL PINCH EXIT 06-01-04 SPRING CORRUGATE 06-01-05 ROLL CORRUGATE 06-01-06 HOLDER CORRUGATE 06-01-11 HARNESS ASSY FUSER 200V 06-01-13 CHUTE DUP GATE...
Page 440 C648-MECH-071 Only numbered Service Parts are available. 07-01-01 07-01-01 07-01-03 07-01-09 07-01-04 07-01-05 07-01-04 07-01-13 07-01-14 07-01-14 07-01-14 07-01-14 (JP231) 07-01-18 07-01-17 07-01-19 Front Kmy05010EC FOR EPSON AcuLaserC3800N/DN NO.7-1 Rev.01 C648...
Page 441 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 07-01-01 HOLDER ASSY WHEEL STAR 07-01-03 LINK L 07-01-04 LEVER RELEASE 07-01-05 KIT HOLDER ASSY DAMPER L 07-01-09 KIT HOLDER ASSY DAMPER R 07-01-13 LINK R 07-01-14 FOOT 07-01-17 GUIDE TRAY R 550...
Page 442 C648-MECH-081 Only numbered Service Parts are available. 08-01-02 (J2761) (P211) (P221) (P222) 08-01-05 08-01-06 (P251) Front Kmy05011EB FOR EPSON AcuLaserC3800N/DN NO.8-1 Rev.01 C648...
Page 443 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 08-01-02 DRIVE ASSY MAIN 08-01-05 KIT MOT ASSY PH 08-01-06 KIT GEAR ASSY PH APPENDIX Exploded diagrams and Parts List Confidential...
Page 444 (J22) (P2761) (P276) (J251) 10-01-07 (J401) (J5041) (J232) (J14) (J222) (J15) (J274) (P273) (J231) (J18) (J221) (P233) (P272) (P234) (P235) (P236) (P275) 10-01-08 (J504) (J211) (J40) (J501) (J502) (J141) (P184) (P183) (P182) (P181) Kmy05013EA FOR EPSON AcuLaserC3800N/DN NO.10-1 Rev.01 C648...
Page 445 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 10-01-01 HARNESS ASSY ESS S 10-01-02 HARNESS ASSY VIDEO S 10-01-03 HARNESS ASSY HUM 10-01-04 HARNESS ASSY TNR SNR 10-01-05 HARNESS ASSY CRUM 10-01-06 HARNESS ASSY EXIT CLT 10-01-07 HARNESS ASSY R SIDE 550...
Page 446 Only numbered Service Parts are available. C802-OPTI-160 02-01-03 [Ref PL2.3.1] [Ref PL2.2] 02-01-05 02-01-06 (J4201) (J4213) [Ref PL2.4.1] Kmy05016EB Front FOR 550-Sheet Paper Cassette Unit NO.2-1 Rev.01...
Page 447 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-01-03 SCREW JOINT 02-01-05 CLUTCH ASSY TURN OPT 02-01-06 CLUTCH ASSY FEED OPT APPENDIX Exploded diagrams and Parts List Confidential...
Page 448 Only numbered Service Parts are available. C802-OPTI-161 (J273) 02-02-03 (J419) 02-02-05 02-02-06 (J421) (P4211) (J4211) (P4213) 02-02-07 (P4212) (J420) 02-02-15 02-02-15 (P4202) 02-02-15 02-02-08 (P4201) (J422) 02-02-15 (J4222) (P4222) (P4221) 02-02-09 (J4221) 02-02-10 (P421) (P422) (P423) (P420) 02-02-11 (P1) 02-02-12 (P419) Kmy05017EC Front...
Page 449 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-02-03 HARNESS ASSY FDR UNIT 02-02-05 SWITCH ASSY SIZE 02-02-06 PWBA FEED-H 02-02-07 HARNESS ASSY C2 CHUTE 02-02-08 HARNESS ASSY C2 TURN 02-02-09 HARNESS ASSY C2 MOT 02-02-10 DRIVE ASSY OPT FDR...
Page 450 C802-OPTI-162 Only numbered Service Parts are available. 02-03-01 (without80) 02-03-04 02-03-08 02-03-08 02-03-08 02-03-08 02-03-08 02-03-09 02-03-09 02-03-09 02-03-09 02-03-09 (P42121) (J42121) (J4212) 02-03-14 CST NO PAPER SENSOR 02-03-30 02-03-80 (with PL2.3.ax2+PL2.5.a) 02-03-25 Front Kmy05018EB FOR 550-Sheet Paper Cassette Unit NO.2-3 Rev.01...
Page 451 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-03-01 FEEDER ASSY UNIT OPT SEC 02-03-04 ROLL ASSY TURN 02-03-08 ROLL PINCH TURN 02-03-09 SPRING PINCH TURN 02-03-14 SENSOR UPPER PASS 02-03-25 ACTUATOR NO PAPER A4 02-03-30 HARNESS ASSY C2 NO PAPER...
Page 452 Only numbered Service Parts are available. C802-OPTI-163 [Ref PL2.5.1] 02-04-02 Front Kmy05019EA FOR 550-Sheet Paper Cassette Unit NO.2-4 Rev.01...
Page 453 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-04-02 CASSETTE ASSY FRONT 550 OPT E APPENDIX Exploded diagrams and Parts List Confidential...
Page 454 C802-OPTI-164 Only numbered Service Parts are available. (without 80) 02-05-01 02-05-02 02-05-09 02-05-13 02-05-12 02-05-80 (with PL2.3.ax2+PL2.5.a) 02-05-23 02-05-23 02-05-23 02-05-26 Front Kmy05021EA FOR 550-Sheet Paper Cassette Unit NO.2-5 Rev.01...
Page 455 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 02-05-01 CASSETTE ASSY REAR 550 E 02-05-02 PLATE ASSY BTM A4 E 02-05-09 GUIDE ASSY SIDE R 550 E 02-05-12 HOLDER ASSY RETARD E 02-05-13 COVER RTD CST (MAT) E 02-05-23...
Page 456 C802-OPTI-158 Only numbered Service Parts are available. 01-01-25 (J427) [Ref PL11.2] 01-01-09 01-01-12 DUP JAM 01-01-10 SENSOR (P4301) (J4301) 01-01-13 (J430) 01-01-15 (J428) To PL11.2 01-01-18 (P430) (P431) (J2720) (P427) (P1) (P428) (P429) Front Kmy05014EA FOR Duplex Unit NO.1-1 Rev.01...
Page 457 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 01-01-09 ACTUATOR DUP 01-01-10 SPRING SENSOR DUP 01-01-12 SENSOR UPPER PASS 01-01-13 HARNESS ASSY DUP SNR 01-01-15 PWBA DUP-H 01-01-18 HARNESS ASSY DUP UNIT 01-01-25 FAN DUP APPENDIX Exploded diagrams and Parts List...
Page 458 C802-OPTI-159 Only numbered Service Parts are available. 01-02-02 01-02-21 01-02-28 01-02-10 (J431) From PL11.1 01-02-23 (J429) 01-02-14 01-02-15 Front Kmy05015EB FOR Duplix Unit NO.1-2 Rev.01...
Page 459 EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C Ref No. Part Name 01-02-02 BELT DUP 3M-128Z 01-02-10 CLUTCH ASSY FEED 01-02-14 ROLL ASSY DUP-1 01-02-15 ROLL ASSY DUP-2 01-02-21 SPRING DUP 01-02-23 MOTOR ASSY DUP 01-02-28 HARNESS ASSY DUP EARTH APPENDIX Exploded diagrams and Parts List...

This manual is also suitable for:

Aculaser c2800d Aculaser c3800 Aculaser c3800d

Epson AcuLaser C2800 Service Manual

Chapter 1 PRODUCT DESCRIPTION

Chapter 2 OPERATING PRINCIPLES

Chapter 3 TROUBLESHOOTING

Chapter 4 DISASSEMBLY/REASSEMBLY

Chapter 5 ADJUSTMENT

Chapter 6 MAINTENANCE

Chapter 7 APPENDIX

Quick Links

Troubleshooting

Related Manuals for Epson AcuLaser C2800

Summary of Contents for Epson AcuLaser C2800

This manual is also suitable for:

Table of Contents
