Dodge Neon 2001 Service Manual

Hide thumbs Also See for Neon 2001:
Table of Contents

Advertisement

Quick Links

Download this manual
1.0
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1
SYSTEM COVERAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2
SIX-STEP TROUBLESHOOTING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . .1
2.0
IDENTIFICATION OF SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
3.0
SYSTEM DESCRIPTION AND FUNCTIONAL OPERATION . . . . . . . . . . . . . . . . . . . . . .1
3.1
AIRBAG SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
3.1.1 DRIVER AIRBAG MODULE (DAB). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
3.1.2 CLOCKSPRING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
3.1.3 PASSENGER AIRBAG MODULE (PAB) . . . . . . . . . . . . . . . . . . . . . . . . . .3
3.1.5 SEAT AIRBAG MODULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3.1.6 ACM/SIACM DIAGNOSTIC TROUBLE CODES . . . . . . . . . . . . . . . . . . . .4
3.1.6.1 ACTIVE CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.1.6.2 STORED CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.2
AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.3
EXTERIOR LIGHTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.4
ELECTRO/MECHANICAL INSTRUMENT CLUSTER (EMIC). . . . . . . . . . . . . . . . .5
3.5
INTERIOR LIGHTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.6
REMOTE KEYLESS ENTRY MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.6.1 VEHICLE THEFT SECURITY SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2 POWER DOOR LOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2.1 CENTRAL LOCKING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2.2 ROLLING (AUTOMATIC) DOOR LOCKS. . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2.3 DOOR LOCK INHIBIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2.4 POWER DECKLID RELEASE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.6.2.5 PANIC MODE (IF EQUIPPED) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.7
VEHICLE COMMUNICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.8
USING THE DRBIII . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.8.1 DRBIII ERROR MESSAGES AND BLANK SCREEN . . . . . . . . . . . . . . .8
3.8.2 DRBIII DOES NOT POWER UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.8.3 DISPLAY IS NOT VISIBLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.0
DISCLAIMERS, SAFETY, WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.1
DISCLAIMERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2.1 TECHNICIAN SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4.2.2 VEHICLE PREPARATION FOR TESTING. . . . . . . . . . . . . . . . . . . . . . . . .8
4.2.3 SERVICING SUB-ASSEMBLIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.2.4 DRBIII SAFETY INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.3
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.3.1 VEHICLE DAMAGE WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.3.2 ROAD TESTING A COMPLAINT VEHICLE . . . . . . . . . . . . . . . . . . . . . . . .9
5.0
REQUIRED TOOLS AND EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6.0
GLOSSARY OF ACRONYMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
7.0
DIAGNOSTIC INFORMATION AND PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . .11

TABLE OF CONTENTS

i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Neon 2001 and is the answer not in the manual?

Questions and answers

Related Manuals for Dodge Neon 2001

Summary of Contents for Dodge Neon 2001

  • Page 1: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ............1 SYSTEM COVERAGE .
  • Page 2 TABLE OF CONTENTS - Continued AIRBAG ACM ACCELEROMETER - ACTIVE.........12 ACM ACCELEROMETER - STORED .
  • Page 3 TABLE OF CONTENTS - Continued ACM, NO LEFT SIACM MESSAGE - ACTIVE....... . .47 ACM, NO RIGHT SIACM MESSAGE (ACTIVE) .
  • Page 4 TABLE OF CONTENTS - Continued *BALANCE INOPERATIVE ..........85 *CD EJECT SWITCH INOPERATIVE.
  • Page 5 TABLE OF CONTENTS - Continued *LOW BEAM HEADLAMPS WILL NOT TURN OFF ......136 *LOW BEAM HEADLAMPS WILL NOT TRN ON ......137 INSTRUMENT CLUSTER ABS MESSAGE NOT RECEIVED .
  • Page 6 TABLE OF CONTENTS - Continued *PARK LAMPS FAIL TO FLASH DURING ALARM ......202 *VTSS FAILS TO ARM/DISARM FROM DRIVER DOOR CYLINDER LOCK SWITCH .
  • Page 7 TABLE OF CONTENTS - Continued DECKLID SECURITY SWITCH (KNOCK OUT) - GRAY 2 WAY ....226 DECKLID SOLENOID - BLACK 2 WAY ........226 DOME LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 3 WAY .
  • Page 8 TABLE OF CONTENTS - Continued REMOTE KEYLESS ENTRY MODULE - BLACK 26 WAY ..... .249 RIGHT FRONT DOOR SPEAKER - BLACK 2 WAY ......249 RIGHT HEADLAMP (BUILT-UP-EXPORT) - 3 WAY .

  • Page 9: Introduction

    GENERAL INFORMATION • 1.0 INTRODUCTION symptom analysis • problem isolation The procedures contained in this manual include • repair of isolated problem all the specifications, instructions and graphics • verification of proper operation needed to diagnose 2001 body system problems. The diagnostics in this manual are based on the failure condition or symptom being present at the time of 2.0 IDENTIFICATION OF...

  • Page 10: Driver Airbag Module (Dab)

    GENERAL INFORMATION The microprocessor in the ACM monitors the the system or the MIC lamp circuit may be inter- impact sensor signal and the airbag system electri- nally shorted to ground. If the lamp comes on and cal circuits to determine the system readiness. If stays on for a period longer than 6-8 seconds then the ACM detects a monitored system fault, it sends goes off, there is usually an intermittent problem in...

  • Page 11: Passenger Airbag Module (Pab)

    GENERAL INFORMATION ribbon-like, electrically conductive tape that winds PANT PROTECTION. FASTENERS, and unwinds with the steering wheel rotation. The SCREWS, AND BOLTS ORIGINALLY USED clockspring is used to maintain a continuous elec- FOR THE AIRBAG SYSTEM COMPONENTS trical circuit between the instrument panel wire HAVE SPECIAL COATINGS AND ARE SPE- harness and the driver side airbag module, the horn CIFICALLY DESIGNED FOR THE AIRBAG...

  • Page 12: Acm/Siacm Diagnostic Trouble Codes

    GENERAL INFORMATION INFLATOR. DO NOT PUNCTURE, INCINER- An “Interrogate Right SIACM or Interrogate left ATE, OR BRING INTO CONTACT WITH ELEC- SIACM” diagnostic trouble code indicates an active TRICITY. DO NOT STORE AT TEMPERA- trouble code in the respective module. TURE EXCEEDING 93°C (200°F).

  • Page 13: Exterior Lighting

    GENERAL INFORMATION down until the circuit is repaired. The radio will at specified calibration points and will illuminate also set a trouble code, which the DRBIII all the PCI Bus controlled indicators. The Cluster display indicating which output is effected. will also illuminate each segment of the VF display.

  • Page 14: Vehicle Theft Security System

    GENERAL INFORMATION cycle the ignition switch. To transfer back to dealer 3.6.2.3 DOOR LOCK INHIBIT storage mode, the DRBIII must be used, the IOD This feature disables the door lock command from fuse removed, and the ignition switch cycled. Some- the interior door lock switch whenever the dirver times the instrument cluster doesn’t transmit a door is open and the key is in the ignition.
  • Page 15 GENERAL INFORMATION • Remote Keyless Entry Module indicates whether or not the PCI bus is operational. The message is only an indication that a module is • Sentry Key Immobilizer Module either not responding or the vehicle is not equipped. •...

  • Page 16: Using The Drbiii

    GENERAL INFORMATION 3.8 USING THE DRBIII 3.8.3 DISPLAY IS NOT VISIBLE Low temperatures will affect the visibility of the Refer to the DRBIII user’s guide for instructions display. Adjust the contrast to compensate for this and assistance with reading trouble codes, erasing condition.

  • Page 17: Servicing Sub-Assemblies

    GENERAL INFORMATION • 4.2.3 SERVICING SUB-ASSEMBLIES When measuring current, connect the meter in series with test lead. Some components of the chassis system are in- • Disconnect the live test lead before disconnecting tended to be serviced as an assembly only. Attempt- the common test lead.

  • Page 18: Glossary Of Acronyms

    GENERAL INFORMATION 6.0 GLOSSARY OF ACRONYMS powertrain control module power distribution center antilock brake system pulse width modulated airbag control module remote keyless entry AECM airbag electronic control module RSIACM right SIACM (ACM) seat airbag ASDM airbag system diagnostic module SIACM side impact airbag control module (ACM)

  • Page 19: Diagnostic Information And Procedures

    DIAGNOSTIC INFORMATION AND PROCEDURES...
