Dodge 2004 Neon SRT4 Owner's Manual

Dodge 2004 neon srt4 automobile owner's manual
Hide thumbs Also See for 2004 Neon SRT4:
Table of Contents

Advertisement

Quick Links

See also: Diagnostic Manual
SECTION
1

INTRODUCTION

2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
4
UNDERSTANDING YOUR INSTRUMENT PANEL
5
STARTING AND OPERATING
6
WHAT TO DO IN EMERGENCIES
7
MAINTAINING YOUR VEHICLE
8
MAINTENANCE SCHEDULES
9
IF YOU NEED CONSUMER ASSISTANCE
10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
INDEX
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
PAGE
1
2
3
4
5
6
7
8
9
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2004 Neon SRT4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dodge 2004 Neon SRT4

Summary of Contents for Dodge 2004 Neon SRT4

  • Page 1: Introduction

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...

  • Page 3: Table Of Contents

    CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .

  • Page 4: Introduction

    4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
  • Page 5 INTRODUCTION 5...

  • Page 6: Warnings And Cautions

    6 INTRODUCTION WARNINGS AND CAUTIONS This manual contains WARNINGS against operating procedures which could result in an accident or bodily injury. It also contains CAUTIONS against procedures which could result in damage to your vehicle. If you do not read this entire manual you may miss important information.

  • Page 7: Things To Know Before Starting Your Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....9 Locking Doors With The Key ....9 Key-In-Ignition Reminder .
  • Page 8 8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock The Trunk ....17 Using The Panic Alarm ....17 Programming Additional Transmitters .

  • Page 9: Things To Know Before Starting Your Vehicle 7

    A WORD ABOUT YOUR KEYS The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your dealer. Ask your dealer for these numbers and keep them in a safe place.

  • Page 10: Replacement Keys

    10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE immediately after the ignition switch is turned on for a bulb check. Afterwards, if the bulb remains on, this indicates a problem with the electronics. If the bulb begins to flash after the bulb check, this indicates that an invalid key has been used to start the vehicle.

  • Page 11: Customer Key Programming

    consists of programming a blank key to the vehicle electronics. A blank key is one which has never been programmed. NOTE: When having the Sentry Key Immobilizer System serviced, bring all vehicle keys with you to the dealer. Customer Key Programming You can program new keys to the system if you have two valid sentry keys by doing the following: 1.

  • Page 12: Steering Wheel Lock

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE STEERING WHEEL LOCK Your vehicle is equipped with a passive steering wheel lock. This lock prevents steering the vehicle without the ignition key. If the steering wheel is rotated no more than 1/2 turn in either direction and the key is not in the ignition switch, the steering wheel will lock.

  • Page 13: Power Door Locks

    WARNING! When leaving the vehicle always remove the key from the ignition lock, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe personal inju- ries and death.

  • Page 14: Child-Protection Door Lock System (Rear Doors)

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child-Protection Door Lock System (Rear Doors) To provide a safer environment for children riding in the rear seat, the rear doors of your vehicle have the child- protection door lock system. To use the system, open each rear door and slide the control UP to engage the locks and DOWN to disengage the child-protection locks.

  • Page 15: Internal Emergency Trunk Lid Release

    INTERNAL EMERGENCY TRUNK LID RELEASE WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended. Once in the trunk, young children may not be able to escape, even if they entered through the rear seat.

  • Page 16: Remote Keyless Entry

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY This system allows you to lock or unlock the doors and trunk or activate the panic alarm from distances up to about 23 feet (7 meters) using a hand held transmitter. NOTE: A slight delay of up to two seconds can occur before the doors or trunk will unlock.

  • Page 17: To Unlock The Trunk

    To Unlock the Trunk Press the TRUNK button on the transmitter twice to unlock the trunk. NOTE: A slight delay of up to two seconds can occur before the trunk unlatches. Using The Panic Alarm To turn on the panic alarm feature, press and release the PANIC button.

  • Page 18: General Information

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information This device complies with FCC rules part 15. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, in- cluding interference that may cause undesired operation.

  • Page 19: Power Windows

    POWER WINDOWS The window switches on the driver’s door panel control both front windows. The switch on the passenger’s door panel controls the passenger’s window. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems.

  • Page 20: Lap/Shoulder Belts

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.
  • Page 21 WARNING! • Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of a collision the best. •...
  • Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to allow the belt to go around your lap.
  • Page 23 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.

  • Page 24: Adjustable Upper Shoulder Belt Anchorage

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system.

  • Page 25: Lap/Shoulder Belt Untwisting Procedure

    Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 1. Position the latch plate as close as possible to the anchor point.

  • Page 26: Seat Belts And Pregnant Women

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. At about 6 to 12 inches above the latch plate, grasp and twist the belt webbing 180° to create a fold that begins immediately above the latch plate. 3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate.

  • Page 27: Seat Belt Extender

    Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision. Seat Belt Extender If a seat belt is too short, even when fully extended and when the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, your dealer can provide you with a seat belt extender.
  • Page 28 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the vehicle is equipped with side airbags, they are located inside the driver and front passenger seats, and their covers are also labeled SRS AIRBAG. NOTE: Airbag covers may not be obvious in the interior trim;...
  • Page 29 Airbags inflate in moderate to high speed impacts. Along with the seat belts, front airbags work with the instru- ment panel knee bolsters to provide improved protection for the driver and front passenger. Side airbags also work with seat belts to improve occupant protection. The seat belts are designed to protect you in many types of collisions.
  • Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a child from 1 to 12 years old must ride in the front passenger seat because the vehicle is crowded, move the seat as far back as possible, and use the proper child restraint.
  • Page 31 Airbag System Components The front airbag system consists of the following: • Airbag Control Module (ACM) • AIRBAG Readiness Light • Driver Airbag • Passenger Airbag • Steering Wheel and Column • Instrument Panel • Crash Sensor • Interconnecting Wiring •...
  • Page 32 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Airbag Control Module also turns on the AIRBAG light in the instrument panel for 6 to 8 seconds when the ignition switch is first turned to ON/RUN, then turns the light off. If it detects a malfunction in any part of the system, it turns on the light either momen- tarily or continuously.
  • Page 33 • The knee impact bolsters help protect the knees and position you for the best interaction with the front airbag. If A Deployment Occurs The airbag system is designed to deploy when the Airbag Control Module detects a moderate-to-severe frontal collision, to help restrain the driver and front passenger, and then to immediately deflate.
  • Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Deployed airbags can’t protect you in another colli- sion. Have the airbags replaced by an authorized dealer as soon as possible. Side Airbag System — If Equipped • The Side Impact Airbag Control Modules determine if a side collision is severe enough to require the airbag to inflate.

  • Page 35: Child Restraint

    Maintaining Your Airbag Systems WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
  • Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children 12 years and under should ride properly buck- led up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats, rather than in the front. WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle.
  • Page 37 • Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
  • Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits. • Carefully follow the instructions that come with the restraint.
  • Page 39 the rear seat to install the child restraint. You will easily feel them if you run your finger along the intersection of the surfaces. The lower strap hooks are passed over the top of each bar, pushing aside the seat cover material. In addition, there are tether strap anchorages behind each rear seating position located in the panel between the rear seat back and the rear...
  • Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Attach the tether strap hook (A) of the child restraint to the anchor (B) and remove slack in the tether strap according to the child restraint manufacturer’s instruc- tions. WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
  • Page 41 WARNING! Do not install child restraint systems equipped with LATCH attachments at all three rear seating posi- tions at one time. The LATCH anchorages are de- signed to restrain no more than two child restraints at a time in the event of a collision. We urge that you carefully follow the directions of the manufacturer when installing your child restraint.

  • Page 42: Transporting Pets

    42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The lap portion should be low on the hips and as snug as possible. • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position. •...

  • Page 43: Safety Checks You Should Make Inside The Vehicle

    A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and not an indication of a problem. SAFETY TIPS Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless.

  • Page 44: Periodic Safety Checks You Should Make Outside The Vehicle

    44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Light The light should come on and remain on for 6 to 8 seconds as a bulb check when the ignition switch is first turned to ON/RUN. If the bulb is not lit during starting, have it replaced.

  • Page 45: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......47 Inside Day/Night Mirror ....47 Outside Mirror —...
  • Page 46 46 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers ....55 Mist Function ......56 Intermittent Wiper System .

  • Page 47: Mirrors

    MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A two point pivot system allows for horizontal and vertical mirror adjustment. Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).

  • Page 48: Understanding The Features Of Your Vehicle

    48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electric Remote-Control Mirrors Use the mirror select switch, located on the drivers door trim panel, to adjust the view obtained in the outside mirrors. Press the rocker knob to the L or R for Left or Right mirror selection.

  • Page 49: Reclining Bucket Seats

    WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 50: Folding Rear Seat

    50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat To provide additional storage area, the center of each rear seatback can be folded forward. Pull on the loops shown in the picture to fold down either or both seatbacks. WARNING! •...

  • Page 51: To Open And Close The Hood

    TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. First pull the hood release lever located under the driver’s side of the instrument panel. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51 Then lift the safety catch located under the front edge of the hood, near the center and raise the hood.

  • Page 52: Lights

    52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Use the hood prop rod to secure the hood in the open position as shown. To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the center of the hood to ensure that both latches engage.

  • Page 53: Interior Lights

    Interior Lights The interior lights come on when a door is opened. The interior lights will automatically turn off in about 8 minutes if a door is left open or the dimmer control is left in the Dome light position. Turn the ignition switch ON to restore the interior light operation.

  • Page 54: Headlights, Parking Lights, Instrument Panel Lights

    54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE lights, the passing lights, and fog lights. The lever is located on the left side of the steering column. Headlights, Parking Lights, Instrument Panel Lights Turn the end of the Multi-Function Control Lever to the first detent for parking light operation.

  • Page 55: Turn Signals

    Turn Signals Move the Multi-Function Control Lever up or down to detent and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. You can signal a lane change by moving the lever partially up or down.

  • Page 56: Mist Function

    56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If the lever is pulled while in the OFF position, the wipers will operate for two wipe cycles, then turn OFF. CAUTION! • In cold weather, always turn off the wiper switch and allow the wipers to return to the park position before turning off the engine.

  • Page 57: Tilt Steering Column

    TILT STEERING COLUMN To tilt the column, push down on the lever below the turn signal control and move the wheel up or down, as desired. Pull the lever back towards you to lock the column firmly in place. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57 WARNING! Tilting the steering column while the vehicle is moving is dangerous.

  • Page 58: Console Features

    58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONSOLE FEATURES The Standard console with armrest has two front cup holders and a front storage tray. There are two additional cupholders; one is molded in the center of the console to hold large cups, and the other is on the underside of the console lid to serve passengers in the rear seat.

  • Page 59: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....61 Instrument Cluster—Turbo ....62 Instrument Cluster Descriptions .
  • Page 60 60 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting Satellite Mode In RBP, RBU, RAZ, And RBQ Radios ..... .75 Selecting a Channel .....75 Storing And Selecting Pre-Set Channels .

  • Page 61: Instrument Panel Features

    UNDERSTANDING YOUR INSTRUMENT PANEL 61 INSTRUMENT PANEL FEATURES...

  • Page 62: Understanding Your Instrument Panel

    62 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER—TURBO...

  • Page 63: Instrument Cluster Descriptions

    INSTRUMENT CLUSTER DESCRIPTIONS 1. Fog Light Indicator This light shows when the fog lights are ON. 2. Brake System Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light comes on, it may indicate that the parking brake is applied, or there is a low brake fluid level.
  • Page 64 64 UNDERSTANDING YOUR INSTRUMENT PANEL If the ABS light remains on or comes on during driving, it indicates that the Anti-Lock portion of the brake system is not functioning and that service is required, however, the conventional brake system will continue to operate normally provided that the BRAKE warning light is not If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefit of Anti-Lock...
  • Page 65 The light does not show the quantity of oil in the engine. This can be determined using the procedure shown in Section 7. 9. Seat Belt Reminder Light When the ignition key is first turned on, this light will come on for about six seconds. A chime will sound if you have not pulled the shoulder belt out of the retractor.
  • Page 66 66 UNDERSTANDING YOUR INSTRUMENT PANEL 16. Malfunction Indicator Light This light is part of an onboard diagnostic system called OBD that monitors engine con- trol systems. The light will illuminate briefly when the key is in the ON/RUN position before engine start.
  • Page 67 20. Trip Indicator This light will illuminate when the Trip Odometer is in use. 21. Temperature Gauge The temperature gauge shows engine coolant temperature. Normal operating range should be within one notch above or one notch below the 200 degree mark. The gauge pointer may show a higher than normal temperature when driv- ing in hot weather, up mountain...

  • Page 68: Electronic Digital Clock

    68 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC DIGITAL CLOCK The clock and radio each use the display panel built into the radio. A digital readout shows the time in hours and minutes whenever the ignition switch is in the ON or ACC position.

  • Page 69: Electrical Disturbances

    Electrical Disturbances Radio waves may pick up electrical disturbances during transmission. They mainly affect the wave amplitude, and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal. AM Reception AM sound is based on wave amplitude, so AM reception can be disrupted by such things as lightning, power lines and neon signs.
  • Page 70 70 UNDERSTANDING YOUR INSTRUMENT PANEL Seek Press and release the SEEK button to search for the next station in either the AM or FM mode. Press the top of the button to seek up and the bottom to seek down. The radio will remain tuned to the new station until you make another selection.

  • Page 71: Cd Player Operation

    You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
  • Page 72 72 UNDERSTANDING YOUR INSTRUMENT PANEL display will show the track number and index time in minutes and seconds. Play will begin at the start of track 1. Seek Press the top of the SEEK button for the next selection on the CD.

  • Page 73: Cd Changer Operation - If Equipped

    CD Changer Operation — If Equipped MODE Press the MODE button to select between the cassette tape player, CD player, and the CD changer (if equipped). Disc/Program Button 1 Press the DISC (button 1) button to play the next avail- able disc.

  • Page 74: Satellite Radio - If Equipped

    74 UNDERSTANDING YOUR INSTRUMENT PANEL SATELLITE RADIO — IF EQUIPPED Satellite radio uses direct satellite to receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius™ Satel- lite Radio. This service offers up to 100 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.

  • Page 75: Selecting Satellite Mode In Rbb And Rbk Radios

    ESN/SID Access With RBP, RBU, RAZ, and RBQ Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and TIME buttons simultaneously for 3 seconds. All twelve ESN/SID num- bers will be displayed. The radio will exit the ESN/SID mode when any other button is pushed, the ignition is turned OFF, or 5 minutes has passed since any button was pushed.

  • Page 76: Storing And Selecting Pre-Set Channels

    76 UNDERSTANDING YOUR INSTRUMENT PANEL 888-539-7474 to discuss options for channel blocking or unblocking. Please have your ESN/SID information available. Storing and Selecting Pre-Set Channels In addition to the 10 AM and 10 FM pre-set stations, you may also commit 10 satellite stations to push button memory.

  • Page 77: Compact Disc Maintenance

    • Driving under wide bridges or along tall buildings can cause intermittent reception. • Placing objects over or too close to the antenna can cause signal blockage. COMPACT DISC MAINTENANCE To keep the compact discs in good condition, take the following precautions: 1.

  • Page 78: Climate Controls

    78 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS Air Conditioning The Air Conditioning System allows you to balance the temperature, amount, and direction of air circulating throughout the vehicle. The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere.
  • Page 79 Bi-Level Air is directed through the panel and floor out- lets. NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. NOTE: If you choose either the Mix or Defrost modes while the Circulation control is in the Recirculation Mode, the system will automatically switch to the Out-...
  • Page 80 80 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If your air conditioning performance seems lower than expected, check the front of the A/C con- denser located in front of the radiator, for an accumula- tion of dirt or insects. Clean with a gentle water spray from behind the radiator and through the condenser.

  • Page 81: Operating Tips

    UNDERSTANDING YOUR INSTRUMENT PANEL 81 Operating Tips...
  • Page 82 82 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Vehicle side windows tend to fog on the inside in mild rainy or humid weather. To clear the windows, use the A/C, PANEL and blower controls. Direct the panel outlets toward the side windows. Do not use recirculate without A/C for long periods as fogging may occur.

  • Page 83: Electric Rear Window Defroster

    ELECTRIC REAR WINDOW DEFROSTER A push-button at the center of the instrument panel, below the radio, turns the defroster ON or OFF. An amber light shows that the defroster is on. NOTE: The defroster turns off automatically after 10 minutes of operation. Each following activation of the defroster will last for five minutes.

  • Page 85: Starting And Operating

    STARTING AND OPERATING CONTENTS Starting Procedures .....87 Manual Transaxle ..... .87 Normal Starting .
  • Page 86 86 STARTING AND OPERATING Tire Inflation Pressures ....105 Radial-Ply Tires ..... . 107 Compact Spare Tire .

  • Page 87: Starting Procedures

    STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. CAUTION! Long periods of engine idling, especially at high engine speeds can cause excessive exhaust tempera- tures which can damage your vehicle. Do not leave your vehicle unattended with the engine running.

  • Page 88: Starting And Operating

    88 STARTING AND OPERATING If the engine fails to start within 15 seconds, turn the key OFF wait 10 to 15 seconds, then repeat the normal starting procedure. WARNING! Do not attempt to push or tow your vehicle to get it started.

  • Page 89: After Starting

    CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. After Starting The idle speed will automatically decrease as the engine warms up. TURBOCHARGER COOL DOWN CHART Driving Conditions Normal Driving...

  • Page 90: Manual Transaxle

    90 STARTING AND OPERATING MANUAL TRANSAXLE NOTE: The parking brake should be engaged and the gear selector placed in REVERSE before leaving the vehicle, especially on an incline. NOTE: Clutch must be depressed for engine to start. Fully depress the clutch pedal before you shift gears. As you release the clutch pedal, lightly depress the accelera- tor pedal.

  • Page 91: Recommended Shift Speeds

    Never drive with your foot resting on the clutch pedal, or try to hold the vehicle on a hill with the clutch pedal partially engaged. This will cause abnormal wear on the clutch. Never shift into REVERSE until the vehicle has come to a complete stop.

  • Page 92: Downshifting

    92 STARTING AND OPERATING If you exceed these speeds, you may notice the engine cut in and out. This is caused by an electronic limiter in the engine computer. The engine will run normally when you reduce engine speed. Downshifting Proper downshifting may improve fuel economy and prolong engine life.
  • Page 93 When parking on a hill,, turn the front wheels toward the curb on a downhill grade and away from the curb on a uphill grade. You should always apply the parking brake before leav- ing the vehicle. STARTING AND OPERATING 93 WARNING! •...

  • Page 94: Brake System

    94 STARTING AND OPERATING BRAKE SYSTEM Your vehicle is equipped with power assisted brakes as standard equipment. In the event power assist is lost for any reason (for example, repeated brake applications with the engine off), the brakes will still function. The effort required to brake the vehicle will be much greater than that required with the power system operating.

  • Page 95: Power Steering

    WARNING! • Anti-lock system (ABS) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction afforded. •...

  • Page 96: Tire Safety Information

    96 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings NOTE: • P(Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards.
  • Page 97 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Milimeters (mm) 65 = Aspect Ratio in Percent (%)
  • Page 98 98 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions.

  • Page 99: Tire Identification Number (Tin)

    Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire. DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.

  • Page 100: Tire Loading And Tire Pressure

    100 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: Some vehicles have a “Tire and Loading Infor- mation” placard located on the driver’s side “B” pillar. Tire and Loading Information Placard This placard tells you important information about the, 1) number of people that can be carried in the vehicle 2) the total weight your vehicle can carry...
  • Page 101 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size and cold tire inflation pressures specified on the Tire and Loading Information placard and the Vehicle Loading section of this manual.
  • Page 102 102 STARTING AND OPERATING 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. NOTE: The following table shows examples on how to calculate total load, cargo/luggage and towing capacities of your vehicle with varying seating configurations and...
  • Page 103 STARTING AND OPERATING 103...

  • Page 104: Tires-General Information

    104 STARTING AND OPERATING WARNING! Overloading of your tire is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle-never overload them. TIRES—GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 105: Tire Inflation Pressures

    2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Underinflation also increases tire rolling resistance and results in higher fuel consumption. 3.
  • Page 106 106 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure al- ways reinstall the valve stem cap–if equipped. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure”.

  • Page 107: Radial-Ply Tires

    WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Don’t drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).

  • Page 108: Tire Spinning

    108 STARTING AND OPERATING CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with the compact spare installed. Damage to the vehicle may result. Tire Spinning When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 35 mph (55 km/h).

  • Page 109: Tread Wear Indicators

    Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves and will appear as bands when the tread depth becomes 1/16 inch (2 mm).

  • Page 110: Alignment And Balance

    110 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combina- tions of unapproved tires and wheels may change suspension dimensions and performance charac- teristics, resulting in changes to steering, han- dling, and braking of your vehicle.

  • Page 111: Tire Chains

    Tire Chains Due to limited clearance, tire chains are not recom- mended. CAUTION! Damage to the vehicle may result if tire chains are used. Snow Tires Some areas of the country require the use of snow tires during winter. Some standard tires are of the all season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall.

  • Page 112: Tire Rotation Recommendations

    112 STARTING AND OPERATING Snow tires may have a lower speed rating than factory equipped tires and may not match the maximum vehicle speed. Snow tires generally have lower speed ratings than what was originally equipped with your vehicle and should not be operated at sustained speeds over 75 mph (120 km/h).

  • Page 113: Selecting Fuel

    If you experience these symptoms, try another brand of “regular” gasoline be- fore considering service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, engine performance, and durability for your vehicle.

  • Page 114: Reformulated Gasoline

    114 STARTING AND OPERATING Reformulated Gasoline Many areas of the country require the use of cleaner burning fuel referred to as Reformulated Gasoline. Re- formulated gasolines contain oxygenates, and are specifi- cally blended to reduce vehicle emissions and improve air quality. The manufacturer supports the use of reformulated gaso- lines.

  • Page 115: Sulfur In Gasoline

    vehicle. The MMT content of gasoline may not be indi- cated on the gasoline pump, therefore you should ask your gasoline retailer whether or not his/her gasoline contains MMT. It is even more important to look for gasolines without MMT in Canada because MMT can be used at higher levels than allowed in the United States.

  • Page 116: Adding Fuel

    116 STARTING AND OPERATING ADDING FUEL NOTE: The fuel tank filler tube has a restricting door about 2 inches (50 mm) down from the opening. If fuel is poured from a portable container, the container should have a flexible nozzle long enough to force open the restricting door.

  • Page 117: Vehicle Loading

    WARNING! • Remove the fuel tank filler tube cap (gas cap) slowly to prevent fuel spray from the filler neck which may cause injury. • The volatility of some gasolines may cause a build up of pressure in the fuel tank that may increase while you drive.

  • Page 119: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....120 If Your Engine Overheats ....120 Jacking And Tire Changing .

  • Page 120: Hazard Warning Flasher

    120 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The flasher switch is on top of the steering column, just behind the steering wheel. Depress the switch and both cluster indicators and all front and rear direc- tional signals will flash. Depress the switch again to turn Hazard Warning Flashers off.
  • Page 121 the fan control to High. This allows the heater core to act as a supplement to the radiator and aids in removing heat from the engine cooling system. CAUTION! Driving with a hot cooling system could damage your vehicle. If temperature gauge reads over 250 degrees (in the red zone), pull over and stop the vehicle.

  • Page 122: Jacking And Tire Changing

    122 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack.
  • Page 123 2. Loosen, but do not remove, the wheel nuts by turning them to the left one turn while the wheel is still on the ground. WHAT TO DO IN EMERGENCIES 123 CAUTION! Do not attempt to raise the vehicle by jacking on the crossmember below the radiator or on the front suspension crossmember.
  • Page 124 124 WHAT TO DO IN EMERGENCIES Do not raise the vehicle until you are sure the jack is securely engaged. 4. Raise the vehicle by turning the jack screw to the right. Raise the vehicle only until the tire clears the surface. Miminum tire lift provides maximum vehicle stability.

  • Page 125: Jump-Starting Procedures Due To A Low Battery

    7. Finish tightening the nuts. Push down on the wrench while tightening the wheel nuts. Alternate nuts until each nut has been tightened twice. Correct wheel nut torque is 100 ft. lbs. (135 N·m.). If you are not sure about the tightness, have them checked with a torgue wrench by your dealer or at a service station.
  • Page 126 126 WHAT TO DO IN EMERGENCIES 1. Wear eye protection and remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact. 2. When boosting from a battery in another vehicle, park that vehicle within booster cable reach but without letting the vehicles touch.
  • Page 127 WARNING! Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or clothing. Don’t lean over battery when attaching clamps or allow the clamps to touch each other. If acid splashes in eyes or on skin, flush the contaminated area immediately with large quantities of water.

  • Page 128: Driving On Slippery Surfaces

    128 WHAT TO DO IN EMERGENCIES WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle.

  • Page 129: Freeing A Stuck Vehicle

    4. Keep tires properly inflated. 5. Maintain enough distance between your vehicle and the vehicle in front of you to avoid a collision in a sudden stop. FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion.

  • Page 130: Towing A Disabled Vehicle

    130 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE With Ignition Key Your vehicle may be towed if the gearshift lever is in NEUTRAL. If the transaxle is not operative, the vehicle must be towed with the front wheels off the ground. CAUTION! If the vehicle being towed requires steering, the ignition switch must be in the OFF position, not in...

  • Page 131: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS 2.4L Turbo Charged Engine Compartment ..133 Onboard Diagnostic System — OBD II ..134 Emissions Inspection And Maintenance Programs ......134 Replacement Parts .
  • Page 132 132 MAINTAINING YOUR VEHICLE Hoses And Vacuum/Vapor Harnesses ..152 Brake System ......153 Manual Transaxle .

  • Page 133: 2.4L Turbo Charged Engine Compartment

    MAINTAINING YOUR VEHICLE 133 2.4L TURBO CHARGED ENGINE COMPARTMENT...

  • Page 134: Maintaining Your Vehicle

    134 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, and engine control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.
  • Page 135 Normally, the OBD system will be ready. The OBD system may not be ready if your vehicle was recently serviced, if you recently had a dead battery, or a battery replacement. If the OBD system should be determined not ready for the I/M test, your vehicle may fail the test. Your vehicle has a simple ignition key actuated test which you can use prior to going to the test station.

  • Page 136: Replacement Parts

    136 MAINTAINING YOUR VEHICLE vehicle serviced before going to the I/M station. The I/M station can fail your vehicle because the MIL symbol is on with the engine running. REPLACEMENT PARTS Use of genuine Mopar parts for normal/scheduled main- tenance and repairs is highly recommended to insure the designed performance.

  • Page 137: Engine Oil

    Engine Oil Checking Oil Level To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about 5 minutes after a fully warmed engine is shut off, or before starting the engine after it has sat overnight.
  • Page 138 138 MAINTAINING YOUR VEHICLE Change Engine Oil Road conditions and your kind of driving affects the interval at which your oil should be changed. Check the following list to decide if any apply to you. • Day and night temperatures are below 32°F (0°C) •...
  • Page 139 the requirements of DaimlerChrysler Material Standard MS-6395. Use Mopar or an equivalent oil meeting the specification MS-6395. The manufacturer recommends the use of Mobil 1 10W30 synthetic engine oil. American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API).
  • Page 140 140 MAINTAINING YOUR VEHICLE the engine oil. Engine oil is an engineered product and it’s performance may be impaired by supplemental ad- ditives. Disposing of Used Engine Oil Care should be taken in disposing of used engine oil from your vehicle. Used oil, indiscriminately discarded, can present a problem to the environment.
  • Page 141 Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.

  • Page 142: Ignition Wiring System

    142 MAINTAINING YOUR VEHICLE Engine Timing Belt Replace the engine timing belt at the intervals described in the appropriate maintenance schedule. Ignition Wiring System The ignition cables should be kept clean and properly connected. Terminals should be fully seated. Cracked, damaged, or faulty cables should be replaced.
  • Page 143 CAUTION! When servicing the battery, always reinstall the battery thermowrap. The thermowrap provides bat- tery heat protection and will extend overall battery life. Failure to reinstall the thermowrap can result in evaporative loss of the battery fluid. MAINTAINING YOUR VEHICLE 143 WARNING! Battery posts, terminals and related accessories con- tain lead and lead compounds.

  • Page 144: Air Conditioner

    144 MAINTAINING YOUR VEHICLE CAUTION! It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked positive (+) and negative (-) and identified on the battery case.

  • Page 145: Power Steering Fluid Check

    Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated.

  • Page 146: Windshield Wiper Blades

    146 MAINTAINING YOUR VEHICLE Windshield Wiper Blades Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild non abrasive cleaner, or use the washer solvent. This will remove accumulations of salt or road film and help reduce streaking and smearing.

  • Page 147: Windshield Washer Reservoir

    Windshield Washer Reservoir The washer fluid reservoir is located in the engine compartment and should be checked for fluid level at regular intervals. Fill the reservoir with windshield washer solvent (not radiator antifreeze) Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.

  • Page 148: Cooling System

    148 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition key to the OFF position. The fan is temperature con- trolled and can start at any time the ignition key is in the ON position.
  • Page 149 Engine Coolant Disposal Used ethylene glycol based engine coolant is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. Do not store ethylene glycol based engine coolant in open containers or allow it to remain in puddles on the ground.
  • Page 150 150 MAINTAINING YOUR VEHICLE Adding Coolant When adding coolant, a minimum solution of 50% eth- ylene glycol antifreeze coolant in water should be used. Use higher concentrations (not to exceed 70%) if tempera- tures below –34°F (-37°C) are anticipated. Use only high purity water such as distilled or deionized water when mixing the water/antifreeze solution.
  • Page 151 The radiator normally remains completely full, so there is no need to remove the radiator cap unless checking for coolant freeze point or replacing coolant. Advise your service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month.

  • Page 152: Hoses And Vacuum/Vapor Harnesses

    152 MAINTAINING YOUR VEHICLE E. Make sure that the radiator and coolant bottle hoses are not kinked or obstructed. F. Keep the front of the radiator and air conditioning condenser clean. G. Do not change the thermostat for summer or winter operation.

  • Page 153: Brake System

    Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Suggested service intervals can be found in the Mainte- nance Section. WARNING! Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage.
  • Page 154 154 MAINTAINING YOUR VEHICLE WARNING! Worn brake hoses can burst and cause brake failure. You could have an accident. If you see any signs of cracking, scuffing, or worn spots, have the brake hoses replaced immediately. Brake Master Cylinder The fluid level in the master cylinder should be checked when performing under hood services, or immediately if the brake system warning lamp is on.

  • Page 155: Manual Transaxle

    WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire. Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter. Do not allow petroleum based fluid to contaminate the brake fluid as seal damage will result! Manual Transaxle...
  • Page 156 156 MAINTAINING YOUR VEHICLE hot or cold weather and other extreme conditions will have an adverse effect on paint, metal trim, and under- body protection. The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle.
  • Page 157 Special Care • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month. • It is important that the drain holes in the lower edges of the doors, rocker panels and rear deck lid be kept clear and open.
  • Page 158 158 MAINTAINING YOUR VEHICLE DO NOT USE: • Any abrasive cleaner • Any abrasive cleaning pad (such as steel wool) or abrasive brush • Any cleaner that contains an acid which can react with and discolor the chrome surface. CAUTION! Many wheel cleaners contain acids that may harm the wheel surface.
  • Page 159 WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.

  • Page 160: Fuses

    160 MAINTAINING YOUR VEHICLE Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage will also weaken the fabric. If the belts need cleaning, use a mild soap solution or lukewarm water.

  • Page 161: Interior Fuses

    Interior Fuses The fuse access panel is behind the end cover at the left side of the instrument panel. To remove the panel, pull it out, as shown. A diagram identifying the components and circuits is located on the inside of the cover. MAINTAINING YOUR VEHICLE 161 CAUTION! When replacing a blown fuse, it is important to use...

  • Page 162: Replacement Bulbs

    162 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS LIGHT BULBS — Inside ABS Indicator ......LED Airbag Indicator ......LED Brake System Warning Indicator .

  • Page 163: Bulb Replacement

    BULB REPLACEMENT Headlight Bulb Replacement CAUTION! Do not touch the new headlight bulb with your fingers. Oil contamination will severely shorten bulb life. 1. Remove the three upper fascia screws. MAINTAINING YOUR VEHICLE 163 2. Remove two screws from the headlight assembly and remove the assembly from the vehicle.

  • Page 164: Front Park/Turn Signal Lights

    164 MAINTAINING YOUR VEHICLE Front Park/Turn Signal Lights 1. Remove the headlight assembly 2. Twist the bulb socket 1/4 turn and remove. 3. Pull the bulb from the socket and replace. Front Sidemarker Light 1. Remove the screws and push-pins from the front fender splash shield.

  • Page 165: Fluid Capacities

    FLUID CAPACITIES Fuel (Approximate) Engine Oil 2.4 Liter Turbo Charged Engines Cooling System * 2.4 Liter Turbo Charged Engines * Includes heater and coolant recovery bottle filled to MAX level. MAINTAINING YOUR VEHICLE 165 U.S. Metric 12.5 Gallons 47.5 Liters 5.0 qts 4.8 Liters 8.1 qts...

  • Page 166: Recommended Fluids, Lubricants And Genuine Parts

    166 MAINTAINING YOUR VEHICLE RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Chassis Component Manual Transmission Fluid Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) Use Mobil 1 10W30 synthetic engine oil.

  • Page 167: Maintenance Schedules

    MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..168 Maintenance Schedule ....168 Schedule “B” ......171 Schedule “A”...

  • Page 168: Emission Control System Maintenance

    168 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
  • Page 169 NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule “B” of the Maintenance Schedules section of this manual. NOTE: Most vehicles are operated under the conditions listed for Schedule B .
  • Page 170 170 MAINTENANCE SCHEDULES At Each Oil Change • Change the engine oil filter. • Inspect the exhaust system. • Inspect the brake hoses. • Inspect the CV joints and front suspension compo- nents. • Check the manual transaxle fluid level and fill plug condition.

  • Page 171: Schedule "B

    SCHEDULE “B” Follow schedule “B” If you usually operate your vehicle under one or more of the following conditions. Change the manual transaxle fluid every 48,000 miles (77 000 km) if the vehicle is usually operated under one or more of the conditions marked with an †. •...
  • Page 172 172 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter. Replace as necessary.* Inspect and replace, if required, the make-up air filter (located inside the air cleaner). 3,000 6,000 9,000 12,000...
  • Page 173 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Replace the engine air cleaner filter. Replace the spark plugs. Inspect the tie rod ends and boot seals. Inspect the PCV valve and replace as neces- sary.* Replace the make-up air filter (located inside the air cleaner).
  • Page 174 174 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Change the brake fluid. If vehicle is used for trailer towing. Inspect the engine air cleaner filter. Replace as necessary.* Change the manual transaxle fluid. Inspect and replace, if required, the the make-up air filter (located inside the air cleaner).
  • Page 175 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Replace the engine air cleaner filter. Replace the spark plugs and ignition cables. Inspect the tie rod ends and boot seals. Inspect the PCV valve and replace if neces- sary.
  • Page 176 176 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter and re- place as necessary.* Replace the engine air cleaner filter. Replace the spark plugs. Inspect the tie rod ends and boot seals. Inspect the PCV valve and replace if neces- sary.
  • Page 177 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Change the brake fluid. If vehicle is used for trailer towing. Inspect the engine air cleaner filter and replace as necessary.* Change the manual transaxle fluid. Flush and replace the engine coolant at 60 months or 102,000 miles.

  • Page 178: Schedule "A

    178 SCHEDULE “A” SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Replace the engine air cleaner filter. Replace the spark plugs. Inspect the tie rod ends and boot seals. Replace the make-up air filter (located inside the air cleaner).
  • Page 179 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. 35,000 40,000 45,000 50,000 (56 000) (64 000) (72 000) (80 000) [30] [36] SCHEDULE “A” 179 55,000 (88 000) [42]...
  • Page 180 180 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Replace the engine air cleaner filter. Replace the spark plugs and ignition cables. Inspect the tie rod ends and boot seals. Inspect the PCV valve and replace if necessary. Not required if previously changed.
  • Page 181 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Replace the engine air cleaner filter. Replace the spark plugs. Adjust the generator drive belt tension. Inspect the tie rod ends and boot seals. Inspect the PCV valve and replace if necessary. Not required if previously changed.
  • Page 182 182 SCHEDULE “A” WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.

  • Page 183: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......184 Prepare For The Appointment .

  • Page 184: Suggestions For Obtaining Service For Your Vehicle

    184 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty, discuss additional charges with the service manager.
  • Page 185 • If for some reason you are still not satisfied, talk to the general manager or owner of the dealership. They want to know if you need assistance. • If your dealership is unable to resolve the concern, you may contact the Manufacturer’s Customer Center. Any communication to the Manufacturer’s Customer Center should include the following information: •...

  • Page 186: Warranty Information

    186 IF YOU NEED CONSUMER ASSISTANCE Service Contract You may have purchased a service contract for your vehicle to help protect you from the high cost of unex- pected repairs after your manufacturer’s new vehicle limited warranty expires. The manufacturer stands be- hind only the manufacturer’s Service Contracts.

  • Page 187: Mopar Parts

    MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best. REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra- tion (NHTSA) in addition to notifying the manufacturer.

  • Page 188: Publication Order Forms

    188 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.

  • Page 189: Department Of Transportation Uniform Tire Quality Grades

    DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.

  • Page 190: Temperature Grades

    190 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (highest), B, and C, repre- senting the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
  • Page 191 INDEX...
  • Page 192 192 INDEX ABS (Anti-Lock Brake) System ....94 Adding Engine Coolant (Antifreeze) ..150 Adding Fuel ......116 Air Cleaner, Engine .
  • Page 193 Catalytic Converter ..... 141 CD Changer ......72,73 CD Player .
  • Page 194 194 INDEX Downshifting ......92 Drive Belts ......140 Driving On Slippery Surfaces .
  • Page 195 Fuses ....... . 160 Gas Cap ......116 Gasoline .
  • Page 196 196 INDEX Keyless Entry System ..... 16 Keys ........9 Lane Change and Turn Signals .
  • Page 197 Maintenance Procedures ....136 Maintenance Schedule Schedule A ......178 Schedule B .
  • Page 198 198 INDEX Power Door Locks ......13 Steering ......95,145 Steering, Checking .
  • Page 199 Security Alarm ......65 Sentry Key ......9 Service Assistance .
  • Page 200 200 INDEX Sizes ....... 97 Snow Tires ......111 Spinning .

Table of Contents

Save PDF
