Siemens Pointek CLS200 Operating Instructions Manual

Capacitance switches
Hide thumbs

Advertisement

Quick Links

Pointek CLS200/CLS300 standard
Point level
Capacitance switches
Pointek CLS200/CLS300 standard
Operating Instructions
7ML5630 (CLS200 standard, rod version)
7ML5631 (CLS200 standard, cable version)
7ML5632 (CLS200 standard, sanitary connection)
7ML5633 (CLS200 standard, sliding coupling)
7ML5650 (CLS300 standard, rod version)
7ML5651 (CLS300 standard, cable version)
05/2021
A5E47827796-AA
Safety notes
The manual
Abbreviations and
identifications
Pointek CLS200/300
Standard
Installation
Wiring
Operation
Troubleshooting
Technical data
Technical reference
Maintenance and repairs
Hazardous area installation
Dimensions
Shortening the cable
Application
Product documentation and
support
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G

Advertisement

loading

  Related Manuals for Siemens Pointek CLS200

  Summary of Contents for Siemens Pointek CLS200

  • Page 1 Pointek CLS200/CLS300 standard Safety notes The manual Abbreviations and Point level identifications Pointek CLS200/300 Standard Capacitance switches Pointek CLS200/CLS300 standard Installation Wiring Operating Instructions Operation Troubleshooting Technical data Technical reference Maintenance and repairs Hazardous area installation Dimensions Shortening the cable...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3: Table Of Contents

    Safety notes ............................6 Safety marking symbols ....................... 6 The manual ............................7 Application examples ......................8 Abbreviations and identifications ......................9 Pointek CLS200/300 Standard ......................10 Pointek CLS200/300 applications..................11 Pointek CLS200/300 features ..................... 12 Installation ............................13 Safety notes........................13 Pointek CLS200 ........................
  • Page 4 High frequency oscillator ....................57 Detection range ......................... 57 CLS200 electrode ....................... 57 CLS300 electrode ....................... 58 Pointek CLS200 standard pressure versus temperature curves ..........60 A.6.1 CLS200 compact and extended rod versions, threaded ............60 A.6.2 CLS200 cable version, threaded ..................60 A.6.3...
  • Page 5 CLS 300 dimensions ......................88 D.2.2 Flange facing table ......................100 Shortening the cable ......................... 101 Pointek CLS200 Standard, cable version ................101 Pointek CLS300 Standard, cable version ................105 Application ............................106 Level detection ........................ 106 Alarm signaling ........................ 106 Fault signaling .........................
  • Page 6: Safety Notes

    Means important information about the product or that part of the operating manual. Safety marking symbols In manual On Product Description Caution: refer to accompanying documents (manual) for details. Earth (ground) Terminal Protective Conductor Terminal Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 7: The Manual

    Note Please follow the installation and operating procedures for a quick, trouble-free installation and to ensure the maximum accuracy and reliability of your Pointek CLS200/ 300. This manual applies to the Pointek CLS200/300 Standard model only. Pointek CLS200/300 is available in two models, Standard and Digital. For information on the CLS200/300 Digital model, please see manual 7ML19985JJ02.
  • Page 8: Application Examples

    The application examples used in this manual illustrate typical installations using Pointek CLS200/300; other configurations may also apply. In all examples, substitute your own application details. If the examples do not apply to your application, check the applicable parameter reference for the available options. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 9: Abbreviations And Identifications

    Farads Farad Process Device Manager configuration tool PEEK Polyaryletherether- organic polymer ketone Polyphenylene Sulfide polymer PTFE Polytetrafluoroethylene thermoplastic fluoro- polymer PVDF Polyvinylidene Fluoride engineered fluoropoly- Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 10: Pointek Cls200/300 Standard

    For information on the CLS200/300 Digital, please see manual 7ML19985JJ02. • Pointek CLS200/300 is to be used only in the manner outlined in this instruction manual, otherwise protection provided by the equipment may be impaired. • This product is intended for use in industrial areas. Operation of this equipment in a residential area may cause interference to several frequency based communications.
  • Page 11: Pointek Cls200/300 Applications

    Refer to Technical data (Page 50) for CE applications. Pointek CLS200/300 applications Pointek CLS200/300 is designed for level detection and simple pump control in a variety of applications: • Liquids, solids (powder and granules), slurries, interface detection (for example, oil/ water), and foam detection •...
  • Page 12: Pointek Cls200/300 Features

    Pointek CLS200/300 Standard 4.2 Pointek CLS200/300 features Pointek CLS200/300 features • Potted construction protects components from shock, vibration, humidity, and/or condensation • High chemical resistance on probes • Level detection independent of tank wall/pipe (CLS200 only) • Freely programmable set up covers wide range of applications/materials •...
  • Page 13: Installation

    The installer is responsible for providing appropriate strain-relief to prevent pulling or twisting. • Versions with blanking element mounted by default. Blanking elements are not to be used with any form of adaptors or reducers. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 14: Pointek Cls200

    • Before installing the instrument, verify that the environment complies with any restrictions specified on the product nameplate. • To ensure compliance with CE EMC regulations, please install in accordance with the testing details on Approvals (verify against product nameplate) in Pointek CLS200/300 (Page 50). 5.2.1...
  • Page 15: Location

    • Provide a sun shield to protect the transmitter from direct heat radiation. Precautions: • Avoid mounting Pointek CLS200 in locations subject to strong vibrations in the vicinity, whenever possible. • Do not exceed the permissible ambient temperature limits (see Environmental in Pointek CLS200/300 (Page 50) for details).
  • Page 16: Mounting

    Installation 5.2 Pointek CLS200 5.2.3 Mounting Pointek CLS200 (compact threaded probe shown) High level alarm Low level alarm ① Normal process level ② Vertical ③ Normal process level ④ Horizontal For high level alarm (level exceeds normal process level): • normally mounted into the vessel top, or •...
  • Page 17: Mounting Restrictions

    Installation 5.2 Pointek CLS200 5.2.3.1 Mounting restrictions Note • Keep the sensor at least 50 mm (2") away from any nozzle or tank wall. • If multiple units are used, allow at least 100 mm (4") between them, to prevent interference.
  • Page 18: Cls200 Dimensions

    Sensors must be at least 100 mm (4") apart. Mount diagonally if space is restricted See also Hazardous area installation (Page 68) 5.2.3.2 CLS200 dimensions Dimensions for all versions of the Pointek CLS200 Standard can be found in CLS200 (Page 77). Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 19: Process Cautions Cls200

    • Consider material surface configuration when installing unit. • Tensile load must not exceed probe or vessel rating (See Tensile(max) under Electrode - CLS200 Standard table in Pointek CLS200/300 (Page 50)). • Avoid areas where material build up occurs. Pointek CLS200/CLS300 standard...
  • Page 20 Installation 5.2 Pointek CLS200 Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 21: Pointek Cls300

    • Provide a sun shield to protect the transmitter from direct heat radiation. Precautions: • Avoid mounting Pointek CLS300 Standard in locations subject to strong vibrations in the vicinity, whenever possible. • Do not exceed the permissible ambient temperature limits (see Pointek CLS200/300 (Page 50) for details). 5.3.3 Mounting...
  • Page 22: Mounting Restrictions

    • Keep the sensor at least 50 mm (2") away from any nozzle or tank wall. • If multiple units are used, allow at least 500 mm (20") between them, to prevent interference. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 23 Installation 5.3 Pointek CLS300 Multiple Units Sensors must be 500 mm (20") Mount diagonally is space is restricted. apart. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 24: Process Cautions Cls300

    • Keep unit out of path of falling material, or protect probe from falling material. • Consider material surface configuration when installing unit. • Tensile load must not exceed probe or vessel rating. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 25 Installation 5.3 Pointek CLS300 Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 26: Cls300 Dimensions

    5.3 Pointek CLS300 Note Buildup of material in Active Shield area does not affect switch operation. 5.3.5 CLS300 dimensions Dimensions for all versions of the Pointek CLS300 Standard can be found in CLS300 (Page 88). Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 27: Wiring

    3. Ground the instrument according to local regulations. 4. Tighten the gland to form a good seal. 5. If you wish to carry out a function test, follow the test procedures in Functionality tests - CLS200 (Page 33). Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 28: Recommended Cable Entries (Equivalents Can Be Used)

    2. Feed cable through dome nut and clamping insert. Fold braided shield over clamping insert. Make sure that braided shield overlaps the O-ring by 3/32" (2 mm) and covers the entry 360 degrees. 3. Push clamping insert into body and tighten dome nut. Assemble into housing. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 29 (2) to the entry (5), and turn a further 1/2 to 3/4 turn with a wrench. Note Support the cable to prevent it from twisting. To ease the wiring inside the enclosure, it may be beneficial to strip the inner sheath of the cable. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 30 8 A @ 250 V AC, 2000 VA 5 A @ 30 V DC, 150 W ② Solid state switch 30 V DC/30 V AC (peak) 82 mA max Note Switch and potentiometer settings are for illustration purposes only. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 31: Relay Output Connection

    • Maximum Current: 82 mA • Non-polarized Connect protective earth wire to terminal provided in housing. Use crimp type cable socket for 4 mm screw diameter, ring form or U-form (e.g. DIN 46234) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 32: Diode Protection

    Nominal 24 V DC 48 V DC V DC 22 to 26 V 46 to 50 V 120 Ω 234 Ω Connect protective earth wire to terminal provided in housing and marked with Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 33: Functionality Tests - Cls200

    2. Turn the delay potentiometer P1 clockwise about 1/8 of a turn. 3. Grasp the probe with your hand. L1 should turn on immediately, but L2 should turn on after a longer delay than in Step 1. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 34: Functionality Tests - Cls300

    Test the switch function: 1. Turn the delay potentiometer P1 fully counter-clockwise. 2. Turn the trip point potentiometer P2 clockwise until the yellow sensor status LED L1 is off. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 35 Grasp the probe with your hand. The yellow sensor status light L1 will glow, indicating switch function. After an appropriate delay the red output status light L2 will glow. This concludes the switch function test. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 36: Operation

    Pointek CLS200 7.1.1 User interface • A switch bank of five dip switches allows you to control the settings for Pointek CLS200 (standard model). • Three LEDs (L2, L1, and L3) indicate output status, sensor status, and power ON or OFF.
  • Page 37: Indicators

    Failsafe The Failsafe function controls the response of Pointek CLS200 to a fault so that the process will be put into a safe mode of operation. (See Fault signaling (Page 107) for further details). Failsafe and Alarm mode are interconnected: •...
  • Page 38: Switch Bank

    Operation 7.1 Pointek CLS200 Relay and solid-state switch functionality Alarm Mode Dip Switch Covered Probe Uncovered Probe Failsafe High S3 - ON Failsafe Low S3 - OFF 7.1.1.3 Switch bank 4 dip switches (S1, S2, S3, and S5) control settings for the alarm output. The fifth dip switch (S4) is used only to test the delay settings.
  • Page 39: Setup

    7.1.1.5 Start up After Pointek CLS200 is properly mounted apply power to the unit. The green LED (L3) glows, indicating the unit is powered and operational. Pointek CLS200/CLS300 standard...
  • Page 40 Operation 7.1 Pointek CLS200 Setpoint Adjustment ① Delay: alarm activation ② Delay: alarm deactivation ③ Failsafe/alarm ④ Test delay settings ⑤ Setup mode / run mode When S3 is set to ON, it inverts the relay function, and the functioning of S1 and S2.
  • Page 41 8. Set DIP switch S5 to OFF (run mode). Delay alarm output If you want to slow the Pointek CLS200 response, to compensate for turbulence or false readings, set a delay interval using potentiometer P1, and set S1 and/or S2 to OFF, to enable the delay for either alarm activation, alarm de-activation, or both.
  • Page 42: Pointek Cls300

    To test the delay function, follow the test procedure on Functionality tests - CLS200 (Page 33). Operation After completing the setup, replace the lid and secure the lid clip. Pointek CLS200 Standard model is now ready to operate. Pointek CLS300 7.2.1...
  • Page 43: Indicators

    (See Fault signaling (Page 107) for further details). Failsafe and Alarm mode are interconnected: • High Alarm/Failsafe High • Low Alarm/Failsafe Low Relay and solid-state switch functionality Alarm Mode Dip Switch Covered Probe Uncovered Probe Failsafe High Failsafe Low Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 44: Switch Bank

    (alarm OFF) protection S2-ON disables delay of alarm activation (alarm ON) S3- OFF Low alarm/dry run S1-ON disables delay of alarm activation (alarm ON) protection S2-ON disables delay of alarm de-activation (alarm OFF) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 45: Setup

    7.2.1.5 Start up After Pointek CLS300 is properly mounted and the switch bank is set up, apply power to the unit. The green LED (L3) glows, indicating the unit is powered and operational. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 46 Interface detection • immerse sensor in OFF (low) liquid A / liquid B whichever material has • foam / liquid lowest dielectric con- stant Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 47 Interface detection (Failsafe Low, no delay, sensitivity adjusted to detect an interface) Preparation • Ensure that L3 (green) is lit. • Turn delay potentiometer P1 fully counter-clockwise (to minimum). • Turn trip point potentiometer P2 fully counter-clockwise (to maximum). Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 48 To test the delay function, follow the test procedure on Functionality tests - CLS300 (Page 34). Operation After completing the setup, replace the lid and secure the lid clip. Pointek CLS300 Standard model is now ready to operate. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 49: Troubleshooting

    Readjust trip point potentiometer P2. L1 (yellow) responds when Check that relay changes state when sensor is covered. S3 is toggled ON and OFF L1 (yellow) flashes when ma- terial level approaches the alarm setpoint. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 50: Technical Data

    Technical data Note Siemens makes every attempt to ensure the accuracy of these specifications, but reserves the right to change them at any time. Pointek CLS200/300 Power Supply 12 to 250 V AC/DC (0 to 60 Hz) Ex approvals Max voltage which does not invalidate the intrinsically safe protection of the sensor (probe);...
  • Page 51 Technical data 9.1 Pointek CLS200/300 Failsafe operation Failsafe High or Failsafe Low Delay timers 2: Alarm ON to OFF and Alarm OFF to ON Mechanical Electrode - CLS200 Standard Model Length Process Connections Extension Tensile Wetted Parts (max) (max) 5500 mm/...
  • Page 52 Technical data 9.1 Pointek CLS200/300 Electrode - CLS300 Standard Model Length Process Connections Tensile Wetted Parts (max) (max) Rod (19 1000 • Threaded: ¾”, 1", or 1 ½" BSPT • 316L stainless steel mm/40” (R), BSPP (G) or NPT; 1 ¼” NPT •...
  • Page 53 (outdoor applications). For CE requirements the use of EMC rated cable entries is required for all CLS200 devices and for CLS300 devices with flange process connections. Weight Weight varies based on configuration. For example: compact Pointek CLS200/300, 1 kg (2.20 lb.) approx. 100 mm (4”) insertion length, 3/4” process connection Or 1.4404 material...
  • Page 54 Technical data 9.1 Pointek CLS200/300 Process Note Please see Pointek CLS200 standard pressure versus temperature curves (Page 60) and Pointek CLS300 standard pressure versus temperature curves (Page 63). relative dielectric constant (ε 1.5 minimum Temperature at process connection CLS200 temperature: 1)2) –40 to 85 °C (–40 to 185 °F)
  • Page 55 WHG (Germany) Note EN 61326 (CE EMC) testing was conducted on the Pointek CLS200 while mounted in a metallic vessel and wired using shielded cable, where the cable was terminated in an EMC cable gland at the device entry point.
  • Page 56: Technical Reference

    For definitions relating to capacitance, see the Glossary. The relative dielectric constant of air (vacuum) is 1: all other materials have a higher value. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 57: High Frequency Oscillator

    The Pointek CLS200 electrode is the primary sensor of the system. It supplies the electrical capacitance value. The reference is the environment at the time of setup. The design of the Pointek CLS200 probe makes it very sensitive to changes in capacitance in the immediate vicinity of the electrode tip.
  • Page 58: Cls300 Electrode

    Active Shield section. This effectively eliminates any electrical potential difference between the shield and the measurement section and prevents additional changes in capacitance occurring, especially when material builds up at the probe entrance to the tank. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 59 The powder-coated aluminum enclosure provides reliable operation in environments with dust, moisture, and high-frequency interference. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 60: Pointek Cls200 Standard Pressure Versus Temperature Curves

    Technical reference A.6 Pointek CLS200 standard pressure versus temperature curves Pointek CLS200 standard pressure versus temperature curves A.6.1 CLS200 compact and extended rod versions, threaded ① Atmospheric ② Permitted operating pressure ③ Permitted operating temperature A.6.2 CLS200 cable version, threaded ①...
  • Page 61: Cls200 Sanitary Compact And Extended Rod Versions

    Technical reference A.6 Pointek CLS200 standard pressure versus temperature curves A.6.3 CLS200 sanitary compact and extended rod versions ① Atmospheric ② Permitted operating pressure ③ Permitted operating temperature A.6.4 CLS200 compact and extended rod, ASME welded flange ① Atmospheric ②...
  • Page 62: Cls200 Cable, Asme Welded Flange

    Technical reference A.6 Pointek CLS200 standard pressure versus temperature curves A.6.5 CLS200 cable, ASME welded flange ① Atmospheric ② Permitted operating pressure ③ ASME 150 lb ④ Permitted operating temperature The curve denotes the minimum allowable flange class for the shaded area below.
  • Page 63: Cls200 Cable, En Welded Flange

    The curve denotes the minimum allowable flange class for the shaded area below. Pointek CLS300 standard pressure versus temperature curves A.7.1 CLS300 standard, extended rod and cable versions, threaded ① Atmospheric ② Permitted operating pressure ③ Permitted operating temperature Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 64: Cls300 High Temperature Rod Version, Threaded

    CLS300 standard, extended rod and cable versions, ASME welded flange ① Atmospheric ② Permitted operating pressure ③ ASME 300 lb ④ ASME 150 lb ⑤ Permitted operating temperature The curves denote the minimum allowable flange class for the shaded area below. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 65: Cls300 High Temperature Rod Version, Asme Welded Flange

    CLS300 standard, extended rod and cable versions, EN welded flange ① Atmospheric ② Permitted operating pressure ③ PN 40 ④ PN 16 ⑤ Permitted operating temperature The curves denote the minimum allowable flange class for the shaded area below. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 66: Cls300 High Temperature Rod Version, En Welded Flange

    CLS300 high temperature rod version, EN welded flange ① Atmospheric ② Permitted operating pressure ③ PN 40 ④ PN 16 ⑤ Permitted operating temperature The curves denote the minimum allowable flange class for the shaded area below. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 67: Maintenance And Repairs

    Please note the following: • The user is responsible for all changes and repairs made to the device. • All new components must be provided by Siemens Milltronics Process Instruments Inc. • Restrict repair to faulty components only.
  • Page 68: Hazardous Area Installation

    Certificate numbers: See EU - Declaration of Conformity for the list of standards valid for ATEX certificates. ATEX year of manufacturing Year of 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2029 manufac- ture Marking code Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 69: Cls200 Approvals

    II 2(1) D Ex ia tb [ia Da] IIIC TX Db Level probe II 1 G Ex ia IIC TX Ga II 1 D Ex ia IIIC TX Da II 1/2 D Ex ia IIIC TX Da/Db Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 70: Atex: Permitted Zones For Installation (Cls200)

    C.2 CLS200 approvals C.2.2 ATEX: permitted zones for installation (CLS200) Rod version Ambient side Dust applications Gas applications Marking Da/Db Ga/Gb Category Zone Process side Dust applications Gas applications Category Zone Cable version Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 71: Flame Proof And Dust Ignition Proof (Cls200)

    -40 to +80 °C (-40 to +176 °F) T90 °C For process temperature > 85 °C: only applicable for versions with thermal isolator With option FFKM O-ring seal: lower process temperature limited to - 20 °C (-4 °F) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 72: Inmetro (Cls200)

    Explosion Proof / Dust Ignition Proof Ambient temperature range Process temperature range Temperature class -40 to +85 °C (-40 to +185 °F) -40 to +125 °C (-40 to +257°F) See also FM/CSA connection drawing (Page 76) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 73: Cls300 Approvals

    II 1/2 G Ex ia/db [ia Ga] IIC TX Ga/Gb II 1/2 D Ex ia/tb [ia Da] IIIC TX Da/Db C.3.2 ATEX: permitted zones for installation (CLS300) Ambient side Dust applications Gas applications Marking Da/Db Ga/Gb Category Zone Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 74: Flame Proof And Dust Ignition Proof (Cls300)

    Temperature class -40 to +70 °C (-40 to +158 °F) -40 to +80 °C (-40 to +176 °F) -40 to +85 °C (-40 to +185 °F) -40 to +100 °C (-40 to +212 °F) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 75: Fm/Csa (Cls300)

    +85 °C. C.3.5 FM/CSA (CLS300) Explosion Proof / Dust Ignition Proof Ambient temperature range Process temperature range Temperature class -40 to +85 °C (-40 to +185 °F) -40 to +125 °C (-40 to +257°F) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 76: Fm/Csa Connection Drawing

    Hazardous area installation C.4 FM/CSA connection drawing FM/CSA connection drawing Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 77: Dimensions

    Dimensions CLS200 Enclosure, threaded process connection ① 2 cable entries 1/2 NPT or M20x1.5 ② Therman isolator Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 78 Dimensions D.1 CLS200 Compact version, threaded ① Electronics/enclosure ② PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 79 Extended rod version, threaded ① Y01 (insertion length) Min. insertion length = 200 mm (7.87") Max. insertion length = 5500 mm (216") ② 316 L stainless steel extension ③ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 80 Dimensions D.1 CLS200 Sanitary compact version ① 316L stainless steel sanitary process connection ② PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 81 Y01 (insertion length) Min. insertion length = 110 mm (4.3") Max. insertion length = 5500 mm (216") ② 316L stainless steel sanitary process connection ③ 316L stainless steel extension ④ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 82 Sliding coupling version, threaded ① Y01 (insertion length) Min insertion length = 350 mm (13.82") Max insertion length = 5500 mm (216") ② 316L stainless steel sliding coupling ③ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 83 Min. insertion length = 500 mm (19.69") Max. insertion lenth = 35000 mm (1378") ② FEP insulated cable ∅ 6 mm (0.3") ③ 316L stainless steel sensor weight ④ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 84 2 cable entries 1/2" NPT or M20x1.5 ② Thermal isolator Flange facing table Flange Facing (raised face) Flange Class Facing thickness Δ ASME150/300 2 mm (0.08") Δ ASME600/900 7 mm (0.28") Δ PN16/40 2 mm (0.08") Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 85 Dimensions D.1 CLS200 Compact version, welded flange ① Electronics/enclosure ② PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 86 Extended rod version, welded flange ① Y01 (insertion length) Min. insertion length = 200 mm (7.87") Max. insertion length = 5500 mm (216") ② 316L stainless stell extension ③ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 87 316L stainless steel sensor weight Min. insertion length = 500 mm (19.69") Max. insertion length = 30000 mm (1181") ② FEP insulated cable ∅ 6 mm (0.3") ④ PPS or optional PVDF probe Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 88: Cls300

    Dimensions D.2 CLS300 CLS300 D.2.1 CLS 300 dimensions Threaded process connection ① 2 cable entries 1/2" NPT or M20x1.5 ② Thermal isolator Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 89 Dimensions D.2 CLS300 Rod version, threaded ① Probe ② ③ Y01 (insertion length) ④ Measuring length Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 90 Dimensions D.2 CLS300 High temperature rod version, threaded ① Probe ⑤ Y01 (insertion length) ② Ceramic insulator(s) Min.= 350 mm (14") ③ Thermal isolator Max. 1000 mm (39") Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 91 Dimensions D.2 CLS300 ④ Y02 ⑥ Measuring length Extended active shield (Y02): standard length 125 mm (4.92") Optional active shield lengths: 250 mm (9.84") or 400 mm (15.75") Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 92 Extended active shield (Y02): standard length 125 mm (4.92") Optional active shield lengths: 250 mm (9.84") or 400 mm (15.75") ④ Y01 (insertion length) Min = 1000 mm (40") Max = 25000 mm (984") ⑤ Measuring length Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 93 Stainless steel weight ② PFA insulated cable ③ ④ Y01 (insertion length) Extended active shield (Y02): standard length 125 mm (4.92") Optional active shield lengths: 250 mm (9.84") or 400 mm (15.75") ⑤ Measuring length Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 94 Dimensions D.2 CLS300 Flanged process connections Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 95 Rod version, welded flange ① Probe ⑤ Active shield ② Electronic/enclosure ⑥ Y01 (insertion length) Min. = 250 mm (9.8") Max. = 1000 mm (39.37") ③ Lid clip ⑦ Measuring length ④ Lid Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 96 D.2 CLS300 High temperature rod version, welded flange ① Probe ② Ceramic insulator(s) ③ Thermal isolator ④ ⑤ Y01 (insertion length) Min. = 250 mm (9.8") Max. 1000 mm (39.37") ⑥ Measuring length Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 97 Extended active shield (Y02): standard length 125 mm (4.92") Optional active shield lengths: 250 mm (9.84") or 400 mm (15.75") ④ Min = 1000 mm (40") Max = 25000 mm (984") ⑤ Measuring length Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 98 Extended acutive shield (Y02): standard length 105 mm (4.13"). Optional active shield lengths: 230 mm (9.06") or 380 mm (14.96") Insertion length does not include any raised face/gasket face dimension (see Flange facing table (Page 100)) Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 99 ③ Extended active shield (Y02): standard length 105 mm (4.13") ④ Y01 (insertion length) Insertion length does not include any raised face/gasket face dimensions (see Flange facing table (Page 100)) ⑤ Measuring lenth Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 100: Flange Facing Table

    Dimensions D.2 CLS300 D.2.2 Flange facing table Flange Facing (raised face) Flange Class Facing thickness Δ ASME150/300 2 mm (0.08") Δ ASME600/900 7 mm (0.28") Δ PN16/40 2 mm (0.08") Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 101: Shortening The Cable

    Shortening the cable Pointek CLS200 Standard, cable version CAUTION Possible only with the general purpose configuration; please verify against product nameplate. Preparation Determine the required cable length, and subtract that amount from the actual length, to find the excess length to cut off.
  • Page 102 Shortening the cable E.1 Pointek CLS200 Standard, cable version Steps 1. Unscrew the cable gland compression nut to relieve the sealing cone and release the cable. ① Cable gland compression nut ② Probe sleeve ③ Probe, lower assembly 2. Unscrew the probe sleeve from the lower assembly using two 17 mm (0.67") wrenches across the flat surfaces, as shown below.
  • Page 103 Shortening the cable E.1 Pointek CLS200 Standard, cable version 3. Remove the heat shrink insulation covering the solder connections. ① Lead ② 9.5 mm (0.37") heat shrink insulation ③ Cable core ④ Tension block ⑤ Steel spacer 4. Unsolder the connections.
  • Page 104 Shortening the cable E.1 Pointek CLS200 Standard, cable version 11.Prepare the leads for soldering, and if heat shrink is used to insulate splices, remember to slip on the heat shrink before soldering the leads. 12.Make the solder connections and position the heat shrink to completely insulate each solder connection before shrinking it.
  • Page 105: Pointek Cls300 Standard, Cable Version

    Make sure that no cable strands are pushed out of their position in the cable and that the cable is fully inserted. 5. Re-fasten the weight by tightening the three set screws. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 106: Application

    The relay and solid-state switch are interlinked: when the change in capacitance is greater than the setting at the trip point, the output switches. (For a diagram illustrating the relay and solid-state switch contacts, see Pointek CLS200 (Page 36) (for CLS200) or Pointek CLS300 (Page 42) (for CLS300).)
  • Page 107: Fault Signaling

    The following examples assume that the pump should be turned off in the event of a failure. If this is not the case in your process, please see the relay diagram on Pointek CLS200 (Page 36) (for CLS200) or Pointek CLS300 (Page 42) (for CLS300), and make the appropriate connections to suit your application.
  • Page 108: Product Documentation And Support

    Entering a serial number 1. Open the PIA Life Cycle Portal (https://www.pia-portal.automation.siemens.com). 2. Select the desired language. 3. Enter the serial number of your device. The product documentation relevant for your device is displayed and can be downloaded.
  • Page 109: Technical Support

    In addition to our technical support, Siemens offers comprehensive online services at Service & Support (http://www.siemens.com/automation/service&support). Contact If you have further questions about the device, contact your local Siemens representative at Personal Contact (http://www.automation.siemens.com/partner). To find the contact for your product, go to "all products and branches" and select "Products &...
  • Page 110: Glossary

    This is measured by the ratio of the capacitance of a condenser with the material as Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 111 “the loop-current will saturate to 3.8 or 20.5 if the level exceeds the Range settings” solid-state device a device whose function is performed by semi-conductors or the use of otherwise completely static components such as resistors and capacitors. stilling-well a grounded metal tube with openings. Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 112: Index

    16, 17, 21 mounting restrictions, 22 failsafe multiple units, 23 functioning (analog), 107 failsafe high (analog), 107 failsafe low (analog), 107 failsafe/alarm setting (analog), 38, 44 operating principles, 56 fault signalling options (analog), 107 Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...
  • Page 113 (analog), 31 start up (analog), 39, 45 Support, 109 Support request, 109 Technical support, 109 partner, 109 personal contact, 109 tension block, 102 test settings (analog), 39, 45 troubleshooting (analog), 49 wiring (analog), 27 Pointek CLS200/CLS300 standard Operating Instructions, 05/2021, A5E47827796-AA...

This manual is also suitable for:

Pointek cls300
