7.2. Specifications

General
Dimensions (W x L x H) in mm
Weight
Housing material
Electrical
Rated supply voltage
Voltage drop to sensor supply
Internal current consumption at 24V DC
Input connection type
Over voltage protection
Short circuit protection
Sensor supply current per connector
Sensor supply current per module
Status indication
Short circuit indication
Digital input
Number of inputs
Input type
Signal 1
Signal 0
Permissible residual current
Input current signal 1
Table. 7-1 EX245-DX1 specifications
Item Description
54 x 120 x 61
280 g or less
Nylon, PBT
24 VDC
Max. 1.6 V
50 mA or less
8 x M12, 5-way sockets with double allocation
A-coded (Normal key)
Yes, more than 30 VDC at US1 (sensor/input)
Yes
Max. 0.5 A
Max. 2 A
Yes, per input
Yes, per connector
16
PNP
11 to 30 V
-3 to 5 V
Max. 1.5 mA
Typ. 4.5 mA
