10.4. Joint pack

One "Joint assembly" and two "Modular adaptor assembly" are contained in one "Joint pack".

Model No.: EX245-ZJP

Joint assembly

NOTE

・

One Joint pack is attached to the EX245-DX1, EX245-DY1 and EX245-EA2-1/2.

・

Regarding mounting, refer to the

Modular adaptor assembly

Fig. 10-7 EX245-ZJP

Section

3.1.2.

-56-

No.EX##-OMU0020-A
