1.2. Structure
No.
Components
1
SI Unit
2
Digital Input Module
3
Digital Output Module
4
End plate
5
Solenoid valves
Fieldbus, valve interface and supply voltage to modules
Supply voltage to sensors and input digital data
Output to electric loads
End plate of module
Operate pneumatic devices
Fig. 1-1 System structure
-11-
Function
No.EX##-OMU0020-A
