5. Diagnosis

5.1. Diagnostics data on I/O mapping

The SI unit can be allocated diagnostics data as digital input data on I/O mapping, if one of the module,
Diagnostics type 1 or Diagnostics type 2, is configured. Use PROFINET master's software to select a
requested diagnostics type to allocate the diagnostics data on I/O mapping.
5.1.1. Diagnostics type 1
5.1.1.1. General diagnostics 1
Bit Description
0 System fault
1 Valve-coil(s) short circuit
2 Module error
3 Changed module layout
4 US1 Diagnostics
5 US2 Diagnostics
6 US3 Diagnostics
7 US4 Diagnostics
NOTE
・ The diagnostics on I/O mapping "US3 Diagnostics" and "US4 Diagnostics" are options which
can be enabled to use a special module.
Table. 5-1 Overview of Diagnostics type 1
Byte Description
0 General diagnostics 1
1 General diagnostics 2
2 Valve diagnostics 1
3 Valve diagnostics 2
Table. 5-2 General diagnostics 1
0: No error on Diagnostics data on I/O mapping
1: At least one error on Diagnostics data on I/O mapping has occurred
0: No valve coil(s) have a short circuit
1: At least one valve coil has a short circuit
0: No module has an error
1: At least one connected module has an error
0: Module layout has not changed
1: Module layout has changed or is different from Configuration setting
0: US1 present (> approx. 21.6 VDC)
1: US1 has dropped (< approx. 20.4 VDC)
0: US2 present (> approx. 22.8 VDC)
1: US2 has dropped (< approx. 21.6 VDC) or not present
0: First additional supply for the loads (US3) present (> approx. 22.8 VDC)
1: First additional supply for the loads (US3) has dropped (< approx. 21.6 VDC)
or not present
0: All additional supplies for the loads excluding the first one (US4, US5, etc.)
present (> approx. 22.8 VDC)
1: At least one of additional supplies for the loads excluding the first one (US4,
US5, etc.) has dropped (< approx. 21.6 VDC) or not present
-26-
Explanation
