Model No.:EX245-AWP
(10 pieces for Push Pull connectors of power connection)
The EX245-AWP can be used with the EX245-SPN1/EX245-SPN2.
Mount the seal cap in the unused connector.
IP65 rating is maintained by using the seal cap properly.
Model No.:EX245-AWC
(10 pieces for Push Pull connectors of PROFINET connection)
The EX245-AWC can be used with the EX245-SPN1/EX245-SPN2.
Mount the seal cap in the unused connector.
IP65 rating is maintained by using the seal cap properly.
NOTE
・
In case of the EX245-SPN1 or EX245-SPN2, the Seal caps is fitted to all bus & power connector
when shipped from factory.
Fig. 10-5 EX245-AWP
Fig. 10-6 EX245-AWC
-55-
No.EX##-OMU0020-A
