Flash Card And Microcontroller Replacement; Flash Card - Cafection Encore Ground Service & Installation Manual

9.5

Flash Card and Microcontroller Replacement

The flash card and the microcontroller can be replaced in order to improve and update the
machine's software.
9.5.1
Before you begin, turn power OFF.
72
SERVICE & INSTALLATION MANUAL for Cafection's Encore Ground

Flash Card

The flash card holds the GUI software (Graphical User Interface).
All drinks recipes, sales counters and other settings are stored in the flash card.
To remove the flash card:
1. Remove the mainboard protection panel (inside the door).
2. Pull the flash card outward.
To install the flash card:
1. Make sure the colored side of the card is on the right.
2. Insert the flash card and push it GENTLY to make sure no damage is done.
3. Screw back the mainboard protective cover.
4. Turn power back ON.
5. At startup, the screen will indicate the flash card version.
Enter the serial number of the brewer under the Admin tab to ensure proper internet
network communications (see section 6.6.6).
XXXXXX-XXXXXXXXX
www.cafection.com 800-561-6162
MAKE SURE THE
VERSIONS OF THE
MICROCONTROLLER AND
THE FLASH CARD MATCH.
Colored side
ENCORE GROUND Rev. 0 2017-04
