© Panduit Corp.
2020
4B: Environmental
When storing and transporting an unused unit, please take care to use the original packaging.
Operational Temperature and Humidity
Storage/ Transportation Temperature and Humidity
5: INSTALLATION / SETUP
5A: Take Inventory
1. Remove components from the shipping box and refer to section 5B for an itemized component list.
5B. What's Included
1. WA29569D01 - Tool Cage Assembly
2. WA29568E01 and WA29567D01 - PATMFM4.0 Fixture Assembly
3. WA29602C01 - Tip Deflector
4. WA29606D01 - Table-Top Template
5. CA29558B01 - EI Communication Cable
6. WA29653C01 - Air Regulator
7. WA29516B01 - Tool Cavity Cover
8. CA29740B01 - (x8) #6-1.0" Mounting Screws (For Wood)
5C. Modify Work Surface with Template
1. Lay the cut-out template down onto the desired work surface. A dashed line on the template denotes the
minimum distance relative to the leading edge, as required by the fixture. Once the template is aligned
appropriately, secure the sheet at each corner and ensure the template is flat against the work surface.
2. Using the template as a guide, drill a total of eight (8) 5/64" diameter through holes.
3. Using the template as a guide, cut inside the solid rectangular outline.
4. Once the above has been completed, remove the template and recycle.
5. This completes the process of preparing a work surface for the fixture to be installed.
(If the required work surface is to be metal, use the appropriate countersunk sheet metal fasteners and
hardware in the next step – not included).
5D. PATMFM4.0 Fixture Assembly Installation
installation).
1. Secure the Fixture Assembly to the work surface using the provided #6 Philips head screws around the
perimeter of the Overlay Plate. Pay attention to the sensor wiring located on the underside of the Fixture
Assembly. Be careful not to pinch the sensor harness between the Assembly and the work surface.
OPERATION MANUAL
14
+10C(+50F) to +38C(+100F) Max 90% RH
Non-Condensing
-40C(-40F) to +70C (+158F) Max 90% RH
Non-Condensing
(Ensure that the PAT4.0 system is off before
PATMFM4.0
ENGLISH
